BRIGGS & STRATTON CORPORATION
MILWAUKEE, WISCONSIN, U.S.A.
BRIGGS & STRATTON IS A TRADEMARK OF BRIGGS & STRATTON CORPORATION AND IS USED UNDER LICENSE TO ALTON INDUSTRY LTD. GROUP
1/4 in. AIR DIE GRINDER
Operator's Manual
Product Model # 6384-00
Manual # 80018892
Read and understand this
instruction manual thoroughly
before using the product. It
contains important information
for your safety as well as
operating and maintenance
advice.

Advertisement

Table of Contents
loading

Summary of Contents for Briggs & Stratton 6384-00

  • Page 1 1/4 in. AIR DIE GRINDER Operator’s Manual Product Model # 6384-00 Manual # 80018892 Read and understand this instruction manual thoroughly before using the product. It contains important information for your safety as well as BRIGGS & STRATTON CORPORATION operating and maintenance advice.
  • Page 2 Thank you for purchasing this quality-built Briggs & Stratton™ air tool. We are pleased that you’ve placed your confidence in the Briggs & Stratton brand. When operated and maintained according to the instructions in this manual, your Briggs & Stratton air tool will provide reliable service. Where to Find Us You can contact Briggs &...

  • Page 3: General Safety Information

    General Safety Information 3. Always use protective eyewear which provides protection from flying particles from the front and side when using the tool. Ear protectors should also The safety alert symbol is used to identify safety be worn. information about hazards that can result in personal 4.

  • Page 4: Air Supply

    Air die grinder safety instructions 8. A long air hose (usually over 26 ft/8 m) may cause up 1. Always use the die grinder in the manner and for the to 15 PSI/1.1 bar drop in pressure, so you need to set functions described in this manual.

  • Page 5: Technical Specifications

    Technical Specifications COMPONENT SPECIFICATIONS Free speed 22,000 RPM Collet size 1/4 in. (6.35 mm) Avg. air consumption 4.5 CFM/0.3 m³/min Working pressure 90 PSI/6.3 bar Air inlet 1/4 in. (6.35 mm) NPT (F) Air hose 3/8 in. (9.53 mm) (inner diameter) Figure 4 Assembly Instructions 5.

  • Page 6: Troubleshooting

    Operation Instructions Push the lever (A) forward and press down on the trigger (B) to start the tool (D). (See Figure 7) Figure 7 Troubleshooting PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION 1. Grit or gum in the tool. 1. Flush the tool with air tool oil or gum solvent. 2.

  • Page 7: Exploded Diagram And Parts List

    Exploded Diagram and Parts List Description Qty. Description Qty. Part No. Part No. Main housing Rotor Trigger Rotor blade Lever Cylinder Spring Bushing Bolt Front plate Bolt Steel ball O-ring Bolt O-ring Bearing Valve stem Collet holder Spring Fixing ring O-ring Decorating ring Screw nut...

  • Page 8: Limited Warranty

    Briggs & Stratton™ Air Tool Warranty Policy January, 2016 LIMITED WARRANTY Briggs & Stratton™ is a trademark of BRIGGS & STRATTON CORPORATION and is used under license to Alton Industry Co. Ltd® Alton Industry Co. Ltd warrants this Briggs & Stratton brand product for a period of one year from the date of original retail purchase against defects in materials and workmanship.
