Delphi Roady SA10069 Installation Manual

8816DM Roady Card Keys 6/25/04 8:06 AM Page 1
XM Satellite Radio Accessory Products Limited Consumer Warranty
Delphi Product and Service Solutions ("Delphi") warrants all Portable XM Satellite Radio Accessory Products sold by Delphi ("Products") to be free of
defects in material and workmanship, subject to the following conditions: The duration of Delphi's warranty with respect to Delphi Portable XM
Satellite Radio Accessory Products is limited to one (1) year from the date of sale to the original consumer purchaser. No other express warranties are
made with respect to any Product. All implied warranties, including warranties of merchantability and fitness for a particular purpose are limited to
the warranty period set forth above. This warranty is not transferable and applies only to the original consumer purchaser of the Product. Delphi will, as
its sole obligation under this warranty, replace or repair, at its option, any Product that does not conform to this warranty. Products may be repaired or
replaced with new or with refurbished items. This limited warranty does not cover defects in appearance, cosmetic, or decorative items, including any
non-operative parts. Under no circumstances will Delphi be liable for any incidental or consequential damages under this warranty or any implied
warranties. These remedies are the customer's exclusive remedies for breach of warranty. This limited warranty only extends to customers who purchase
the Products in the United States. Delphi will not be responsible for damage resulting from any (i) deviation from Delphi's operating instructions as
printed in Delphi's catalog or on any packaging, labels, or other literature provided with a Product, (ii) installation of a Product in a manner which is
inconsistent with Delphi's written instructions, (iii) alteration or modification of a Product, (iv) misuse, (v) neglect, (vi) abuse, (vii) accident, (viii) normal
wear and tear, (ix) commercial use, (x) improper storage, (xi) environmental conditions, including excessive temperature or humidity, (xii) service by
anyone other than a Delphi authorized repair facility, (xiii) other improper application, installation or operation of the Product, or (xiv) defects or
malfunctions of which Delphi is not advised within ten (10) days of the expiration of the limited warranty period. How you (the Customer) can get
service: To obtain warranty service, you must return the defective Product with the original receipt to the original place of purchase. If further clarification
or additional information is required from Delphi, you may call Delphi at: 1.877.GO DELPHI (1.877.463.3574). If warranty service is needed at any time
during the warranty period, the purchaser will be required to furnish a sales receipt/proof of purchase indicating the date of purchase, amount paid,
and place of purchase. Customers who fail to provide such proof of purchase will be charged for the repair/replacement of any Product. How state
law relates to the warranty: Some states do not allow limitations on how long implied warranties last, or the exclusion or the limitation of incidental
or consequential damages. So the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights. You may also
have other rights that may vary from state to state. NO PERSON IS AUTHORIZED BY DELPHI TO MODIFY OR ADD TO THIS LIMITED WARRANTY.
Delphi Corporation The Roady name, Roady2 name, XM name, and related
logos are trademarks of XM Satellite Radio Inc.
1441 West Long Lake Road • Troy, Michigan 48098-5090 U.S.A.
Customer Service: [1] 877.GO DELPHI
Printed on Recycled Paper
©2004 Delphi Corporation. All rights reserved.
www.delphi.com
DPSS-04-E-043
Roady Home Kit
Installation Guide
For Use With Roady ™ and Roady2 ™ Satellite Radio Receivers
Warning: This guide and the user
guide that came with your Roady or Roady2
contain important safety and operating
information. Please read and follow the
instructions in these manuals. Failure to do
so could result in personal injury or damage
to your unit or property.
Roady Home Kit Set-up
Your Roady Home Kit contains the following components:
Caution: Connect only
appropriate input devices to
the unit's jacks. Connecting an
incorrect input device may
damage the system and/or any
external electronic device. It is
recommended that you use
XM ® High-gain only the A/C power adaptor
Roady Home Stand
Home Antenna that came with your Roady
Home Kit. If you need to use a
different adaptor, it must be a
6V, 100mA DC adaptor and
must contain a unified polarity
type jack, identified by the
symbol.
6V A/C power adaptor Remote Audio cable
control
Figure 1. Roady Home Kit components.
Set up your Roady Home Kit as follows:
1. Connect the XM Home Antenna to
the jack labeled .
2. Connect the power adaptor to the
connector labeled "6V."
3. Connect the ministereo (black
connector) end of the audio cable
to the jack labeled . Connect the
red and white connectors to the
input jacks of your audio equipment.
Or, connect a set of powered speakers
directly to your unit by plugging the
speakers' cables directly into the
jack.
Figure 2. Connect components to your unit as shown.
