- Page 1 Hardened 5-Port 10/100M DIN-Rail Mount Switch ETM-IES-05-U1-A User's Manual (V1.0 Version)
-
Page 2: Package Checklist
ETM-IES-05-U1-A supports 4 ports 10/100BaseT/TX, Full/Half duplex mode, and auto MDI/MDI-X connection. The ETM-IES-05-U1-A has a wide operating temperature range of -40 to 185°C (-40 to 85°C), and are designed to withstand a high degree of vibration and shock. The rugged hardware design makes either model perfect for ensuring that your Ethernet equipment can withstand critical industrial applications. -
Page 3: Panel Layout
Panel Layout Front Panel View 1. Terminal Block For Power 2. Shielding Ground 3. Power LED PWR1 4. Power LED PWR2 5. 10/100BaseT/TX Port-TP1 6. 10/100BaseT/TX Port-TP2 7. 10/100BaseT/TX Port-TP3 8. 10/100BaseT/TX Port-TP4 9. 10/100BaseT/TX Port- UP-LINK 10. DIN Rail Kit Top Panel View Full View... -
Page 4: Mounting Dimensions
DIN-Rail Mounting The aluminum DIN-rail attachment plate should already be fixed to the back panel of the ETM-IES-05-U1-A Switch when you take it out of the box. If you need to the D reattach N-rail attachment plate, make sure the stiff metal spring is situated towards the top, as shown in the figures below. -
Page 5: Wiring The Redundant Power Inputs
Tighten the four screws for added stability. Grounding the ETM-IES-05-U1-A switch Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). Run the ground connection from the ground screw to the grounding surface prior to connecting devices. -
Page 6: Communication Connections
RJ45 Ethernet Port Connection ETM-IES-05-U1-A switches have 5 10/100BaseT(X) Ethernet ports. 10/100BaseT/TX Ethernet Port Connection The 10/100BaseT/TX ports located on the ETM-IES-05-U1-A switch’s front panel are used to connect to Ethernet-enabled devices. Below we show pinouts for both MDI (NIC-type) ports and MDI-X (HUB/Switch-type) ports, and also show cable wiring diagrams for straight-through and cross-over Ethernet cables. -
Page 7: Led Indicators
LED Indicators The front panel of the ETM-IES-05-U1-A switch contains several LED indicators. The function of each LED is described in the table below. Color State Description Power is being supplied to power input PWR2 PWR1 GREEN Power is not being supplied to power... -
Page 8: Specifications
Specifications Parameter Specifications RJ45 Ports: 10/100BaseT/TX auto connection, Interface Full /Half duplex or force work mode, and support MDI/MDI-X connection Standard：IEEE802.3, IEEE802.3x, IEEE802.3u Forwarding and Filtrate Rate: 148810pps Technology Transmit type: Store and Forward switching process type Support 1K MAC Address Input Voltage: 12VDC~58VDC, Power Overload Current Protection...
