TITANIUM-SERIES
AMPLIFIERS
OWNER'S MANUAL
GZTA 1.800DX-II
GZTA 1.1200DX-II
•
1 Ohm stable
•
Linkable 2 Ohm
•
Mosfet power supply
•
Power and protection indicator
•
Variable 12dB Bass boost (45Hz)
•
Phaseshift 0 / 180° (Switch)
•
Variable Subsonic
•
Variable Lowpass
•
Adjustable input sensitivity
•
Soft delayed remote turn on
•
Stereo RCA output
•
Bass remote control
•
Thermal / Short / Overload protection
Features
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ground Zero TITANIUM SERIES
Summary of Contents for Ground Zero TITANIUM SERIES
- Page 1 TITANIUM-SERIES AMPLIFIERS OWNER’S MANUAL GZTA 1.800DX-II GZTA 1.1200DX-II Features • 1 Ohm stable • Linkable 2 Ohm • Mosfet power supply • Power and protection indicator • Variable 12dB Bass boost (45Hz) • Phaseshift 0 / 180° (Switch) • Variable Subsonic •...
-
Page 2: Planning Your System
Tools and materials you need • Screwdriver • Electric drill, 3 mm / 0.12” carbide drill bit • Mounting screws • Power wire min. 25 mm² / 4AWG • Ground wire min. 25 mm² / 4AWG • Speaker wire min. 2 x 2,5 mm² / 13AWG Please note •... - Page 3 Warning Chose a mounting position where all electric wires are protected from being damaged by sharp edges, heat or other conditions. +12Volt DC electrical connections must be fused on the battery side. Make sure your radio and all other devices will be turned off while connection your system.
- Page 4 Controls and functions – GZTA 1.1200DX-II...
-
Page 5: Controls And Functions
Controls and functions Speaker terminals For connection of the subwoofer GND -> Ground connection Power terminals REM -> Remote antenna terminal BATT -> +12 Volt GREEN – OK Satus indication RED – Error Terminal for connection of the RCA wires. Cinch inputs To avoid failure, please use high quality RCA wires. - Page 6 Stereo wiring – GZTA 1.800DX-II...
- Page 7 Master & slave wiring – GZTA 1.800DX-II...
- Page 8 Master & slave wiring – GZTA 1.800DX-II...
- Page 9 Stereo wiring – GZTA 1.1200DX-II...
- Page 10 Master & slave wiring – GZTA 1.1200DX-II...
- Page 11 Master & slave wiring – GZTA 1.1200DX-II...
-
Page 12: Specifications
Specifications Model GZTA 1.800DX-II GZTA 1.1200DX-II Type 1 Channel Class D 1 Channel Class D RMS Power @ 4 Ω 1 x 350 W 1 x 400 W (1% THD+N) (1% THD+N) 1 x 450 W 1 x 500 W (10% THD+N) (10% THD+N) CEA Standard CEA-2006-A... -
Page 13: Troubleshooting Guide
Trouble shooting guide Symptoms Check Points Cure Check fuses in amplifier. Be sure remote lead is connected. Is the POWER LED illuminated? Check signal leads. Check again control. No sound Check tuner/deck volume level. Check for speaker short or amplifier Is the diagnostic LED illuminated? overheating No power to the amplifier... - Page 14 We reserve the right to make needed change or improvement to the product without informing customer about this in advance. De Garantie bepalingen van alle door ground zero geleverde producten is volgens wettelijke bepalingen geregeld, Een retourzending kan alleen na duidelijke afspraak en in de originele verpakking plaatsvinden.SVP een aankoopbon en een duidelijke storingsomschrijving bijvoegen.Van garantie uitgesloten zijn defecten door...
