MERIDIAN SERIES
Heated Pass-Throughs
MODELS:
 MHPT1-S
Single section
Solid full height door
 MHPT1-GS
Single section
Half glass/half solid door
 MHPT1-G
Single section
Full height glass door
MHPT2-GHSH
SPECIFICATIONS
Exterior: Cabinet front and shroud shall be 22-gauge
stainless steel. Exterior sides shall be aluminum. Facing
of shroud shall be easily removable without the use of
tools.
Cabinet interior shall be anodized aluminum. Bottom
& top of liner shall be die-stamped to provide
radius corners and a recessed bottom. Base shall be
fully insulated with high-density foamed in place
polyurethane.
Interior shall have three epoxy-coated wire shelves per
door section. Shelf support pilasters shall be heavy-duty
with shelves adjustable at 1.0" (2.5 cm) increments.
Units are mounted on 6" (15.24 cm) legs.
Doors: Solid doors shall have a 22-gauge stainless steel
exterior & anodized aluminum interior liner. Doors shall
be fully insulated with high density foamed in place
polyurethane. Each door shall have two self-closing,
cam-lift style hinges. Doors shall be easily removable
®
 MHPT2-S
 MHPT2-GS
 MHPT2-G
STANDARD FEATURES
• Shroud removes without tools, for easy condenser
maintenance
• Built in door locks
• Durable stainless steel doors and shroud, for lasting good
looks
• New high-density foam insulation cuts energy costs
• Big, easy grip handles are easy to find, don't intrude into
kitchen traffic
• Attractive aluminum side panels are easy to clean and
corrosion resistant
• Heavy-duty hinges with stay open feature
• Refrigeration system is located outside the food zone, more
space for product storage
• Mini watt door heaters eliminate condensation with
minimal energy cost
• Easy to read dial thermometer
• Tri seal door gaskets lower energy costs with a unique
insulating design
• Chrome shelves
• Aluminum interior stands up to food acids without
corroding
without use of tools. Door gaskets shall be magnetic snap-in
style to allow simple replacement. Door handles shall be
recessed.
Glass doors are constructed with a combination of extruded
aluminum & PVC, and are provided with magnetic gaskets.
Doors will have self-closing hinges and continuous handle
along vertical dimension of door(s).
• Please specify right or left hand hinging at time of order.
Mechanical controls shall be located behind a removable
shroud facing.
Dual Voltage Models Only: Electrical connections shall
be 115/208-240 volt, 60 hertz, single phase, and must be
hard-wired to the junction box located on top of the unit.
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Project __________________________
Item ____________________________
Quantity _________________________
CSI Section 11400
Two section
Solid full height doors
Two section
Half glass/half solid doors
Two section
Full height glass doors
• Lots of interior storage space for the money
• Rugged metal legs, adjustable to compensate for
uneven floors
OPTIONS AND ACCESSORIES
 Stainless steel exterior sides
 Stainless steel interior
 Stainless steel kick plate
 Door and end laminate
 Stainless steel exterior back
 Digital thermometer
 TXV
 Chrome Shelves
 Tray Slides
 220/50/1 electrical
 Electronic control
 Stainless steel legs
 Casters
Heating Assembly: Cabinets to be designed to
maintain temperature up to 200ºF. Helical shaped,
tubular fin heating element. High speed blower to
provide uniform airflow in cabinet. Removable/
replaceable heating system. No exposed elements inside
cabinet. Fan and heating elements service accessible
without tools. Temperature to be controlled by an
adjustable electronic thermostat equipped with an analog
display. On/off switch in front.
Approval _________________
Phone: 800-733-8948
Fax: 800-669-0619
Date____________________
Email: info@delfield.com
