NovaTec NV BLINDS eclectics Instructions

Your blind will be supplied with universal wall (face) or bottom fix brackets.
1. Components
2 x Pulley guides
(and screws capable
of being top or wall
fixed)
top fix
wall
fix
2. Fixing the Headbox.
Face or Bottom Fix.
Universal Brackets are supplied.
Place the brackets on the cill or the wall, positioning them 50mm from
either end of the recess or the end of the cassette. On blinds over
90cm you will be provided with an extra bracket for every 80cm of
width, these are to be spaced and fitted equally across the width of
the blind.
Pencil through the fixing holes, drill and screw. Place the front of the
headbox into the bracket and snap the blind back into position.
3. Fixing the pulley guides and cleat hook
a) The 2 pulley guides supplied can be fixed inside the recess
(to the ceiling) or outside the recess (to the wall) depending
on how you fixed your headbox - see opposite.
Please ensure that when attaching pulleys they align with the
knot holders on the reverse of the blind. This will prevent the
blind rolling up unevenly.
b) Drill and screw the pulley guides at 50mm in from the ends
of the cassette to the first hole of the pulley guide.
c) Installing the supplied cleat reduces the the hazards of
strangulation and entanglement of young children by limiting
access to the control cord. Fix the cleat on the pull cord side at
a minimum of 1.5m off the floor either inside or outside the
recess. Please ensure that suitable fixings are used so the cleat
cannot become detached.
Bottom-up Roller Blind Fitting Instructions
Universal Brackets
cleat (plus screw
Young children can be strangled by loops in pull cords, chains, tapes and inner
cords that operate the product. To avoid strangulation and entanglement, keep cords
out of the reach of young children. Cords may become wrapped around a child's neck.
Move beds, cots and furniture away from window covering cords. Do not tie cords
together. Make sure cords do not twist and create a loop.
s)
max. 50mm
inside recess fixing
PLEASE SEE OVER FOR FURTHER FITTING INSTRUCTIONS
pull cord
knotholder detail
on reverse of blind
max. 800 mm
outside recess fixing
max. 50mm
cleat
