Overview

DC22K Docking Station

8 7
1. Battery connector
2. Pogo-pin docking connector
3. Battery connector
4. LED indicators
1
2
3
6 5 4
5. DC-in jack
6. RS232 port
7. Ethernet(RJ-45) port
8. USB 2.0 port (5V/500mAh)
Overview

VHM16 Cradle Vehicle Dock

1 2
9 8
1. Latch bar (with key slot)
2. Latch
3. Mounting holes
4. Pogo-pin docking connector
5. Screws
10
3
4
5
7 6
6. DC-in jack
7. USB 2.0 port (5V/500mAh)
8. Ethernet(RJ-45) port
9. RS232 port
10. Key for the key slot
Illustrations are for reference only. Actual product specifications may vary.
