Summary of Contents for Omega OMOG25B
- Page 1 INSTRUCTION MANUAL FOR OMEGA MICROWAVE OVEN OMOG25B/ OMOG25S/ OMOG25W...
-
Page 3: Table Of Contents
The manufacturer will not be responsible for any damage to property or to persons caused by incorrect installation or improper use of the appliance. Due to continual product development, Omega reserves the right to alter specifications and appearances without notice. - Page 4 IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE. To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following: 1. WARNING: Liquids and other foods must not be heated in sealed containers since they are liable to explode.
-
Page 5: Important Safety Warnings
IMPORTANT SAFETY WARNINGS 25. WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children shall be kept away unless continuously supervised. 26. The microwave oven must be operated with the decorative door open (for ovens with a decorative door.) 27. -
Page 6: Utensils In The Microwave
UTENSILS IN THE MICROWAVE MATERIALS TO BE AVOIDED IN THE MICROWAVE OVEN Utensils Remarks Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with metal handle May cause arcing. Transfer food into microwave-safe dish. Metal shields the food from microwave energy. Metal trim may Metal or metal trimmed utensils cause arcing. -
Page 7: Product Details
PRODUCT DETAILS Model: OMOG25B, OMOG25S, OMOG25W Rated Voltage: 240V~50Hz Rated Input Power(Microwave): 1450W Rated Output Power(Microwave): 900W Oven Capacity: Rated Input (Grill) 1000W Turntable Diameter: 315 mm External Dimensions (WxDxH): 513x410x307mm Net Weight: Approx. 14.8kg SETTING UP YOUR OVEN Names of Microwave Oven Parts and Accessories Remove the microwave oven and all materials from the carton and oven cavity. -
Page 8: Installation
INSTALLATION Countertop Installation Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged. Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron. Installation Select a level surface that provides enough open space for the intake and/or outlet vents. -
Page 9: Operating Instructions
OPERATING INSTRUCTIONS Setting the Clock When the microwave oven is powered on, the oven will display "0:00" and the buzzer will ring once. 1. Press "CLOCK" once - "00:00" displays. 2. Turn to adjust the hour figures. The input time should be within 0-23(24-hour). 3. - Page 10 OPERATING INSTRUCTIONS Grill or Combi (Grill and Microwave) Cooking 1. Press "Grill/Combi". The screen will display “G”. Press "Grill/Combi" for times or turn to choose the power you want. "G", "C-1"or "C-2" will display for each added press. 2. Press "START/+30SEC./CONFIRM" to confirm. 3.
- Page 11 OPERATING INSTRUCTIONS Multi-Stage Cooking A maximum of two stages can be set. If one stage is defrosting, it should be put the first stage. The buzzer will ring once after each stage and the next stage will begin. Note: Auto menu and preheating cannot be set as one of the stages. Example: If you want to defrost the food for 5 minutes, then to cook with 80% microwave power for 7 minutes, the steps are as follows: 1.
- Page 12 OPERATING INSTRUCTIONS Auto Menu 1. In standby mode, turn right to choose the function wanted, and "A-1","A-2","A-3".."A-10" will be displayed. 2. Press "START/+30 SEC/CONFIRM" to confirm the menu you need. 3. Turn to choose the weight of menu, and "g" indicator will be displayed. 4.
-
Page 13: Maintenance And Cleaning
MAINTENANCE AND CLEANING CAUTION Personal Injury Hazard It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy. CLEANING CAUTION: Be sure to unplug the appliance from the power supply. -
Page 14: Warranty
WHAT IS COVERED: By Our Warranty During the warranty period, Omega or its authorised Service Centre will, at no extra charge, if your appliance is readily accessible without the need of special equipment and subject to the terms and conditions of this warranty, repair or replace any parts which it considers defective.
