Delphi SA10003 Installation Manual
Delphi SA10003 Installation Manual

Delphi SA10003 Installation Manual

Universal fm modulator

Advertisement

Quick Links

SKYFi Universal Adaptor
FM Modulator
DELPHI SA 10003
MADE IN MALAYSIA
Frequency switch
SKYFi Car Cradle
XM Antenna
To vehicle
AM/FM
antenna
R a d i o t o t h e p o w e r o f X
To ground
To vehicle
audio/stereo
-
(black)
88.1MHZ
87.9MHZ
88.5MHZ
+
To vehicle
(red)
12V power
(female)
terminal
+
(male) (red)
Audio In
6V DC In
Connecting Delphi XM SKYFi
to Your Vehicle With an FM
Modulator
Note: Connect FM modulator ground
terminal to vehicle ground before making any
other connections.
Connect the red (+) lead to the vehicle
12V power terminal, which is powered
when the ignition is in the accessory
position.
The 12V power connecting cord is
permanently connected for SKYFi
modulation.
