Made in Malaysia
(Buatan Malaysia)
Thank you for purchasing BERJAYA product. Please read this
service manual carefully before operating the product.
Please keep this manual in a safe place for future reference.
(Terima kasih kerana membeli produk BERJAYA. Sila baca
manual penyelenggaraan dengan teliti sebelum menggunakan
produk ini. Simpankan panduan operasi ini dengan selamat
untuk rujukan masa depan.)
(SM - Refrigerated Barline / REV 02 / 2019 / 02)
Service Manual
(Manual Penyelenggaraan)
Refrigerated Barline
(Peti Sejuk Barline)
Contents (Kandungan) : -
- Installation (Pemasangan)
- Safety Precautions And Warnings (Langkah-Langkah
Keselamatan Dan Amaran)
- Important Warnings (Amaran Penting)
- Explosive Drawings (Gambarajah Terperinci)
- Components Lists (Senarai Komponen)
- Circuit Diagram (Rajah Litar)
- Maintenance (Penyelenggaraan)
- Before Calling For Service (Sebelum Memanggil
Perkhidmatan)
- Memo (Memo)
2
3
3
5
6
7
7
8
9
Advertisement
Related Manuals for BERJAYA 660 Series
Summary of Contents for BERJAYA 660 Series
- Page 1 - Safety Precautions And Warnings (Langkah-Langkah Keselamatan Dan Amaran) - Important Warnings (Amaran Penting) Thank you for purchasing BERJAYA product. Please read this - Explosive Drawings (Gambarajah Terperinci) service manual carefully before operating the product. - Components Lists (Senarai Komponen) Please keep this manual in a safe place for future reference.
- Page 2 INSTALLATION (PEMASANGAN) 1- Select a good location. Place your refrigerator where it is easy to use. Do not tilt more than 45° during transportation. (Letakkan peti sejuk di tempat yang sesuai di mana ia mudah digunakan. Jangan dicondongkan melebihi 45 darjah semasa alat ini diangkutkan.) 2- Avoid placing the unit near heat sources, direct sunlight or moisture.
- Page 3 CLEANING (PEMBERSIHAN) - It is important that your refrigerator be kept clean to prevent undesirable odors. Spilled food should be wiped off immediately, since acidity can stain plastic surface. Never use metallic scouring pads, brushes, coarse abrasive cleaners of strong alkaline solutions on any surface. (Adalah amat penting untuk memastikan peti sejuk berada dalam keadaan yang bersih supaya ia tidak berbau.
- Page 4 Power Cord Replacement If the supply cord is damaged, it must be replaced by a special cord or assembly from the manufacturer or its service agent. (Mengantikan wayar kuasa elektrik) (Jika palam atau wayar peti penyejuk rosak, ia hendaklah digantikan dengan alatan yang dibekalkan oleh pengilang atau ejen perkhidmatannya.) About Grounding (Earthing) In the event of an electric short circuit, grounding (earthing) reduces the risk of electric shock by providing an escape...
- Page 5 Durable Days (Sebelum Tarikh Luput) Milk (Susu) 2 - 6˚C (36˚F - 43˚F) Durable Days (Sebelum Tarikh Luput) EXPLOSIVE DRAWING (SENARAI KOMPONEN) Refrigerated Barline (Peti Sejuk Barline) COMPONENT LIST (SENARAI KOMPONEN) 660 Series Model (Model) B2D/C5/600-SM B2D/C6/600-SM B3D/C7/600-SM B3D/C8/600-SM Parts (Bahagian)
- Page 6 760 Series Model (Model) B2D/C5/7-SM B2D/C6/7-SM B3D/C7/7-SM B4D/C8/7-SM Parts (Bahagian) Compressor (Pemampat) (1/4HP) (1/4HP) (1/3HP) (2/5HP) Condenser (Kondenser) CD-033-3 CD-033-3 CD-050-3 CD-060-3 Cooling Coil (Lingkaran Penyejukan) CC-16-C5/6 CC-16-C5/6 CC-16C-2 CC-16C-2 A/C Fan (Kipas A/C) FE-F6-ROHS FE-F6-ROHS FE-F6-ROHS FE-F6-ROHS Fan Motor (Motor Kipas) FE-VDE10W FE-VDE10W FE-VDE10W...
- Page 7 5- After the compressor operates 6 hours, defrost will take place, the light on, the compressor stops running. But the blower fan is still continuously run. (Setelah pemampat berfungsi selama 6 jam, proses nyah salji akan dijalankan. Lampu menyala dan pemampat akan berhenti berfungsi.
- Page 8 Unused For A Long Period (Unit Tidak Digunakan Untuk Jangkamasa Lama) a- Empty all goods and disconnect power. a- Semua barang hendaklah dikeluarkan dan tangalkan palam. b- Keep door open to avoid mould and stinking. b- Biarkan semua pintu-pintu terbuka supaya kulat tidak bertumbuh dan kebuk berbau busuk. BEFORE CALLING FOR SERVICE (SEBELUM MEMANGGIL PERKHIDMATAN) Service calls can often be avoided! If you feel your refrigerator is not operating properly, check these possible causes first : - (Panggilan untuk perkhidmatan kerapkali dapat dielakkan!)
- Page 9 MEMO (MEMO) Please fill in the following at the purchasing time for future service reference. (Sila isikan jadual yang berikut untuk rujukan perkhidmatan lepas jualan.) Model Number (Nombor Model) : Purchasing Date (Tarikh Pembelian) : Dealer's Name (Nama Pengedar) : Address (Alamat) : Home (Rumah) : Contact Number (Nombor Telefon) :...
