ALLTRONIC Micro6R Manual

Control Type Micro 6R Threephase 400V or Monophase 230V
P1 WORKING TIME TRIMMER
P2 PAUSE TIME TRIMMER
P3 PEDESTRIAN TIME TRIMMER
F1 = FUSE 5X20 F2A
F2 = FUSE 5X20 T0,8A
F3 = FUSE 5X20 T0,8A
RL1 LIGHT OF COURTESY RELAY (exit 24Vdc)
RL2 BLINKER RELAY OF 24Vac
RL3 OPEN RELAY
RL4 CLOSE RELAY
RL5 BLINKER RELAY 230Vac
DECLARATION OF CONFORMITY (according to ISO/IEC Guide 22 and EN 45014)
Manufacturer's Name :
Manufacturer's Address :
Product Name :
Central for Rapid/Rolling Door
Model :
Micro6R
CONFORMS TO THE FOLLOWING EMC SPECIFICATIONS BASED ON SAMPLE TESTING:
The product has been tested in the typical installation configuration and with peripherals which conform to EMC Directive.
I the undersigned declare that the product herewith complies with the protection requirements of the EMC Directive 89/336/
EEC, the 73/23/CEE Low Tension Directive and also the Directive 89/392/CEE (Electric Equipment Security of the Devi-
ces).
Bene Vagienna, 12/07/2017
For fast, rolling, sliding and Sectional door
TRIMMER – FUSE – RELAY
on 24Vac protection : blinker supply 24Vac
on 18Vac protection : electronic supply and exit 24Vdc.
on 230Vac protection : blinker supplì 230Vac.
ALLTRONIC s.n.c.
Via Torino. 84—12041 Bene Vagienna (Cn) Italy
DECLARES THAT THE FOLLOWING PRODUCT
EN 55011
EN 55014-1
EN 55014-2
EN 61000-3-2
EN 61000-3-3
EN 60335-1
EN 60204-1
EN 12453
EN 61000-6-1
EN 61000-6-3 + A11
Allodi Francesco
Proprietario
