EZCLA User Manual
EZ CARRIER LIFT AUTOMATIC
Customer Care:
For Service at any time, go to
www.ezcarrierusa.com
Or call 888-302-2774
Monday – Friday 9 A.M. – 4 P.M. EST
To activate your 1-year manufacturer's warranty please fill out and return you warranty card or register your
product online with us at ezcarrierusa.com within 10 days of receiving your purchase.
1
Advertisement
Table of Contents
Related Manuals for EZ Carrier EZCLA
Summary of Contents for EZ Carrier EZCLA
- Page 1 EZCLA User Manual EZ CARRIER LIFT AUTOMATIC Customer Care: For Service at any time, go to www.ezcarrierusa.com Or call 888-302-2774 Monday – Friday 9 A.M. – 4 P.M. EST To activate your 1-year manufacturer’s warranty please fill out and return you warranty card or register your...
-
Page 2: Table Of Contents
Dear Customer, Thank you for your purchase of an EZ Carrier product! We truly appreciate your business and look forward to supporting you as a customer. We are highly confident you will be satisfied with your carrier no matter its application. From transporting mobility devices to outdoor recreational equipment and gear to general cargo carrying, we are sure your EZ Carrier product will meet all your needs. -
Page 3: Important Safety Warnings
IMPORTANT SAFETY WARNINGS & PRECAUTIONS IMPORTANT!: READ ALL WARNINGS AND PRECATIONS BEFORE CONTINUING • Always Inspect your carrier prior to operation, checking to confirm no parts are worn or damaged. If ANY parts are worn or damaged, DO NOT USE THE CARRIER. Failure to properly tighten bolts and insert pins where required may cause assembly failure, serious injury or death. -
Page 4: Installation
IMPORTANT!: EZ Carrier is not liable for any damages, injuries or deaths due to improper installation. Please remember to always inspect your carrier for loose bolts, pins, wear or damage prior to use. -
Page 5: Part Identifcation Chart
PART IDENTIFCATION CHART Before reading further please familiarize yourself with the parts that are labeled in the drawing below:... -
Page 6: Assembly - Class Ii Reciever Attachment
ASSEMBLY – CLASS II RECIEVER ATTACHMENT WARNING!: Failure to properly tighten bolts and insert pins where required may cause assembly failure, serious injury or death. Always check that all bolts are securely fastened and pins are locked in place before use of the product. Class II 1.) Place the collar on the 3/8 Hex Head Bolt 2.) Insert the Receiver Attachment Connector into the receiver hitch. -
Page 7: Assembly - Class Iii Reciever Attachment
ASSEMBLY – CLASS III RECIEVER ATTACHMENT WARNING!: Failure to properly tighten bolts and insert pins where required may cause assembly failure, serious injury or death. Always check that all bolts are securely fastened and pins are locked in place before use of the product. 1.) Remove the cotter pin from the Silent Hitch Pin™. -
Page 8: Assembly - Attaching Swing-Away Option
ASSEMBLY – ATTACHING SWING-AWAY OPTION WARNING!: NEVER open the Swing-Away with a load on the carrier. You will damage the Swing-Away and carrier while also potentially damaging the vehicle and the mobility device. Any of these actions will VOID your warranty. WARNING!: DO NOT open the Swing-Away on unleveled ground. -
Page 9: Assembly - Mounting The Actuator And H
ASSEMBLY – MOUNTING THE ACTUATOR AND H-FRAME IMPORTANT!: The Actuator has 18” or 24” of travel. Position the Lift Assembly as high as possible, typically the distance from the ground to the upper bolt is as follows: 18” Actuator: 24 to 26 inches or 24” Actuator: 30 to 32 inches. 1.) Align the holes on the Actuator with the holes on the Receiver Attachment (or optional Swing-Away). -
Page 10: Assembly - Attaching The Platform
2.) Rotate the crank clockwise to lower the Actuator and H-Frame to approximately 6 inches above the ground. 3.) Place the Platform on top of the H-Frame so the EZ Carrier stickers face away from the vehicle. 4.) Align the four square holes in the Platform with the holes in the H-Frame. -
Page 11: Assembly - Connecting The Wire Harness
ASSEMBLY – CONNECTING THE WIRE HARNESS WARNING!: Failure to have a fuse between the battery and Powerhead may result in damage to the Powerhead. You must have a 30-amp inline fuse (INCLUDED) between the battery and the Powerhead or damage to the Powerhead will not be covered under the warranty. -
Page 12: Assembly - Attaching The Cargo Buckle
ASSEMBLY – ATTACHING THE CARGO BUCKLE 1.) Insert the 7/16-14 X 1 carriage bolt into the square hole. 2.) Place the 5/8 washer over the carriage bolt. 3.) Place the carriage bolt through the cargo buckle. 4.) Place the lock nut on the screw and firmly tighten using a 5/8 wrench or socket wrench. 5.) Confirm that the cargo buckle is securely attached. -
Page 13: Operating Your Carrier - Raising And
OPERATING YOUR CARRIER – RAISING AND LOWERING THE PLATFORM AND FOLDING INTO THE STORAGE POSITION WARNING!: The Lift Arm will release from the “V” bracket when the platform is lowered. When raising the platform to fold and store, guide the Lift Arm into the “V” bracket using the rubber handle. When operating your carrier be sure to stay clear of moving parts and pinching points to avoid personal injury. -
Page 14: Faqs
FAQS How do I clean and maintain my carrier to get the longest life and best performance? Prior to each use, inspect the carrier for any wear or damage – immediately address any concerns as wear or damage to the carrier can cause property damage or severe personal injury. Routinely hand wash your carrier with water to remove salt, dirt and other road debris to prolong the life of your carrier. -
Page 15: Notes
NOTES __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ ________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________... -
Page 16: Return And Cancellation Policy
RETURN AND CANCELLATION POLICY Return Policy In an effort to keep our prices as low as possible, we do not build extra fees for returns into our prices. We are happy to accommodate customers who wish to return a product, however we must recover the costs we have incurred as a result. -
Page 17: Limited Warranty
5. Any part replaced under the warranty will be covered for the remaining period of the Warranty Period. 6. Any parts replaced under the warranty must be returned to EZ Carrier, LLC and will become the property of EZ Carrier, LLC. EZ Carrier, LLC may, at its discretion make any repairs or replacement of defective parts but such... - Page 18 7. EZ Carrier will bear labor charges for work carried out under the warranty. The warranty may not be transferred to subsequent owners for the balance of the remaining Warranty Period. Buyer has no right to return for repair, replacement, credit, or refund any goods except as set forth in this Section. In no event shall Buyer reconstruct, repair, alter, or replace any goods, in whole or in part, either itself or by or through any third party.
-
Page 19: Liability Disclaimer
The purchaser of the carrier is solely responsible for the installation, use, and the securing of any item being carried. In no event shall EZ Carrier, LLC be liable for any damages whatsoever, including but not limited to any direct, indirect,...
