Summary of Contents for Holding Hands B1
- Page 1 U S E R M A N U A L H O L D I N G H A N D S B1...
- Page 2 Before using, carefully read the product description, rules of use and properly follow them.
-
Page 3: Table Of Contents
Table of Contents: 1. Basic information ……..……………………………………………………………………………… 3 2. Introduction …………………………………………………………………………………………..5 3. Application…. ….………………………………………………………………………………………. 5 4. About the manual………………………………………………………………………………………. 5 5. Security ………...………………………………………………………………………………………. 5 5.1. Precautions before use………….. ……………………………………………………………… 5 5.2. Caution when driving ……………………………………………………………………………... 6 5.3. Waring sings …….. ………………………………………………………………………………. 6 5.4. -
Page 4: Basic Information
Rear tire diameter: 12 " Max. user weight: 100 kg Max. Driveway: 15 ° Manufacturer: Zhejiang Hand in Hand Intelligent Health Technology Co., Ltd. The packaging contains quantity quantity electric wheelchair (model B1) 1 piece Battery 1 piece Charger 1 piece... -
Page 5: Introduction
2. Introduction Thank you for purchasing and using the Holding Hands B1 electric wheelchair. Thank you very much for trust and support for our company. Please read the instructions before using and adapt to them. 3. Application The wheelchair is used to ride around the apartment and for short distances for disabled people, patients and the elderly with short stature who are infirm or sick (except for those who cannot correctly assess the risk of driving and with a large mass - over 100 kg). -
Page 6: Caution When Driving
5.2 Caution when driving ✓ The maximum load of this wheelchair is 100 kg and the maximum angle of inclination is 8°. Avoid walking on steep slopes, high steps, ditches, and avoid walking on railroad tracks and rails without first looking around and helping. ✓... -
Page 7: Repair And Warranty Information
Follow the rules of use contained in this description to keep the truck in good condition. INFORMATION! 5.4 Repair and warranty information Please do not make repairs yourself and do not use spare parts as this may void the warranty. Please keep the purchase invoice / receipt, original box and warranty card. -
Page 8: Tires
Folding: Press the button to unlock the handle and remove the lock. Pull the round backrest tube with both hands so that the backrest and seat cushion are folded down. Pull the footrest up to the vertical position (Figure 6). Figure.6 Figure.7 Tires... -
Page 9: Diagnostics
dissipation by the fan and the temperature of the charger housing increases slightly. 5. The charger is intended for indoor use and is not waterproof. 1. Keep away from sources of ignition when charging. A fire source may cause the battery to ignite or explode. -
Page 10: Operation Of The Controller An Massager
Contractor Please contact the distributor failure Signaling Please contact the distributor 10. Control service Do not use a wheelchair until you are familiar with the operation of the controller. All controller parameters are factory set to ensure the best performance in different conditions. If the controller parameters need to be changed for medical reasons, our professional staff must adapt them. -
Page 11: Wheelchair Inspection And Maintenance
11. Wheelchairs inspection and maintenance The table below lists the activities you need to do to check that the truck is ready for use. If you find any irregularities, please contact your distributor. Check list Device ◎ Can the joystick be moved forward, backward, left and right ◎... -
Page 12: Terms Of A Wheelchair Warranty
◎ After thorough checking of the above functions, if they are working properly, Semi-annual it is recommended to thoroughly clean the hard-to-reach places of the maintenance wheelchair with a slightly damp cloth, cord, or toothbrush. check Annual Professional review is recommended. In case of any problems contact the maintenance service. -
Page 13: Warranty Card
Warranty Card Product bar code ………………………...Receipt or invoice number ……………………… Date and point of purchase..………………………………………………………………………… Description of the fault ………………………………………………………………………………. First name and last name …………………………………. Phone number ………………………………….emeil address: ………………………………………. Return address ……………………………………………………………………………………………………………… ……………………………………………………………………………………………………………… Date and signature: ……………………………… Note: The warranty service accepts the device only properly packaged, protected against damage in transit, with a bar code, warranty card, purchase / invoice receipt and description of the fault. - Page 14 Service Fault description Repair details Date employee...
