- Page 1 Compass Cabinet TV Mount ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE ENSEMBLAJE INSTRUCTIONS DE MONTAGE DO NOT THROW AWAY! NO LA TIRE NE PAS JETER UPDATED AS OF: 04/16/2021 1 of 7...
- Page 2 Parts List Hardware P1 - Crossbrace A - CS M6 x 12mm B - PH M6 x 40mm P2 - Left Insert C - PH M6 x 12mm P3 - Right Insert D - Washer P4 - Upright E - M6 Lock Nut P5 - Mount Frame F - M6 x 95mm P6 - Mount Bracket...
- Page 3 WARNINGS AND DISCLAIMERS ADVERTENCIAS Y RENUNCIAS AVERTISSEMENTS Review full assembly instructions and Previo a comenzar el proceso de Avant de commencer l’ assamblage check that all parts are present before ensamblaje favor revisar veuillez consulter instructions beginning assembly. Heavy or large instrucciones y asegurarse que cuenta con complètes et vérifier si vous avez toutes furniture may require multiple persons in...
- Page 4 Insert Uprights into cut outs in Crossbrace. Insert screws through bottom of Crossbrace STEP 1 to secure Uprights in position. Ensure holes in Uprights are facing direction shown. Remove casting retainer screws from interior of cabinet. Set screws aside. Slide in STEP 2 Mount Inserts through slots in castings making sure that Inserts are oriented correctly with holes closer to back of cabinet.
- Page 5 Position Crossbrace with Uprights in between Mount Inserts and line up holes. Secure STEP 3 with screws (B) and washers and cap with lock nut. Inserts should be level with Crossbrace after tightening. Replace all casting retainer screws STEP 4 removed in Step 2.
- Page 6 Attach Mount Frame to Uprights at desired height with washers and screws (C). See chart STEP 5 for panel display size & weight limits at high and low settings for both cabinet sizes (2 wide with highest setting shown). Max Size 2 WIDE (Diagonal) Weight...
- Page 7 Hang Flat Panel on TV Mount by first hooking top of brackets to Mount Frame. Secure STEP 7 in place by inserting screws (D) through holes on brackets and tightening into Mount Frame until snug. THIS COMPLETES ASSEMBLY INSTRUCTION UPDATED AS OF: 04/16/2021 7 of 7...
