U LT I M AT E 2 0 L
G R E E N PA N T H E R
L AW N M O W E R
User Manual
Fuel Efficient
To cover large area
Multi-Purpose Professional
196cc Powerful Engine
in less time
Lawn Mower
Note: Please read the following instructions before use. This book contains important information on SAFETY, ASSEMBLY, OPERATION
& DISCLAIMER: DUE TO CONSTANT UPGRADATION, FEATURES AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
Advertisement
Table of Contents
Related Manuals for Green Panther Ultimate 20 L
Summary of Contents for Green Panther Ultimate 20 L
- Page 1 U LT I M AT E 2 0 L G R E E N PA N T H E R L AW N M O W E R User Manual Fuel Efficient To cover large area Multi-Purpose Professional 196cc Powerful Engine in less time Lawn Mower Note: Please read the following instructions before use.
-
Page 2: Manual Contents
Useful Mulch Mowing tips Spare parts Free Service coupon Warranty Card Do’s & Dont’s CARTON CONTENTS Quantity Green Panther ULTIMATE 20 L Lawn Mower User manual Engine manual Grass catcher assembly FREE ACCESSORIES Spare Blade (4 Blades) 1Set Safety Articles... -
Page 3: Technical Specification
Congratulations on your purchase of Green Panther ULTIMATE 20 L Lawn Mower. This manual covers the setting up, operation and maintenance of the Green Panther ULTIMATE 20 L Lawn Mower. Please read and understand this owner’s manual before using the mower. If any point is unclear, contact The manufacturer or agent. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS • Never mow while barefoot or wearing open sandals. Wear long trousers and heavy shoes • Know your controls. Read the owner’s manual carefully. Learn how to stop the engine quickly in any emergency • Make sure the lawn is clear of sticks, stones, bones, wire and debris. They could be thrown by the blade •... - Page 5 • Do not over-speed the engine or alter governor settings. Excessive speed is dangerous and shortens the mower life. • It is advisable to wear suitable eye protection when operating a mower. • Turn the fuel off at the conclusion of mowing and reduce the throttle setting during engine run-out.
-
Page 6: Engine Oil
ENGINE OIL • The 4 stroke engine fitted to the lawnmower is shipped with no oil in the sump • Oil must be added before attempting to start the engine otherwise damage to the engine will occur. ENGINE FUEL • Use only fresh unleaded fuel in the lawnmower engine Adjusting the Cutting Height OPERATION -Mulch Mowers Installing the Mulch Plug... -
Page 7: To Start The Engine
Mulch plug installation (A) - Push Mower Mulch plug installation (B) - Push Mower REMOVING THE MULCH PLUG • With the engine stopped, raise the rear flap of the mower. • Grasp the rear of the mulch plug and lift up and away from the mower. •... -
Page 8: Engine Air Cleaner
MAINTENANCE Warning Before carrying out any maintenance on the mower remove the spark plug lead from the spark plug to prevent accidental starting Engine air cleaner Refer to the engine owner’s manual for detailed maintenance instructions. The engine air cleaner elements must be serviced after every 25 hours of normal mowing. -
Page 9: Cutting Assembly
Cutting Assembly • With the engine stopped, remove the spark plug lead and grass catcher or mulch plug. • Set the height of cut lever to the high cut position, and fold the handle bars. • Tilt the mower so the spark plug is up. •... -
Page 10: Benefits For You
BENEFITS FOR YOU Because you mulch as you mow the time and cost savings are also significant: • Eliminating raking of leaves before mowing (Mulch mowing picks up and converts fallen leaves into mulch). • Eliminating raking of cut grass. •... - Page 11 USEFUL MULCH MOWING TIPS Mulch mowing is an art form and to produce the best results consistently, follow these useful hints: • Do not attempt to mulch if the grass is too wet. Wet grass tends to clump together and does not evenly spread out. It also clogs up the underside of the base.
- Page 12 Green Panther Lawn Mower ULTIMATE 20 L - Spare Parts Diagram...
- Page 14 GREEN PANTHER LAWN MOWER ULTIMATE 20 L SPARE PARTS LIST PART NO. PART NO. Description GP-LM-U20-72 4210630 FRONT AXLE WELDING GP-LM-U20-01 4062370 BACK COVER GP-LM-U20-73 4151110 LEFT ANTERIOR AXIS PLATE GP-LM-U20-02 7020606 WING NUT M6 GP-LM-U20-74 6070360 ANTERIOR LABEL GP-LM-U20-03...
- Page 15 Small Maintenance. Big Savings. Small Maintenance. Big Savings. Small Maintenance. Big Savings.
- Page 16 1st Free Service Coupon ISO 9001-2015 CERTIFIED COMPANY FREE SERVICE COUPON (30 Days / 20 hrs (Which ever is earlier) Model Serial Number ULTIMATE 20 L LAWN MOWER PDI Date Service No. Purchase bill no. Date Dealer’s Office Seal & Signature Customer Signature.........
- Page 17 1. LIMITED WARRANTY PERIOD : For a period of six months from the date of Sale / delivery of the product which ever is earlier. 2. LIMITED WARRANTY OBLIGATION : Replacement of defective part(s) by authorized dealer are free of charges. If found defective by reasons of defective material / poor workmanship, parts will be replaced and there will be no value re-imbursement.
- Page 18 Warranty Card CUSTOMER COPY Purchaser’s Name & Address Date of Delivery Dealer’s Office Seal Product Name ULTIMATE 20 L LAWN MOWER Product Serial No. Dealer Sign Customer Sign. Invoice / DN No. I/We accept the terms and conditions of Warranty as in the Warranty Card.
- Page 19 Do’s Don’ts • Always read the instruction manual supplied along with the equipments and understand the correct installation and operating procedures before attempting to use the equipments. • It is important to use the personal protection equipments such as head helmet with visor, ear defenders, goggles, safety gloves, cut resistant shoes, trousers and jackets while operating potentially dangerous machines.
- Page 20 Mowing Patterns Your ULTIMATE 20 L Green Panther Lawn Mower mower will work most efficiently if you use the following mow- ing patterns as much as possible. Cutter housing, equipment design and the direction in which the blades rotate, cause these mowing patterns to give the best results.
