ASSEMBLY AND OPERATING INSTRUCTIONS LIKEtoBIKE 24
Please read this manual carefully before using the LIKEtoBIKE for the first time!
The assembly must be done by an adult!
Remove all packaging materials. Contents of the enclosed acces-
sory box are: Pedals, hexagon tool (Allen key) (4mm,5mm,6mm),
Front and Rear Reflectors, Touch-up paint, Instructions.
clamping plate screws
Twist shifter
2. Dismantle the clamping plate of the adjustable stem, align the
handlebar with the gear knob to the right in the center and fix it by
tightening the four clamping plate screws.
Very important: Check the tightness of the height
adjustment screw (torque 8-10 Nm)
Height adjustment
screw
To adjust the stem, please refer to the separate stem guide.
Very important: With this screw you set only the head-
set play!
This screw is not used to attach the stem!
clamping plate
Adjusting screw for
headset play
(NOT TO FIX THE
HEADSET!)
Seat post
clamping screw
3. 3.After loosening the seat post clamp screw, slide the seat post
into the seat tube.
Please note the minimum insertion depth of the sadd-
le support! This is indicated by a marking line on the
seatpost! The saddle support must not be pulled out
beyond this mark be, otherwise a secure connection to
the seat tube is not guaranteed! The saddle can be adjusted
in the longitudinal direction and inclination after loosening the
saddle fastening screw. Then tighten this screw again!
Adjusting the correct saddle height: Place a pedal in the lowest
position. If the child is sitting on the saddle, it must be able to
touch this pedal with his heel outstretched. Make sure that the
hips remain horizontal and do not tip over to the side!
right pedal
left pedal
4. Now mount the pedals. Turn the pedal axles by hand until snug!
Then tighten with a 15 mm wrench.
Important: The right pedal is mounted clockwise, the
left pedal counterclockwise! The pedals are marked on
the pedal axle with an „R" for the right pedal and an „L" for
the left. It is important to remember this if you need to loosen the
pedal axle someday. So that the pedals can easily be loosened
again later,
grease them lightly before mounting.
After the first long ride please check that the pedals are
seated firmly! Loose pedals could damage the thread of
the cranks or cause a fall!
Saddle fastening
screw
