12 & 20 TON SHORT BOTTLE JACK
12 & 20 TON BOTTLE JACK
Capacity ........................................................... 12 Ton ........................................ 12 Ton ........................................ 20 Ton ......................................... 20 Ton
Closed Height ................................................... 7-1/8" ........................................ 9-5/8" ........................................ 7-1/4" ........................................ 10-5/8"
Extension Screw Travel ........................................ 3" ........................................... 3-1/8" ........................................ 1-5/8" ......................................... 2-3/4"
Maximum Height ............................................. 13-5/8" ...................................... 18-1/2" ...................................... 12-1/8" ....................................... 19-5/8"
Power Lift ......................................................... 3-1/2" ........................................ 5-5/8" ........................................ 3-3/8" ......................................... 6-1/4"
Ram Diameter .................................................. 1-5/8" ........................................ 1-5/8" ........................................ 2-1/8" ......................................... 2-1/8"
Base Size ................................................. 6-1/2" by 4-1/8" ........................ 6-1/2" by 4-1/8" ........................ 4-5/8" by 7-1/8"......................... 4-5/8" by 7-1/8"
Weight ........................................................... 14.85 lbs. ................................... 17.38 lbs. ..................................... 20.9 lbs. ..................................... 27.3 lbs.
791-2230 A, 791-2240 A, 791-2290 A, 791-2330 A
SPECIFICATIONS
791-2230 A
791-2290 A
1
ASME PASE-2019
791-2240 A
791-2330 A
04/20/20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 791-2230 A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Napa 791-2230 A

  • Page 1 Ram Diameter ..........1-5/8" ........1-5/8" ........2-1/8" ......... 2-1/8" Base Size ..........6-1/2" by 4-1/8" ......6-1/2" by 4-1/8" ......4-5/8" by 7-1/8"......4-5/8" by 7-1/8" Weight ............14.85 lbs........17.38 lbs........20.9 lbs........27.3 lbs. 791-2230 A, 791-2240 A, 791-2290 A, 791-2330 A 04/20/20...
  • Page 2 If the manual or product labels are lost or not legible, contact NAPA for replacements. If the operator is not fluent in English, the product and safety instructions shall be read to and discussed with the operator in the operator's native language by the purchaser/owner or his designee, making sure that the operator comprehends its contents.
  • Page 3 OPERATING MANUAL & PARTS LIST FOR 791-2230 A, 791-2240 A, 791-2290 A, 791-2330 A BOTTLE JACK SETUP INSTRUCTIONS This is the safety alert symbol used for the SETUP INSTRUCTIONS section of this manual to alert you to potential personal injury hazards.
  • Page 4: Preventative Maintenance

    Authorized Service Centers are recommended. IMPORTANT: In order to prevent seal damage and jack failure, never use alcohol, hydraulic brake fluid, or transmission oil in the jack. Use NAPA hydraulic Jack Oil #765-1541. Every jack owner is responsible for keeping the jack label clean and readable. Use a mild soap solution to wash external surfaces of the jack but not any moving hydraulic components.
  • Page 5 OPERATING MANUAL & PARTS LIST FOR 791-2230 A, 791-2240 A, 791-2290 A, 791-2330 A Not included in model numbers 791-2230 A and 791-2240 A 791-2230 A, 791-2240 A, 791-2290 A, 791-2330 A 04/20/20...
  • Page 6 OPERATING MANUAL & PARTS LIST FOR 791-2230 A, 791-2240 A, 791-2290 A, 791-2330 A Part # for Models: Item# 791-2290 A 791-2230 A 791-2330 A 791-2240 A Description Qty. Body Screw O-Ring Safety Valve Spring Ball Seat Steel Ball RS791FP...
  • Page 7: Especificaciones

    (6-1/2" by 4-1/8") ....(6-1/2" by 4-1/8") ....(4-5/8" by 7-1/8") ....(4-5/8" by 7-1/8") Peso .............6,7 kg (14.85 lbs.) ....7,9 kg (17.38 lbs.) ....9,5 kg (20.9 lbs.) ....12,4 kg (27.3 lbs.) 791-2230 A, 791-2240 A, 791-2290 A, 791-2330 A 04/20/20...
  • Page 8: Información De Advertencia

    Si las etiquetas del manual o producto son ilegibles o no están en su lugar, deberá ponerse en contacto con NAPA para obtenerlas gratis. El comprador/ propietario o una persona designada deberá...
  • Page 9: Instrucciones De Uso

    MANUAL DEL FUNCIONAMIENTO Y LISTA DE PIEZAS PARA 791-2230 A, 791-2240 A, 791-2290 A, 791-2330 A INSTRUCCIONES DE MONTAJE DEL GATO DE BOTELLA Este símbolo indica una alerta de seguridad y se utiliza en la parte de este manual que versa sobre las INSTRUCCIONES DE MONTAJE, con el fin de advertir sobre los peligros de accidentes personales.
  • Page 10: Diagnóstico De Averías

    MANUAL DEL FUNCIONAMIENTO Y LISTA DE PIEZAS PARA 791-2230 A, 791-2240 A, 791-2290 A, 791-2330 A MANTENIMIENTO DE SEGURIDAD Este símbolo indica una alerta de seguridad y se utiliza en la parte de este manual que versa sobre el MANTENIMIENTO DE SEGURIDAD, con el fin de advertir sobre los peligros de accidentes personales.
  • Page 11: Spécifications

    (6-1/2 po by 4-1/8 po) ....(6-1/2 po by 4-1/8 po) ....(4-5/8 po by 7-1/8 po) ....(4-5/8 po by 7-1/8 po) Poids ........... 6,7 kg (14.85 lbs.) ....7,9 kg (17.38 lbs.) ..... 9,5 kg (20.9 lbs.) ..... 12,4 kg (27.3 lbs.) 791-2230 A, 791-2240 A, 791-2290 A, 791-2330 A 04/20/20...
  • Page 12 état et le ranger dans un endroit facilement accessible à tous ceux qui doivent le lire. Si le manuel ou les étiquettes de l'outil sont perdus ou illisibles, communiquer avec NAPA pour obtenir un remplacement. Si l’utilisateur ne parle pas couramment le français, les consignes de sécurité...
  • Page 13: Directives D'utilisation

    MANUEL DE FONCTIONNEMENT ET LISTE DE PIÈCES POUR 791-2230 A, 791-2240 A, 791-2290 A, 791-2330 A DIRECTIVES DE MONTAGE DU CRIC-BOUTEILLE Voici le symbole utilisé dans la section DIRECTIVES DE MONTAGE du présent manuel pour avertir du risque de blessure.
  • Page 14: Entretien Préventif

    MANUEL DE FONCTIONNEMENT ET LISTE DE PIÈCES POUR 791-2230 A, 791-2240 A, 791-2290 A, 791-2330 A ENTRETIEN PRÉVENTIF Voici le symbole utilisé pour dans la section ENTRETIEN PRÉVENTIF du présent manuel pour avertir du risque de blessure. Suivre toutes les directives pour éviter des blessures pouvant être graves ou mortelles.
