Enchanted Garden 343-2002 Instruction Manual

Low voltage garden light fixture

DEAR CUSTOMER,

Congratulations on your purchase of a ENCHANTED GARDEN

home and provide many years of enjoyment. ENCHANTED GARDEN

professional quality. Ask your dealer about the many other ENCHANTED GARDEN

To ensure the maximum performance of your garden light, please read and save these instructions.

Replacement parts may be ordered by using the fixture model number and the part's name.

INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS

IMPORTANT SAFETY INSTRUCTIONS

• To reduce the risk of FIRE OR INJURY TO PERSONS turn off, unplug transformer and allow lamp to cool before replacing it. Lamp gets HOT quickly.

• Keep the lamp away from materials that may burn.

• WARNING - Risk of Electric Shock. Install all luminaires 10 feet (3.05 m) or more from a pool, spa or fountain.

• Install in accordance with all local codes and ordinances.

Only for use with low voltage power units with a maximum output rating of 15V, 300W per secondary.

FOR LANDSCAPE LIGHTING SYSTEMS ONLY. OUTDOOR USE ONLY.

THE DEVICE IS ACCEPTED AS A COMPONENT OF A LANDSCAPE LIGHTING SYSTEM WHERE THE SUITABILITY OF THE COMBINATION SHALL

BE DETERMINED BY CSA OR LOCAL INSPECTION AUTHORITIES HAVING JURISDICTION.

READ AND SAVE THESE INSTRUCTIONS

CUSTOMER SERVICE

1-888-867-6095

•

343-2002

Low Voltage

GARDEN

LIGHT FIXTURE

BULB TYPE: 11W INCANDESCENT T5 WEDGE BASE

lighting product. Our products will help to enhance the beauty of your

offers a wide selection of lighting products of the highest

products that will help to create your own paradise.

customerservice@niinorthern.com

INST-343_2002-0621-01-EN

Table of Contents

Need help?

Do you have a question about the 343-2002 and is the answer not in the manual?

Page 1 ENCHANTED GARDEN offers a wide selection of lighting products of the highest ® professional quality. Ask your dealer about the many other ENCHANTED GARDEN products that will help to create your own paradise. ®...
Page 2 Assembly of the Light Fixture Thumbscrews 1.1 Carefully remove the fixture from its protective Cover packaging. Pins 1.2 Attach spike, post and base together by turning them Diffuser clockwise. 1.3 Remove the three (3) thumbscrews, lift off cover, diffuser Middle tier and middle tier to give access to the bulb socket.
Page 3 Bury the landscape wire Light adjustment 6 ’’ (15,24cm) max. * llustration of fixture is for example only. * llustration of fixture is for example only. The landscape wire and connector box can also be hidden under It is recommended to adjust your lighting effect at night before mulch, stone or buried under grass at a maximum depth of 6”...
