  • Page 2 MiniHub Install Manual Version 07 June 2013 Page 2 MiniHub User Guide 2/18/2013...

  • Page 3: Table Of Contents

    Table of Contents TABLE OF CONTENTS ............................1 1.GENERAL DESCRIPTION ..........................2 2.HUB SPECIFICATIONS ............................. 2 3.INSTALLATION ..............................5 4.SAFETY ................................6 5.SUPPLY DISCONNECT SWITCH ........................6 5.ENVIRONMENTAL CHARACTERISTICS ......................6 7.MAINTENANCE ............................... 7 APPENDIX 1 ................................ 9 APPENDIX 2 ................................ 9 Page 3 MiniHub User Guide 2/18/2013...

  • Page 4: General Description

    1.General Description The n-DNet™ MiniHub is a standalone network interface unit connecting endpoints to the Mobix patented n-Dimensional Network (see box for n-DNet™ description) It is a feature rich MiniHub designed to collect, store and forward data from up to 2 meters. Meters could be in any combination of electric, gas and/or water with Pulse, RS-232 or RS-485.

  • Page 5: Hub Specifications

    1.Hub Specifications The following tables list the Hub specifications: Physical Specification: Specification Value Length 18 mm Width 10 mm Height 5.3 mm Electrical Specifications: Specification Value Input voltage 110-230 VAC Input Frequency 50-60 HZ Max load consumption 1.5 Watt Environmental : Specification Value Operating temperature Range...
  • Page 6 Specification Value PLC standard Complies with FCC,ARIB and EN50065-1-CENELEC (EU) regulations RF standard: Specification Value RF standard Complies with FCC, ETSI and ARIB Frequency 240–930 MHz Sensitivity -118dBm Max Output Power 20dBm Interfaces Specification Value Pulse/Alarm input port Page 6 MiniHub User Guide 2/18/2013...
  • Page 7 Output port (for valve control) Serial interface RS-232,RS-485 AC switch control 0-100ma/110-250VAC Page 7 MiniHub User Guide 2/18/2013...

  • Page 8: Installation

    1.Installation 1.There are 2 options to mount the MiniHub: •Mount on a DIN rail using the dedicated DIN mounting on the back of the box. •Using the mounting holes on the back of the box See appendix 2 2.To prevent fire spreading in case of circuit faults, the Hub must be installed in a suitable fire enclosure to the latest version of UL 61010-1, without any openings at the bottom.
  • Page 9 4.According to the scheme of connection: •Meter pulse wires (IN_1,IN_2,GND) The number indicates the meter’s number Each two meters have a joint ground connection Connect the (+) wire to the numbered input Connect the (-) wires to the joint GND connector Obj102 1.Meter Pulse + Valve control (GND,IN_2,IN_1,Out_2,Out_1) The output number indicates the controlled valve.

  • Page 10: Safety

    4.Safety •Connect the input and output wires only when mains are not connected •To prevent fire spreading in case of shortcut, the hub must be installed in a suitable enclosure without any openings at the bottom. •Connect mains only to 110-230Vac power source •All AC connections should be done by an authorized electrician •The unit intends to be powered from building wiring in Overvoltage Category II.

  • Page 11: Maintenance

    WARNING: No user-serviceable parts inside • If any component part is found to be damaged and/or in need of service, have all such service performed by a certified electrical contractor or qualified Mobix personnel. Keep the Hub clean • Regularly check for and remove foreign objects or debris on or around your Hub.
  • Page 12 • If operating, disconnect the Hub from the power source. • Inspect the Hub supply cord – look for nicks in the insulation or excessive rubs on the cord. Page 12 MiniHub User Guide 2/18/2013...
  • Page 13 Appendix 1 MiniHub external box Page 13 MiniHub User Guide 2/18/2013...
  • Page 14 Appendix 2 MiniHub installation points Page 14 MiniHub User Guide 2/18/2013...
  • Page 15 Page 15 MiniHub User Guide 2/18/2013...
