Delfield 18650VDL Specification Sheet

18600VD
Versa Drawer™

Models

18650VDL 50" Versa Drawer with (2) 32" drawers and compressor on the left
18650VDR 50" Versa Drawer with (2) 32" drawers and compressor on the right
18682VDL 82" Versa Drawer with (4) 32" drawers and compressor on the left
18682VDR 82" Versa Drawer with (4) 32" drawers and compressor on the right
18682VDL

Specifications

Exterior Top: Constructed of one-piece heavy-gauge
stainless steel with integral 2.12" (5.4cm) high square nosing
at front.
Exterior Sides, Back and Bottom: heavy-gauge stainless
steel sides with removable stainless steel mechanical access
panel on compressor end. Back and bottom are constructed
of galvanized steel.
Interior: Interior of each drawer section is a polyethylene
rotocast liner with ABS drawer front liners
Drawers: Heavy-gauge stainless steel exterior front, with a
thermoformed ABS plastic interior liner. Frame and tracks are
constructed of 11 and 12-gauge stainless steel. Roller track
assemblies have self-lubricating Delrin™ rollers.
980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858
Standard Features
• 4 temperature operation-each drawer is
completely independent and can operate as
a refrigerator, freezer, chiller or thaw cabinet
at any time
• Easy to use microprocessor control with
push button function selection
• HACCP electronic record keeping, alarm
notifications, and service diagnostics
• Heavy-gauge stainless steel top
• Standard on 6" casters
• Mechanical access on compressor end of
unit
• 32" heavy duty full extension drawers with
(2) 12"x20" pan capacity per drawer
• NSF 7 certified
• High density polyurethane foam throughout
• Dart style quick change gaskets
• 8' long electrical cord
• Environmentally friendly HFC-404A
refrigerant
• 34" ADA height standard
• One year parts, one year labor and 5 year
compressor warranty
Refrigeration System: Environmentally friendly HFC-
404A refrigerant. Each independent drawer has it's own
evaporator coil with expansion valve. Digital control acts
as thermometer, thermostat and diagnostic center for each
drawer. Hot gas defrost system is also utilized during thaw
operation.
Electrical Connections: 115 volt, 60 Hertz, single phase. Unit
is wired with 3-wire, grounded, maximum 8' (2.4m) cord and
plug.
The Delfield Versa Drawer is a unique food holding device that includes
an open food container disposed within a refrigerated cabinet such that
both the container and interior of the cabinet are exposed to the same
refrigerated environment, thereby eliminating the need for conventional
dual environment systems which refrigerate food disposed within
insulated, closed containers, while maintaining the interior of the cabinet
at ambient temperature.
Phone: 800-733-8948 or +1 989-773-7981
Fax: 800-669-0619
Project __________________________________
Item ____________________________________
Quantity ________________________________
CSI Section 11400
Approved _______________________________
Date ____________________________________
www.delfield.com
Options &
Accessories
• 6" legs
• 230/50/1 electrical
