Summary of Contents for Bush WCDZ46
- Page 6 WARNING: This appliance is intended to be used in household and domestic applications only. WARNING: This product is not suitable for food storage and must not be used to store food inside.
- Page 7 Do not use the appliance for industrial and commercial use, or any other purpose. The appliance is design for indoor use only and must be protected from rain, moisture and extreme temperature variations. This appliance is not intended for outdoor use. If the socket and refrigerator plug are not compatible please contact after sales service provider.
- Page 8 It is recommended that you remove all the internal and external packaging and clean the interior of the appliance prior to first use. We recommend you wipe all parts with warm water then rise and dry. Place all parts back into the appliance after cleaning. Cleaning and user maintenance shall not be made by children without supervision.
-
Page 11: Accessories Included
1.Cabinet 4.Levelling feet 2.Touch control panel 5.Glass door 3.Wine shelves 6.Lower door hinge Accessories included Handle x 1 Screws x 2 Full instructions on how to fix the handle can be found on Page 13 of this manual... -
Page 13: Installing The Stainless Steel Handle
Installing the stainless steel handle To install the handle, follow the instructions below: 1. Peel back door seal along the right hand side of door. You will find a screw hole at the top and lower of the door where you have peeled the seal back. -
Page 14: Levelling Feet
Levelling feet The appliance must be installed level in order to work properly. If the unit is not level, the doors and magnetic seal alignments will not be covered properly. To level the unit, adjust one or both levelling feet at the base of the unit. Adjustable feet This appliance comes with height adjustable feet which allows the appliance to be installed under bench and ensures the appliance is stable and level. - Page 15 When positioning the appliance, ensure the supply cord is not trapped or damaged. Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
- Page 17 Before use Final checks before operating the appliance 1. Make sure there is sufficient space for air circulation around the appliance .(Please see page 13 of Instruction Manual titled ‘Installation requirements’ for this information). 2. The feet have been adjusted for perfect leveling. 3.
-
Page 18: Door Alarm
Defrosting The wine cooler is designed to defrost automatically every 4 hours. The defrost process will last for 20 minutes. During defrost, the compressor stops working and fan keeps on running for 20 minutes. Door alarm The wine cooler is equipped with an alarm that will sound if the door is left open for more than 60 seconds. Close door or press any key once to switch off... - Page 20 Do not use hard brushes, steel wool, wire brushes, abrasives, or solvents like, alcohol or acetone, boiling water, acids or alkaline to clean this appliance, as it may damage or deform the surface or interior. Light bulb replacement The internal light is a LED type. To replace the lamp, please speak to after sales service provider. Power Failure If the power failure lasts for up to 24 hours, keep the door closed.
- Page 21 Model WCDZ46 Fridge capacity 128L Bottles capacity 46 bottles Voltage and frequency 220-240V AC/50Hz Protection class Climate class Energy consumption 0.65kWh/24h Rated current 0.9A Rated lamp power 1+1W R600a/25g Refrigerant Energy rating 595x575x820 Size WxDxH (mm)
- Page 24 PROBLEM SOLUTION -Ensure there are no obstructions preventing THE DOORS DO NOT door closure. CLOSE PROPERLY -Check the door compartments and shelves are correctly in place. -Check the door seal is not warped or torn. -Check the appliance is level. UNUSUAL NOISES -Check that the appliance is on a flat, level surface and is stable.
