Summary of Contents for Wickes CID18W2
- Page 1 CORDLESS IMPACT DRIVER 18V LITHIUM CID18W2 223728...
-
Page 2: Table Of Contents
CONTENTS GENERAL POWER TOOL SAFETY WARNINGS GENERAL SAFETY WARNINGS FOR BATTERY CHARGER COMPONENT LIST ACCESSORIES SYMBOLS TECHNICAL DATA NOISE INFORMATION OPERATING INSTRUCTIONS TROUBLESHOOTING MAINTENANCE ENVIRONMENTAL PROTECTION DECLARATION OF CONFORMITY... -
Page 3: General Power Tool Safety Warnings
ORIGINAL INSTRUCTION GENERAL POWER TOOL SAFETY WARNINGS protected supply. Use of an RCD reduces the risk of WARNING! Read all safety warnings, electric shock. instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/ 3. - Page 4 GENERAL POWER TOOL SAFETY WARNINGS repaired. b) Use power tools only with specifically designated battery packs. Use of any other battery packs may c) Disconnect the plug from the power source and/ create a risk of injury and fire. or remove the battery pack, if detachable, from the power tool before making any adjustments, c) When battery pack is not in use, keep it away from changing accessories, or storing power tools.
- Page 5 SAFETY WARNINGS FOR BATTERY PACK a) Do not dismantle, open or shred cells or battery pack. b) Do not short-circuit a battery pack. Do not store battery packs haphazardly in a box or drawer where they may short-circuit each other or be short-circuited by conductive materials. When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another.
-
Page 6: General Safety Warnings For Battery Charger
GENERAL SAFETY WARNINGS FOR BATTERY CHARGER WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. -
Page 7: Component List
COMPONENT LIST Collet locking sleeve Battery pack release button Forward/reverse rotating control Belt clip On/off switch Battery pack Soft grip handle Charger LED light ACCESSORIES Charger (ACG118W) 1.5Ah Li-ion battery pack (ABP1815HW) Belt clip We recommend that you purchase your accessories from the same store that sold you the tool. Refer to the accessory packaging for further details. -
Page 8: Symbols
SYMBOLS Li-ion battery. This product has been marked To reduce the risk of injury, read all of this with a symbol relating to ‘separate collection’ instruction manual for all battery packs and battery pack. It Li-Ion will then be recycled or dismantled in order Warning to reduce the impact on the environment. -
Page 9: Technical Data
TECHNICAL DATA Voltage No load speed 0-2500 /min Impact rate 0-3000bpm Max torque 180N.m chuck size 1/4” Charger Protection class Charging time 1 hr Charger Input 220-240V~50/60Hz,37W Charger Output 20VDC 1.5 A Machine weight 1.61 Kg Battery capacity 1.5Ah Li-ion battery For additional battery technical data, refer to the rating plate on the battery pack. - Page 10 VIBRATION INFORMATION Vibration total values (triax vector sum) determined according to EN 62841: Vibration emission value: = 9.474 m/s Uncertainty K = 1.5 m/s² The declared vibration total value and the declared noise emission value have been measured in accordance with a standard test method and may be used for comparing one tool with another.
-
Page 11: Operating Instructions
OPERATING INSTRUCTIONS NOTE: Before using the tool, read the instruction book carefully. Intended Use The power tool is intended for driving in and loosening screws BEFORE PUTTING INTO OPERATION A) CHARGING THE BATTERY a) Do not use any charger other than that specifically provided for use with the equipment. b) If the battery pack is very hot you must remove your battery pack from the charger and allow time for the battery to cool down before recharging. - Page 12 D) HOW TO CHARGE YOUR BATTERY PACK (See Fig. A3) CHARGING PROCEDURE 1) Plug the charger into an appropriate outlet. The light will be green. 2) Slide the battery pack into the charger, the light will turn to red to indicate the charging process has started. 3) When charging is completed, the light will turn to green.
- Page 13 3. ON/OFF SWITCH (See Fig. C) Depress to start and release to stop your driver. The On/ Off Switch is fitted with a brake function which stops your chuck immediately when you quickly release the switch. It is also a variable speed switch that delivers higher speed and torque with increased trigger pressure.
- Page 14 7. DISPOSAL OF AN EXHAUSTED BATTERY PACK To preserve natural resources, please recycle or dispose of the battery pack properly. This battery pack contains Lithium batteries. Consult your local waste authority for information regarding available recycling and/or disposal options. Discharge your battery pack by operating your drill, then remove the battery pack from the drill housing and cover the battery pack connections with heavy-duty adhesive tape to prevent short circuit and energy discharge.
-
Page 15: Troubleshooting
TROUBLESHOOTING 1. WHY DOES THE DRIVER NOT TURN WHEN YOU PRESS THE SWITCH? The forward/reverse rotation control, which is on top of the trigger, is positioned in the lock function. Unlock the forward/ reverse rotation control by putting it into the required rotation position. Push the trigger and the drill will start to rotate. 2. -
Page 16: Maintenance
MAINTENANCE Remove the battery pack from the tool before carrying out any adjustment, servicing or maintenance. Your tool requires no additional lubrication or maintenance. There are no user serviceable parts in your power tool. Never use water or chemical cleaners to clean your power tool. Wipe clean with a dry cloth. -
Page 17: Declaration Of Conformity
DECLARATION OF CONFORMITY Wickes Building Supplies Limited Declare that this product: CORDLESS IMPACT DRIVER Description and SKU code: 223728 Complies with the following Directives and Regulations: 2006/42/EC, Machinery Directive 2014/30/EU, Electromagnetic Compatibility Directive 2011/65/EU & (EU)2015/863 (RoHS),Restriction of Hazardous Substances Directive... - Page 20 Customer Helpline 0345 2005409...
