Unpacking and Setup
This section provides unpacking and setup information for LinkStation.
Open the shipping carton of LinkStation and carefully unpack its contents. The
carton should contain the following items:
Main unit (LinkStation)
LinkStation Base Plate
Base Rubber Feet
Ethernet Cable
Power Cord
LinkNavigator Installation CD
Quick Setup Guide (this user's guide)
Warranty card
If any items are missing or damaged, please contact the reseller or retailer from
which the product was purchased.
The front face of the LinkStation has a protective plastic film covering for
protection from scratching during assembly and shipping. The film can be
removed by peeling it away from any corner of the front face.
Quick Setup Guide
www.buffalo-technology.com
LinkStation
HD-HGLAN Series
1
1
4
1
1
1
1
1
PY00-31003-DM20-01 1-01
Advertisement
Table of Contents
Related Manuals for Buffalo HD-HGLAN Series
Summary of Contents for Buffalo HD-HGLAN Series
-
Page 1: Quick Setup Guide
The front face of the LinkStation has a protective plastic film covering for protection from scratching during assembly and shipping. The film can be removed by peeling it away from any corner of the front face. Quick Setup Guide www.buffalo-technology.com LinkStation HD-HGLAN Series PY00-31003-DM20-01 1-01... - Page 2 Press the power button on the front of LinkStation to turn LinkStation on. Connect the other end of the included Ethernet Cable into a hub, switch, or router on the network, or connect it directly to a nearby running PC.
- Page 3 If it is lit, turn to Page 4 to contintue setting up LinkStation. If the LINK/ACT light is still not lit, please verify the following: Both LinkStation and the hub, switch, or PC are powered on. The Ethernet Cable is securely fastened to both devices.
-
Page 4: Link Navigator Setup
Link Navigator Setup The setup of Link Navigator is performed using the following steps: Insert the LinkNavigator CD into the PC’s CD-ROM drive. Depending on the PC’s configuration, the EasySetup program may launch. If it does not automatically launch, manually launch it by pressing the ‘Start’... - Page 5 Link Navigator Setup This part of the program changes LinkStation’s IP Address. Check the box that states ‘Acquire IP Address Automatically’. This will give LinkStation an IP Address from the network’s router/DHCP server. A static IP Address and gateway can also be set if preferred.
- Page 6 LinkStation Configuration LinkStation, or simply name it LinkStation. Enter a short description of LinkStation in the ‘LinkStation press the ‘Apply’ button. By default there are two shares on LinkStation. If you would like to create additional shares for specific users or specific types of data, then click on the ‘Security’...
-
Page 7: Accessing Linkstation Data From A Pc
Accessing LinkStation Data from a PC Accessing LinkStation data is performed using the following steps: Press the ‘Start’ menu, select the ‘Run...’ option. When the ‘Run’ dialog appears, please type \\LinkStation_Name (where LinkStation_Name is the ‘LinkStation Name’ set on Page 6). -
Page 8: Technical Specifications
Technical Specifications LAN Standards: Transmission Types: Access Media: Media Interface: USB Standard: USB Connector: Data Transmission Speed: Electric Current: Power Consumption: Dimensions: Weight: Operating Temperature: IEEE 802.3u 100BASE-TX; IEEE 802.3 10BASE-T 1000Mbps/100Mbps/10Mbps; (1000BASE-T) 8B1Q4+PAM5 (100BASE-T) 4B5B+MLT-3 (10BASE-T) Manchester Coding CSMA/CD RJ-45 USB 2.0 Hi-Speed (HS) -
Page 9: Ce Mark Warning
Technical Support Buffalo Technology offers Technical Support between the hours of 9am-6pm (GMT) Monday to Thursday and 9am-4:30pm (GMT) Friday for this product. Customers in Europe can obtain Technical Support using the following... - Page 10 MEMO...
- Page 11 MEMO...
-
Page 12: Warranty Statement
Fax: +44 (0) 1753 535420 E-mail: sales@buffalo-technology.com Copyright © 2005 Buffalo Technology UK, Ltd. All Rights Reserved. - Buffalo Technology UK, Ltd. is part of BUFFALO INC., the global manufacturers of IT peripherals, including memory, networking, and multimedia products, inside many of the world’s computers. All trademarks are the property of their...
