24V Li-Ion Battery and Battery Charger
Model No. 88503—Serial No. 319000001 and Up
Model No. 88506—Serial No. 319000001 and Up
You may contact Toro directly at www.Toro.com for
product and accessory information, help finding a
dealer, the complete warranty details, or to register
your product.
WARNING
CALIFORNIA
Proposition 65 Warning
The power cord on this product contains
lead, a chemical known to the State
of California to cause birth defects
or other reproductive harm. Wash
hands after handling.
Safety
Important safety instructions—Save these
instructions.
DANGER
To reduce the risk of fire or electric shock,
carefully follow these instructions:
• Be sure voltage selector is in correct
voltage position before plugging in.
• For use in the U.S.A., the voltage selector
switch must be placed in the 120 volt
position. For use in countries other than
the U.S.A., the voltage selector may need
to be placed in other than the 120 volt
position. Confirm the voltage available at
each country location before using the
product.
• For connection to a supply not in the
U.S.A., use an attachment plug adapter
of the proper configuration for the power
outlet, if needed.
© 2018—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
The battery used in this device may present a
risk of fire or chemical burn if mistreated.
Do not disassemble, heat above 104 degrees
F (40 degrees C), or incinerate. Replace
battery with Toro genuine batteries only. Use
of another battery may present a risk of fire
or explosion.
Dispose of a used battery promptly. Keep
away from children. Do not disassemble and
do not dispose of in fire.
Overheating batteries can cause fire and
severe burns.
Do not open, crush, heat above 104 degrees
F (40 degrees C), or incinerate. Follow the
manufacturer's instructions.
This power unit is intended to be correctly orientated
in a vertical or floor mounted position.
Register at www.Toro.com.
CAUTION
CAUTION
CAUTION
Original Instructions (EN)
All Rights Reserved *3424-967* B
Printed in China
Form No. 3424-967 Rev B
Operator's Manual
Advertisement
Related Manuals for Toro 88503
Summary of Contents for Toro 88503
- Page 1 Form No. 3424-967 Rev B 24V Li-Ion Battery and Battery Charger Model No. 88503—Serial No. 319000001 and Up Model No. 88506—Serial No. 319000001 and Up Operator's Manual You may contact Toro directly at www.Toro.com for CAUTION product and accessory information, help finding a...
-
Page 2: Safety And Instructional Decals
Safety and Instructional Decals Safety decals and instructions are easily visible to the operator and are located near any area of potential danger. Replace any decal that is damaged or missing. decal121-7692 121–7692 decal121-7606 121–7606 decal138-6668 138-6668 decal125-3226 125–3226... -
Page 3: Charging The Battery Pack
Charging the Battery Pack Refer to the table below to interpret the LED indicators on the battery charger. Turn the battery upside down and line up the LED COLOR battery terminal with the slot in the charger (Figure 1 Figure Left Right Indicates:... -
Page 4: Battery Pack Preparation For Recycling
Battery Pack Preparation For Recycling WARNING Upon removal, cover the battery packs terminals with heavy-duty adhesive tape. Do not attempt to destroy or disassemble the battery pack or remove any of its components. Lithium-ion batteries must be recycled or disposed of properly at the nearest battery recycling facility. -
Page 5: Troubleshooting
Troubleshooting Using the battery when it is hot can reduce the operating time. The battery will automatically stop working when it is overheated to prevent damage to it. Remove the battery from the charger and allow it to cool before placing it back into the trimmer. - Page 6 Notes:...
- Page 7 While the exposure from Toro products may be negligible or well within the “no significant risk” range, out of an abundance of caution, Toro has elected to provide the Prop 65 warnings. Moreover, if Toro does not provide these warnings, it could be sued by the State of California or by private parties seeking to enforce Prop 65 and subject to substantial penalties.
