Displays2go INTWHITWRD User Manual

Hide thumbs Also See for INTWHITWRD:
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Rev. 19.08
INTERACTIVE WHITEBOARD
MODEL: INTWHITWRD
Scan QR code to visit the product page:
Operating Instructions for Whiteboard
Note: Before using the product, please read the instructions thoroughly!
If you have any questions regarding our products, please visit us at www.displays2go.com or
contact D2G customer service at 844-221-3393.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INTWHITWRD and is the answer not in the manual?

Questions and answers

Related Manuals for Displays2go INTWHITWRD

Summary of Contents for Displays2go INTWHITWRD

  • Page 1 Scan QR code to visit the product page: Operating Instructions for Whiteboard Note: Before using the product, please read the instructions thoroughly! If you have any questions regarding our products, please visit us at www.displays2go.com or contact D2G customer service at 844-221-3393.

  • Page 2: Table Of Contents

    DISPLAYS2GO Table of Contents Table of Contents 1. Introduction ......................3 2. Set up the Whiteboard ..................... 4 Wall Mounting ....................4 Floor Standing....................6 3. Connection ....................... 7 4. Calibration ........................ 8 Install the Calibration Software................. 8 16- or 9-point calibration................... 8 5.

  • Page 3: Introduction

    DISPLAYS2GO Interactive Whiteboard Introduction Thank you for purchasing the interactive whiteboard with eMark Pen! This interactive whiteboard system uses optical touch sensor, easily turns your projected screen into an interactive touchscreen. It provides the ideal interactive platform for education and business.

  • Page 4: Set Up The Whiteboard

    DISPLAYS2GO Interactive Whiteboard Set up the Whiteboard Wall Mounting The wall mounting installation is quick and easy using the included hardware kit. Minimum 2 people. Tools required: power drill, bubble level, adjustable wrench. Hardware QTY. a. Mounting Bracket – Top 2 pcs b.
  • Page 5 DISPLAYS2GO Interactive Whiteboard Step 3: Insert the (5) expansion wall anchors (c) into the holes drilled in step 2, then unscrew the M8 Hex screw from the anchor sleeves. Make sure all anchors are flush against the wall. See below: Step 4: Insert a screwdriver or other metal rod into the anchor sleeve.

  • Page 6: Floor Standing

    DISPLAYS2GO Interactive Whiteboard Step 7: Horizontally slide the assembled bottom bracket at the back of the whiteboard, until the wall anchor can be seen through the cutout on the bracket. Fix the bracket from the back by tightening the 2xM4 screws on the back of the whiteboard.

  • Page 7: Connection

    DISPLAYS2GO Interactive Whiteboard Connection It’s easy to set up the interactive whiteboard. Just follow a few simple steps below, the whiteboard will be connected and ready to use. Connect the whiteboard with your PC and projector: Insert the USB end of the provided serial cable into one USB port on your PC and insert the other end of the cable into the whiteboard.

  • Page 8: Calibration

    DISPLAYS2GO Interactive Whiteboard Calibration Calibrate after connected with the projector. Install the Calibration Software. Install the calibration software from the supplied USB flash drive onto your PC. Then Find and open the “Optical Touch Device Control Panel” on your Windows desktop.
  • Page 9 DISPLAYS2GO Interactive Whiteboard Choose “16 points” in “calibration” section then click “Apply” and “OK” to confirm the selection. Next, click “Calibrate” to enter the calibration window.
  • Page 10 DISPLAYS2GO Interactive Whiteboard Follow the instructions on the screen: press and hold the blue dot. It will turn green after long press. After 16 dots all turn to green, the calibration is done. Press “OK”...

  • Page 11: Technical Specifications

    DISPLAYS2GO Interactive Whiteboard Technical Specifications ITEM SPECIFICATION Sensing Technology Infrared/ Optical imaging touch technology Sampling Rate 120 fps Touch Points Up to 10 Points Touch Accuracy ±3mm Touch Resolution 32768*32768 Response Time ≈8ms Display Size 86’’ Aspect Ratio 16:10 Whiteboard...
  • Page 12 DISPLAYS2GO Interactive Whiteboard Per EN 61000-4-2: Level 4, contact discharge 6KV, air discharge 8KV...
