Page 1 VandalBullet MOBOTIX MOVE VB-4-IR Quick Install...
Page 2 VandalBullet MOBOTIX MOVE VB-4-IR This guide is for quick installing and connecting the VandalBullet MOBOTIX MOVE VB-4-IR. You can find detailed information on the installation and connections in the Camera Manual (PDF, available on www.mobotix.com > Support > Download Center > Documentation > Manuals).
Page 3 Reset Button Press the reset button with a proper tool for at least 20 seconds to restore the system. Camera Cabling Please follow the instructions below for cable connections. Power Connection Use a DC 12V/AC 24V adaptor and connect it to the 2-pin terminal block of the All-in-One cable and the power outlet. Alternatively, connect the Ethernet cable to the RJ-45 connector of the All-in-One cable, and plug the other end of the cable to a Power over Ethernet (PoE) switch.
Page 4 VandalBullet MOBOTIX MOVE VB-4-IR Before Logging Into the Camera A client program will be automatically installed to the PC when connecting to the camera. Before logging in to the camera, ensure downloading the ActiveX control is allowed by either changing the ActiveX controls and plug-ins or setting Internet’s security level to default.
