Doufit TD-01 Instruction Manual

Hide thumbs

Table Of Contents

TD-01 Treadmill

Instruction Manual

* Please read the instruction manual carefully and follow it.

* Please keep the instruction manual for your later use.

* If you want to give this product to your friends, don't forget to bring them the instruction manual.

Table of Contents

Need help?

Do you have a question about the TD-01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Doufit TD-01

Page 1 TD-01 Treadmill Instruction Manual * Please read the instruction manual carefully and follow it. * Please keep the instruction manual for your later use. * If you want to give this product to your friends, don't forget to bring them the instruction manual.
Page 2: Table Of Contents
Catalogue Precautions .......................... Parts List ..........................Product Brief ........................Assembly Method ....................... Details of Monitor ....................... Operation Guide ........................Adjustment & Maintenance ....................Error Messages & Solutions ....................Service........................... Precautions *The maximum load bearing is 110Kg (about 220 Lbs). *It’s for home use rather than commercial use. *If you feel unwell during using the treadmill, please stop using it immediately and consult your doctor for instructions before next use.
Page 3: Parts List
Parts List Notice：if any part is missing, distorted or broken when you receive the package, please contact service@doufit.net with your order number, we will send the replacement part to you as soon as possible. Component 1.Treadmill 2.Ipad bracket upper cover 3.Ipad bracket bottom cover...
Page 4: Product Brief
Product brief Monitor Power Cord and Switch Motor Cover Fixed Knob Strake Strake Handrail Frame Running Belt Adjustment Bolt of the Running Belt Ipad Bracket Page 3...
Page 5: Assembly Method
Assembly Method Step 1: Raise the armrest Place the treadmill on a flat floor. Raise the armrest as shown. Screw two knobs(No.4) to the bottom of the treadmill to fix the armrest. Step2: Assemble the Ipad bracket Attach the Ipad bracket covers(No.2)(No.3) to the armrest.
Page 6: Details Of Monitor
Details of Monitor Parameters TIME 0:00-60:00 MIN SPEED 1.0-6.0 KM/H DISTANCE 0.00-99.00KM CALORIES 0.0-990KCAL SPEED TIME DIST Operation Guide 1.Insert the plug of the treadmill. 2.Open the power switch on the front of the treadmill. The power switch will be bright. 3.Use the remote control to start your exercise.
Page 7: Adjustment & Maintenance
Adjustment & Maintenance Adjustment of running belt When the running belt leans left when running, please keep the treadmill running at the slowest speed. And then screw the right adjustment bolt clockwise by using the wrench until the belt straight. On the contrary, if the belt leans right, please screw the left adjustment bolt clockwise until the belt straight.
Page 8: Error Messages & Solutions
Treadmill Common Error Messages Prompt Description Fault description Troubleshooting Code The monitor displays the fault code, and the buzzer sounds 3 times. Possible cause: The communication After turning on the power, the between the electronic control system communication between the monitor and the monitor is blocked.Check and the lower control line is abnormal.
Page 9: Service
Service If you have any question or problem, please contact our service email with your order number. Our Website: www.doufit.net Our Email Address: service@doufit.net Page 8...
