Denon AVR-2307CI Specifications

A/V Surround Receiver
AVR-2307CI
Custom Integrated Multi Source/Multi Zone 7.1 A/V Surround Receiver
features HDMI repeater/conversion, XM-HD Surround and iPod
Command and Control Capability.
Audio section
Fully discrete 7-channel high power amplifiers
Front 100 W + 100 W
Center 100 W
Surround 100 W + 100 W
Surround Back 100 W + 100 W
High-quality sound reproduction
• New high resolution 32bit floating point DSP
• 96 kHz processing circuit
• 24 bit, 192 kHz capability high resolution D/A conversion
Denon's basic design for high-quality sound reproduction
• Power transformer for high power driven
• Twin drive rectifier
• Large aluminum extruded heatsink
Wide-Range Play Capability for DVD-Audio and Super Audio CD
The power amp circuits of the AVR-2307CI have been meticulously designed to
reproduce the exceptionally high sound quality with wide frequency response from
10 Hz to 100 kHz.
Supports the most advanced surround playback formats
• DTS 96/24 Decoding for DVD-Video • DTS-ES Discrete 6.1 and Matrix 6.1
• DTS NEO:6 • DTS • Dolby DIgital • Dolby Digital EX • Dolby Pro Logic
Cinema Equalizer
Multi Source / Multi Zone
• 2 source 2 zone capability
• Powered Zone2 (Assignable power amp)
• Zone2 line output
• All ch Preout
Custom Integrated RS232C serial command control
• Remote in/out IR command control Discrete power on/off,
source select and vol ume for main and second zones command.
• IR off, panel lock mode Assignable +12V trigger output
Pure Direct mode, for the pure enjoyment of music in high-quality sound
(8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
(8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
(8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
(8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
Video section
HDMI In/Out terminals and repeater function ( Supports 1080p signal)
The AVR-2307CI is equipped with 2 HDMI inputs, as well as 1 output, allowing the
selection of multiple digital video signals. The HDMI terminals also accepts multi-channel
digital audio input and the input signals can be output via amps.
Video Up/Down conversion capable of output to HDMI
The AVR-2307CI includes a video up/down conversion function that allows the unit
to be connected to the video monitor via a single cable regardless of the video input
signal's format as follows:
1) Composite video signals are converted to HDMI, component video, & S-video;
2) S-video signals are converted to HDMI, component video, & composite video;
3) Component video signals are converted to HDMI
Component video circuits which maintain flat response up to 100MHz,
ensuring sharp image quality
3 sets of component video inputs
Connectivity/ Expandability
ASD-1R Control Dock for iPod
when connected to the AVR-2307CI
iPod (*1) playback can be enjoyed through the AVR-2307CI
I I x
when the ASD-1R, Denon's original Control Dock for iPod
(sold separately), is connected to the dedicated control ter-
minal of the AVR-2307CI. The iPod can also be controlled
via the remote controller supplied with the AVR-2307CI.
*1) Supports 3rd-generation and later iPods equipped with a Dock connec-
tor. Some functions may not work depending on the generation of the iPod
and the version of the software.
XM Mini-Tuner Ready*
(Supports XM 5.1ch surround powered by Neural Audio)
*Optional XM Mini-Tuner and subscribes are required.
Auto Setup and RoomEQ with Microphone
The AVR-2307CI includes an Auto Set-up function that performs basic settings
for the speakers based on frequency response data for the speakers and the
listening room that was measured by a supplied high-performance microphone,
and a Room EQ (equalizer) function that optimizes frequency response character-
istics for the listening room.
® (option): Supports iPod playback
Black version is also available.
