DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual
DPtech LSW3003 Series Industrial Ethernet
Switch Installation Manual
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSW3003 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for DPtech LSW3003 Series

  • Page 1 DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual...
  • Page 2 DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Hangzhou DPtech Technologies Co., Ltd. provides full- range technical support. If you need any help, please contact Hangzhou DPtech Technologies Co., Ltd. and its sale agent, according to where you purchase their products.
  • Page 3 Hangzhou DPtech Technology Co., Ltd has the right to modify the content in this manual, as it is a user guides, Hangzhou DPtech Technology Co., Ltd made every effort in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document do not constitute the warranty of any kind express or implied.
  • Page 4: Table Of Contents

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Table of Contents CHAPTER1 PRODUCT INTRODUCTION ................1 1.1 P ......................... 1 RODUCT VERVIEW 1.2 I ........... 1 NTRODUCTION OF PRODUCT MODEL AND SPECIFICATIONS 1.3 T LSW3003-4GP-I-R ................. 2 HE FRONT VIEW OF 1.4 P...
  • Page 5 DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual 3.4 C ..................... 5 ONNECTING GROUNDING WIRES 3.5 C ....................6 ONNECTING INTERFACE CABLE 3.5.1 H ..................7 ARDWARE POWER FAILURE ALARM 3.5.2 C ....................7 ONNECTING POWER CABLE 3.5.3 C ....................7...
  • Page 6 List of Figures Figure1-1 The front view of DPtech LSW3003-I-R dual power device ........... 3 Figure1-2 The front panel indicator of DPtech LSW3003-4GP-I-R dual power device ......4 Figure1-3 The rear view of DPtech LSW3003-4GP-I-R dual power master device ......... 5 Figure1-4 RJ45 pinout diagram ........................
  • Page 7 DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual List of Tables Table1-1 Console port attribute table ......................5 Table1-2 100M Ethernet electrical interface properties ................5 Table1-3 Gigabit Ethernet interface property table:.................. 6 Table2-1 Temperature/humidity requirement ................... 2 Table2-2 Dust limit in the equipment room ....................2 Table2-3 Limit of harmful gases in the equipment room ................
  • Page 8: Chapter1 Product Introduction

    Chapter 1Product Introduction 1.1 Product Overview The DPtech LSW3003 series of industrial Ethernet switch is the product researched and developed by DPtech company, which aims at enterprise network and metropolitan area network and provides convergence and access layer devices for customers with abundant service features and routing capacities.
  • Page 9: The Front View Of Lsw3003-4Gp-I-R

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Item LSW3003-4GP-I-R Working -40℃~70℃ environment temperature Working 0%~95% environment relative humidity (non-condensation) 1.3 The front view of LSW3003-4GP-I-R 1. Front view (1) Slot SLOT3 interface indicator light 0 (2) Slot SLOT2 interface indicator light 0...
  • Page 10: Figure1-1 The Front View Of Dptech Lsw3003-I-R Dual Power Device

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Figure1-1 The front view of DPtech LSW3003-I-R dual power device Indicator Status Description (1) Slot SLOT3 interface Indicates that slot SLOT3 interface 0 is in communication state indicator 0 green Blinking Indicates slot SLOT3 interface 0 is sending and receiving data...
  • Page 11: Figure1-2 The Front Panel Indicator Of Dptech Lsw3003-4Gp-I-R Dual Power Device

    Indicates that the GE interface 0 is in a non-connected state Fast Indicates that the GE interface 0 is sending and receiving data Blinking(8 Figure1-2 The front panel indicator of DPtech LSW3003-4GP-I-R dual power device 2. Rear view (1) (2)...
  • Page 12: Port Introduction

    1.4 Port introduction 1.4.1 Console port The front panel of LSW3003 series of industrial Ethernet switch has a RS232 asynchronous serial port configuration (CON), which can be used to connect to the computer terminal and can be used to debug, configure, maintain and manage and load software for the system.
  • Page 13: 10/100/1000Base-T Ethernet Interface

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Attribute Description 10Mbps, half / full duplex Interface speed negotiation mode 100Mbps, half / full duplex Medium maximum Support 100m transmission distance transmission distance Interface standard IEEE 802.3i、802.3u、802.3ab 1.4.3 10/100/1000Base-T Ethernet interface 1.Gigabit Ethernet interface properties...
  • Page 14: Ethernet Optical Interface

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Figure1-4 RJ45 pinout diagram 3.Ethernet cable Ethernet electric interface adopt 5 categories twisted pair cable to connect Ethernet, as shown in Figure1-5. Figure1-5 Ethernet cable diagram For different usage, Ethernet twisted pair cables can be divided into straight-through and crossover cables: Standard cable: is also called straight-through cable.
  • Page 15: Interface Module (Lsw-8Gp)

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Figure1-6 Interface module (LSW-4T) appearance 1.5.2 Interface module (LSW-8GP) The interface module (LSW-8GP) provides external 8* Gigabit Ethernet optical interfaces. Figure1-7 Interface module (LSW-8GP) appearance 1.5.3 Interface module (LSW-8ST) The interface module (LSW-8ST) provides 8* 100M Ethernet optical interfaces (ST).
  • Page 16: Processor And Storage

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Figure1-8 Interface module (LSW-8ST) appearance 1.5.4 Processor and storage 1.Processor Processor is the engine that sends and receives data and processes service. 2.Flash Flash is used to store the Conboot software, which can used to boot system when you start the switch.
  • Page 17: Chapter 2Preparing For Installation

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Chapter 2Preparing for Installation To avoid possible bodily injury and equipment damage, read all safety recommendations carefully before installation. Note that the recommendations do not cover every possible hazardous condition 2.1 General safety recommendations ...
  • Page 18: Cleanliness

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual aging of the insulation materials, greatly lower the device reliability, and hence significantly shorten its service life. Table2-1 Temperature/humidity requirement Temperature Relative humidity -40℃~70℃ 0%~95% (non-condensation) 2.2.2 Cleanliness Dust is a hazard to the operating safety of your device. The dust accumulated on the chassis can cause electrostatic adsorption, one of the sources that cause the poor contact of connectors or metal contact points.
  • Page 19: Anti-Interference Requirement

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual  Connect your device to the earth ground properly.  Keep the equipment room as clean as possible.  Maintain adequate temperature and humidity.  Wear an ESD-preventive wrist strap and clothes when handling the circuit board.
  • Page 20: Laser Safety

    2.4 EMC description CISPR22 compliance DPtech LSW3003 series complies with the requirements of CISPR22 for Class A Information Technology Equipment(ITE). Warning: if this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions.
  • Page 21 DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Note:  These tools are not shipped with the firewall, so you need to prepare them by yourself  Chapter 2 Preparing for Installation...
  • Page 22: Chapter 3Device Installation

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Chapter 3Device Installation 3.1 Installation Preparation You have read Chapter 2 “Preparation for Installation” carefully. The requirements in Chapter 2 are satisfied Before install you should power off your device. Chapter 3 Device Installation...
  • Page 23: Installation Procedure

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual 3.2 Installation procedure Start Mount the switch on a Install switch to a 19-inch workbench rack Connect ground wire Connect power cable Connect the switch to a configuration terminal Verify the installation...
  • Page 24: Mounting The Switch To A Specific Site

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual 3.3 Mounting the switch to a specific site Adopt the following methods to the install your switch: 3.3.1 Mounting switch on workbench If a standard 19-inch rack is unavailable, you can place the switch on a clean workbench/tabletop. To prevent any damage, observe the following: ...
  • Page 25: Mounting Switch In A 19-Inch Rack

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Figure3-2 Mounting device on the workbench 3.3.2 Mounting switch in a 19-inch rack 1.Mounting ear Figure3-3 Mounting ear 2.Mounting the switch in a rack Figure3-4 Mounting the device to a rack (To see the image clearly, we only snapshot the device) 3.Fastening the switch...
  • Page 26: Connecting Grounding Wires

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Figure3-5 Fasten the switch 3.4 Connecting grounding wires Caution:  When installing or using your switch, properly connect the grounding wire for lightning protection  and anti-interference. The grounding resistance must be smaller than 5 ohm.
  • Page 27: Connecting Interface Cable

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual To connect the ground cable, you should strip the ground wire insulation rubber about 15mm and hook the wire on a grounding pole clockwise and fasten the ground pole on the switch by hexagonal screw.
  • Page 28: Hardware Power Failure Alarm

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Power terminal (4) Power terminal PWR1 PWR0 (5) Alarm terminal (6) earth terminal 3.5.1 Hardware power failure alarm 3.5.5.1 Hardware power failure alarm The device reserves the external hardware alarm terminals: as shown below, Relay alarm output Warning port Description: C: connect public terminal;...
  • Page 29: Connecting Interface Cable

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual 2.Method for connecting DC power cable Ensure that the protection grounding wire has been correctly connected to the earth, and check the voltage value of each pin (pictured above). The L is connected with a power supply live Wire, N is connected with zero line, grounding earth.
  • Page 30: Connecting Service Port

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Caution:  The serial ports on PCs do not support hot swapping. If the switch device has been powered on, always connect the console cable to the PC before connecting it to the switch, and when you connect PC to the switch, you should connect DB9 terminal configuration cable to PC and then RJ45 terminal.
  • Page 31: Chapter 4Starting Up The Switch And Upgrading Software

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Chapter 4Starting up the switch and upgrading software 4.1 Starting up the Switch at the Initial Boot 4.1.1 Setting up a Configuration Environment 1.Connecting the switch to the terminal pc Connect the RJ-45 connector of the console cable to the console port on the switch, and connect the DB-9 female connector of the console cable to the serial port on the PC that is used for configuring the switch, as shown in Figure4-1..
  • Page 32: Figure4-2 Setting Up A New Connection

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Figure4-2 Setting up a new connection Enter the name of the new connection in the Name field and click <OK>. The dialog box, as shown in Figure 4-3 displays. Select the serial port to be used from the Connect Using drop-down menu. The serial port must be the same port connected by the console cable.
  • Page 33: Figure4-4 Setting Communications Parameters

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Table4-1 Configure serial port properties Attribute Value Baud rate 9600bps(the default) Data bits Parity check None Stop bits Flow control None Note:  To restore the default settings, click Restore Defaults. ...
  • Page 34: Booting The Switch

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Figure4-5 Hyper Terminal Select File/Properties/Settings. In the Properties dialog box, select the Settings tab, as shown in Figure 4-6. Select VT100 or Auto detect in the Emulation dropdown menu. Click <OK>. Figure4-6 Settings tab 4.1.2 Booting the Switch...
  • Page 35: Starting Procedure

    Verify whether terminal PC display normally. Method: start up your device and on the terminal PC you can view the device initialization information. Enter password at the command line and then you can configure <DPtech> command line. 4.1.3 Starting procedure Power up your device, you can view the initialization information on the terminal PC display.
  • Page 36: Default Login Method For Web

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Memory Type:DDRII Capacity of DDRII Memory: 256MB I2C Init Sucessfully! RCWLR=0x54060000 RCWHR=0xa0606c00 Press Ctrl+E to enter Basic boot menu... boot extend... Checking system image... Booting Normal Extend ConBoot..********************************************************* ConBoot, extend Version...
  • Page 37: Figure4-7 Web Management Interface

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Figure4-7 Web management interface Caution:  You should not login to the web management interface by using of http or https protocol on the  same PC. After first time you login to the web management interface, modify the default login password.
  • Page 38: Chapter 5 Maintenance And Troubleshooting

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual Chapter 5 Maintenance and Troubleshooting 5.1 Dealing with power system failures  Trouble phenomenon PWR LED on the front panel isn’t on.  Troubleshooting You can know whether the power system has failed by reading the PWR LED on the front panel. If the power system is operating normally, the PWR LED is ON.
  • Page 39: Garbled Characters On The Terminal

    DPtech LSW3003 Series Industrial Ethernet Switch Installation Manual If no problem is found, examine the console cable or terminal PC(HyperTerminal) settings: please exam the followings: Bits per second is 9600, Data bits is 8, Parity is None, stop bits is 1, Flow control is None, and Terminal Emulation is VT100.
