A&S 2.1 Bar with Wireless Subwoofer 300 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

2.1 Bar with Wireless Subwoofer 300
USER MANUAL

Advertisement

Table of Contents
loading

Summary of Contents for A&S 2.1 Bar with Wireless Subwoofer 300

  • Page 1 2.1 Bar with Wireless Subwoofer 300 USER MANUAL...

  • Page 2: Table Of Contents

    Contents Important Safety Instructions ..................... 3 Safety ....................................... 3 Warning ....................................4 What’s in the Box ........................5 Identifying the Parts ......................6 Main Unit ....................................6 Wireless Subwoofer ................................6 Remote Control ................................... 7 Getting Started ........................7 Prepare the Remote Control ............................7 Replace the Remote Control Battery ...........................

  • Page 3: Important Safety Instructions

    Important Safety Instructions The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude as to constitute a risk of electric shock to persons.

  • Page 4: Warning

    21 The use of apparatus in moderate climates. Warning • The battery (batteries or battery pack) shall not be exposed to excessive heat such as sunshine, fire or the like. • Before operating this system, check the voltage of this system to see if it is identical to the voltage of your local power supply.

  • Page 5: What's In The Box

    What’s in the Box Main Unit Remote Control Instruction Manual AC Power Cable AC Power Cable 3.5mm to 3.5mm audio Cable Wireless Subwoofer Wall Bracket Optical Cable • Design and specifications are subject to change without notice.

  • Page 6: Identifying The Parts

    Identifying the Parts Main Unit Top view    Rear view button 9 OPTICAL/COAXIAL Indicator In OPTICAL mode the light up Orange. Switch the unit between ON and STANDBY mode. In COAXIAL mode the light Orange flash. 10 HDMI ARC Indicator 2 SOURCE button In HDMI ARC mode the light up White.

  • Page 7: Remote Control

    Remote Control Switch the unit between ON and STANDBY mode. 2 SOURCE Select the Input source. 3 VOL+ / VOL– Adjust sound volume level. • Skip to previous/next audio track. • / PAIR Play / pause / resume playback in Bluetooth mode. Press and hold to activate the pairing function in Bluetooth mode or disconnect the existing paired Bluetooth device.

  • Page 8: Replace The Remote Control Battery

    Replace the Remote Control Battery The remote control requires a CR2025, 3V Lithium battery. 1 Push the tab on the side of the battery tray towards the tray. 2 Now slide the battery tray out of the remote control. 3 Remove the old battery. Place a new CR2025 battery into the battery tray with the correct polarity (+/-) as indicated.

  • Page 9: Connections

    710mm 710mm 3 m m Connections Use the HDMI (ARC) Socket ARC (Audio Return Channel) The ARC (Audio Return Channel) function allows you to send audio from your ARC- compliant TV to your sound bar through a single HDMI connection. To enjoy the ARC function, please ensure your TV is both HDMI-CEC and ARC compliant and set up accordingly.

  • Page 10: Use The Coaxial Socket

    Tips: • Your TV must support the HDMI-CEC and ARC function. HDMI-CEC and ARC must be set to On. • The setting method of HDMI-CEC and ARC may differ depending on the TV. For details about ARC function, please refer to your TV owner’s manual. •...

  • Page 11: Connect To Power

    B. Use a 3.5mm to 3.5mm audio cable (included) to connect the TV’s or external audio device headphone socket to the AUX socket on the unit. Connect to Power Before connecting the AC power cord, ensure you have completed all other connections. Risk of product damage! Ensure that the power supply voltage corresponds to the voltage...

  • Page 12: General Operation

    1. Unplug both units from the mains sockets again, then plug them in again after 3 minutes. 2. Press and hold the PAIR switch on the rear of the subwoofer for a few seconds, the Pair indicator on the subwoofer will rapidly blink. Then press on the unit or remote control to switch the unit ON.

  • Page 13: Select Equaliser (Eq) Effect

    Select Equaliser (EQ) Effect Press the EQ button on the unit or the CUSTOM/MOVIE/MUSIC button on the remote control to select the preset equaliser effects. • When CUSTOM (Default) is selected, the COAXIAL indicator will flash (Orange) once. • When MOVIE EQ is selected, the OPTICAL indicator will flash (White) once. •...

  • Page 14: Listen To Music From Bluetooth Device

    If you cannot find the soundbar, press and hold the / PAIR button on the unit or on the remote control. The system has entered pairing mode. The unit' Blue indicator will flash rapidly and prompt “Pairing“. 3 Select “A&S Bar 300” enter “0000” for the password if necessary. The unit will voice “Paired” and the Blue indicator will light up solidly.

  • Page 15: Specifications

    • I can’t find the Bluetooth name of this unit on my Bluetooth device for Bluetooth pairing Ensure the Bluetooth function is activated on your Bluetooth device. Ensure you have paired the unit with your Bluetooth device. • Sometimes the unit will auto turn off back to standby mode when using the AUX source. This is a 15mins power off function, one of the ERPII standard requirement for saving power.
