- Page 1 WECO Reverse Osmosis Drinking Water Filter System Manual HYDRA Series www.wecofilters.com Water Engineering Corporation Long Beach, CA U.S.A 1 (888) 675-5187 sales@wecofilters.com...
- Page 2 It is recommended to change the 3 pre-filters at least every 6-8 months. It is advised to change them on time to avoid any damages to the RO System. It is advised to use WECO replacement filters. Using ‘non-WECO’ and poor quality filters may clog the RO system and will also damage the membrane.
- Page 3 HYDRA Manual FILTERED WATER MAIN SUPPLY WATER BRINE 5th Stage Filter 6th Stage Filter PRODUCT ALKALINE OR WATER TANK UV SYSTEMS ONLY Product Water AUTO SHUT-OFF VALVE Check Valve Flow Restrictor 4th Stage MEMBRANE INLET 3nd Stage 2nd Stage 1st Stage Feed Water Fig.
- Page 4 HYDRA Manual FILTERED WATER MAIN SUPPLY WATER BRINE 6th Stage Filter ALKALINE OR UV SYSTEMS ONLY PRODUCT 5th Stage Filter WATER TANK Check Valve High-Pressure Flow Restrictor Switch Product Water Inlet Water Solenoid Valve 4th Stage GRO MEMBRANE INLET Low-Pressure PUMP Switch 3nd Stage...
- Page 5 HYDRA Manual FILTERED WATER MAIN SUPPLY WATER BRINE 5th Stage Filter 6th Stage Filter PRODUCT ALKALINE OR WATER TANK UV SYSTEMS ONLY Product Water PERMEATA PERMEATA AUTO SHUT-OFF Check Valve VALVE Flow Restrictor BRINE BRINE 4th Stage GRO MEMBRANE INLET INLET 3nd Stage 2nd Stage 1st Stage...
-
Page 6: Installation Instructions
HYDRA Manual INSTALLATION INSTRUCTIONS Tapping into the cold water line (Using the water supply adapter model FW 1) NEEDLE VALVE NOTE: The drinking water system must be connected to the COLD water supply only. 1. Turn off the cold water supply to the sink faucet by locating the Round or oblong handle on the right side of the sink cabinet and Turning clockwise until the water supply is off. -
Page 7: Mounting The Faucet
HYDRA Manual Mounting the faucet Your unit comes complete with a long reach faucet. NOTE: Air gap option installation instructions are available upon request. The following instructions is for non-air gap option. 1. Slide chrome cover plate and rubber gasket onto stem of faucet and place faucet onto sink with the stem going through the hole. -
Page 8: Positioning The System
HYDRA Manual 3. Make sure to align drain saddle to drilled hole. Attach drain clamp to drain pipe and tighten the two screws evenly. (Fig. # 9) NOTE: The center hole on the sponge must be removed. 4. Connect the Black tubing to the drain clamp. Fig. -
Page 9: Start-Up Procedure
We thank you for purchasing our Reverse Osmosis / Nanofiltration unit for your high quality processed drinking water. In order to maintain this high quality water, it is important that scheduled maintenance be followed. RECOMMENDED SYSTEM MAINTENANCE To properly maintain your WECO drinking water system, please use only genuine WECO water replacement filters at www.wecofilters.com... - Page 10 HYDRA Manual Sediment Pre-filter: The pre-filter protects the system and should be maintained regularly, a clear housing has been provided for your convenience. The show-white pre-Filter should be changed when the outside discolors to a cardboard brown color and before the inner surface discolors.
-
Page 11: Changing The Membrane
HYDRA Manual CHANGING THE PRE-FILTERS 1. Turn OFF cold water supply to RO system. Turn OFF tank’s ball-valve. Lift up RO faucet lever briefly to relief the built-up pressure inside the RO system. This will make opening the housings easier. 2. -
Page 12: Operating Limits
HYDRA Manual OPERATING LIMITS Water Water Max. TDS pH Range Temperature Pressure Standard 2000 ppm 40 - 85 F 2 - 11 45 - 85 PSI RO System RO with 2000 ppm 40 - 85 F 2 - 11 45 - 85 PSI Booster Pump MEMBRANE PERFORMANCE HYDRON Membrane Technology Membrane Elements... -
Page 13: Testing Conditions
HYDRA Manual Membrane Type Polyamide Composite Testing Conditions Testing Pressure 60 psi (0.41Mpa) (4.1 BAR) Temperature of Testing Solution 75°F (25°C) Concentration of Testing Solution (NaCl) 250ppm pH Value of Testing Solution Recovery Rate of Single Membrane Element Extreme Operating Conditions Max. - Page 14 HYDRA Manual FLOW TW-1812 This Membrane is Tested and Certified by NSF International A = 10.06” (255.5 mm) D = 0.8125” (20.63 mm) against NSF / ANSI Standard 58 B = 1.796” (45.61 mm) E = 11.68” (296.7 mm) for material requirements only. C = 0.687”...
- Page 15 HYDRA Manual This page is intentionally left blank © 2017 Water Engineering Corporation...
- Page 16 WECO HYDRA Series Reverse Osmosis Drinking Water Filter System Manual WECO www.wecofilters.com Water Engineering Corporation Long Beach, CA U.S.A 1 (888) 675-5187 sales@wecofilters.com...
