Dunraven APOLLO ultrasonic Quick Start Manual page 2

APOLLO ULTRASONIC RECEIVER MULTI SWITCH SETTING CHART
Measure the vertical height of the tank from the transmitter position on top of the tank to the bottom of the tank.
Read to the nearest measurement on the chart.
Height of
tank in mm.
500
550
600
650
700
750
800
850
900
950
1000
1050
1100
1150
1200
1250
1300
1350
1400
1450
1500
1550
1600
1650
1700
Battery removal
Remove the transmitter unit from the tank and
take it to a safe location.
The battery can be accessed by removing 2
self-tapping screws from the base of the unit.
See sketch.
Remove the old battery noting the orientation
('+' mark facing outwards), and replace with a
new battery. 3V-CR2430.
Re-assemble, ensuring
undamaged and secured in position.
Re-locate the transmitter on the tank.
No Need to Rematch
Specifications
Tank Depth measurement:
Minimum depth: 0.1 m, Maximum depth: 3 m
Max communication distance:
200m in normal 'line of sight' conditions
Power Supply:
Receiver: 150-250V, 50-60Hz, Meets EN60335
Transmitter: 3-volt lithium cell
Battery life:
10 years (estimated life)
Wireless communications:
433 mHz.FM transmission, EN 300-220
Max and Min Operation Temp (Transmitter):
Operating temperature range -10° - +60°C.
Not Suitable for pressurised containers. Use on tanks vented to Atmosphere.
Warranty
This unit carries a 1 year warranty when used under normal
operating scenarios. NOTE: warranty is void if transmitter seal is
broken
The contents and images in this guide are subject to
copyright and are not to be reproduced without the
permission of Dunraven Systems Limited
© Dunraven Systems Limited
Switch 1 on/up to enable the low level audible warning
Set Switches On
1
1,7
1,6,8
1,6,7,8
1,5,7
1,5,6
1,5,6,7,8
1,4,8
1,4,6
1,4,6,7
1,4,5,8
1,4,5,7,8
1,4,5,6,7
1,3
1,3,7,8
1,3,6,8
1,3,5
1,3,5,7
1,3,5,6,8
1,3,5,6,7,8
1,3,4,7
1,3,4,6
1,3,4,6,7,8
1,3,4,5,8
1,3,4,5,6
the O-Ring is
Height of
Set Switches On
tank in mm.
1750
1800
1850
1900
1950
2000
2050
2100
2150
2200
2250
2300
2350
2400
2450
2500
2550
2600
2650
2700
2750
2800
2850
2900
3000
For additional information or to view installation videos please visit
our website www.dunravensystems.com
For Support or assistance please email
support@dunravensystems.com
Telephone: 00353 (0) 42 9386505
