Packing List Optical DVI Transmitter Optical DVI Receiver Additional Packing List - 5V Power Adaptor (2pcs)
Page 5
Features High Speed and long distance transmission by single LC type Single-mode Fiber • Single Link TMDS video signals and EDID data are transmitted by optical fiber • Extends up to 1Km by single-mode fiber • DVI Specification 1.0 Compliant •...
Page 6
Connection Caution • Use the DC adapter (5V) included in the product package for the transmitter and Receiver. Connect Single-mode Fiber-Optic cable in order to transmit the signal till 1 kilometers distance.
Connection Connect transmitter to the DVI port on your computer. • Connect receiver to the DVI port on your digital display product. • Connect Single-mode LC type 1 channel standard fiber-optic cable • between transmitter and receiver. Connect power adapter to the transmitter and receiver which has been •...
Precautions for Safety Make sure to comply with precautions to prevent danger and damage on the property through proper usage product. This symbol is intended to alert you that uninsulated voltage Within this product may have sufficient magnitude to cause Electric shock.
Page 9
4. Insert the power plug firmly to avoid shanking. If not inserted firmly, it can cause a fire. 5. Do not disassemble, repair and modify. It can cause a fire and an injury by electrical shock due to abnormal operation. 6.
Cautions 1. Do not put the heavy object on top of the product. It may cause malfunction. 2. Put the product in the flat and stable location. If the product falls down or dropped, it may cause an injury and malfunction. 3.
Out of warranty services When you request services (in the case of non-manufacturing defect but the troubles by misusage), may serve with charge of follows. Defects of products caused by accident, disaster. • Damages of products caused by the customer’s carelessness or Mistaken •...
Page 12
QUICK START GUIDE Optical DVI Extender (Single-Mode) 사용설명서...
Page 13
구성품 광 DVI 송신부 광 DVI 수신부 추가 구성품 - 5V 전원 어댑터 (2ea)
Page 14
제품사양 High Speed and long distance transmission by single LC type Single-mode Fiber • Single Link TMDS video signals and EDID data are transmitted by optical fiber • Extends up to 1Km by single-mode fiber • DVI Specification 1.0 Compliant •...
Page 15
연결방법 주의 사항 • 송 수신 모듈 모두 외부 전원이 필요하므로 반드시 지급되는 DC 어댑터(5V)를 연결하여야 합니다. 광케이블의 규격에 따라 전송 거리의 차이가 있으므로 1Km 전송을 위해서는 반드시 싱글모드 광케이블을 사용하여야 합니다.
Page 16
연결방법 •제품의 송신부를 컴퓨터의 DVI 포트에 연결합니다. •제품의 수신부를 디지털 디스플레이의 DVI 포트에 연결합니다. •송신부와 수신부 사이에 싱글모드 LC타입 1채널 표준 광케이블을 연결합니다. •지급되는 어댑터를 송신부/수신부에 연결합니다. •제품의 모든 연결이 완료되면, 송/수신부의 청색 LED가 점등합니다. - 적색 LED 점등: 전원 수급 - 청색...
Page 17
안전을 위한 주의사항 제품을 올바르게 사용하여 위험이나 재산상의 피해를 미리 막기 위한 내용이므로 반드시 지켜주시기 바랍니다. 경고 지시사항을 위반할 시 사람이 사망하거나 중상을 입을 가능성이 예상되는 내용입니다. 주의 주의사항을 위반할 시 사람이 부상을 입거나 물적 손해 배상이 예상되는 내용입니다. 경고 1.
Page 18
4. 전원플러그가 흔들리지 않도록 확실히 꽂아 주세요. 접속이 불완전한 경우는 화재의 원인이 됩니다. 5. 절대로 분리, 수리, 개조하지 마세요. 이상 작동으로 인해 화재, 감전 상해의 위험이 있습니다. 6. 단자의 구멍 등으로 금속류(머리핀, 쇠붙이 등)나 타기 쉬운 이물질 (성냥, 종이 등)을 집어 넣거나 떨어뜨리지 마세요. 화재, 감전의 원인 이...
Page 19
주의 1. 무거운 물건을 올리지 마세요. 고장의 원인이 됩니다. 2. 평평하고 안정된 장소에 설치하세요. 제품이 넘어지거나 떨어질 경우 상해의 원인 및 고장의 원인이 됩니다. 3. 온도가 너무 높은 곳(50℃ 이상)이나 낮은 곳(0℃ 이하), 습기가 많은 곳에 설치 하지 마세요. 화재 감전의 원인이 됩니다. 4.
Page 20
하기와 같은 항목에 대해서는 유상으로 서비스가 진행되오니 이점 유의 하시기 바랍니다. •사고 및 천재지변(화재, 염해, 수해 등)에 의한 고장 발생 시 •소비자의 취급 부주의, 임의적인 수리 또는 개조로 인한 고장 발생 시 •당사에서 미 지정한 소모품이나 옵션품 사용으로 고장 발생 시 •㈜옵토웰...
