- Page 1 11/11/2002 8:37 AM Page 2 IE 6.1 IE 6.2 owner's manual analog and digital systems...
-
Page 2: Table Of Contents
ie_6.1_6.2.qxd 11/11/2002 8:43 AM table of contents introduction cautions about this manual keep listening, but be safe! unpacking placement mounting instructions warnings and tips system configurations speaker connections maintenance troubleshooting audio adjustment specifications warranty information introduction Thank you for purchasing an a/d/s/ bandpass subwoofer system. Please read the following instructions carefully. -
Page 3: Ie_6.1_6.2.Qxd 11/11/2002 8:43 Am
ie_6.1_6.2.qxd 11/11/2002 8:43 AM Page 2 unpacking These subwoofers are heavy. Rather than lifting the unit out of the shipping carton, turn the open carton over, and lift it off the subwoofer. Remove the packing corners from the subwoofer and then remove it from the plastic bag. -
Page 4: System Configurations
ie_6.1_6.2.qxd 11/11/2002 8:43 AM system configurations The ie-series subwoofers are designed to integrate with a wide variety of full range speakers. A typical installation consists of a factory stereo system driving an external amplifier powering the ie-series subwoofer. A more advanced system utilizes separate midrange and hi frequency speakers and multi- channel amplification, such as an a/d/s/ PH30.2 amplifier powering 346is speakers front and rear along with an ie series subwoofer. -
Page 5: Speaker Connections
ie_6.1_6.2.qxd 11/11/2002 8:43 AM speaker connections The ie-series subwoofers have a terminal cup mounted on one end of the speaker enclosure. Connect the positive (+) wire of the amplifier to the red terminal marked (+) of the speaker enclosure. Then connect the negative (-) wire from the amplifier to the black terminal marked (-) of the speaker enclosure. -
Page 6: Audio Adjustment
ie_6.1_6.2.qxd 11/11/2002 8:43 AM audio adjustments Adjust the gain of the subwoofer amplifier to blend in with the midrange and high frequency speakers. If the amplifier powering the ie subwoofer has an electronic crossover, adjust it for the best sound quality. Typical settings are between 50-100Hz. -
Page 7: Warranty Information
ie_6.1_6.2.qxd 11/11/2002 8:43 AM Page 6 warranty information LIMITED TWO YEAR CONSUMER WARRANTY Directed Electronics, Inc. promises to the original purchaser, to replace this product should it prove to be defective in workmanship or material under normal use, for a period of two years from the date of purchase by the dealer as indicated by the date code marking of the product PROVIDED the product was installed by an authorized Directed dealer. - Page 8 front_cover.qxd 11/11/2002 8:37 AM Page 1 Directed Electronics, Inc. All rights reserved G29000/05 09-02...
