Vetra ViewSplice VIP- 882-V Series User Instruction

User Instruction for
the VIP- 882-V Series "ViewSplice"    
Video Splitter/Multiplexer
FEDERAL COMMUNICATIONS COMMISSION
This equipment has been tested and found to comply with the limits of a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when equipment is operated in
a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at their expense.
CE
This equipment has been tested and found to conform to the directives and standards for a Class A Information Technology
Equipment type and for the Commercial Light Industrial equipment class.

INTRODUCTION

The VIP-882-V, VIP-882-V2, VIP-882-V3, and VIP-882-V4 "ViewSplice"  Video Splitters allow 2, 4, 6, or 8 monitors to be
connected to one PC for simultaneous viewing of up to four separate images on two monitors for each video port on the PC.

INSTALLATION

1. Connect PC to Video Splitter unit:
Connect the video output of the PC to the Video Splitter using a HDD15 male/female extension cable. Connect the male
connector of the extension cable to the PC's video port. Connect the female connector of the same cable to the back panel
connector of the Video Splitter marked "TO PC VIDEO".
Or in the case of the V2, V3, and V4 series ViewSplice
Connect Pc's Monitor A video output to the back panel connector of the Video Splitter marked "PC MON A" and connect the
PC's Monitor B, C, and D video outputs to the back panel of the Video Splitter marked "PC MON B", "PC MON C", and "PC
MON D".
2. Connect Monitors to the Video Splitter:
Connect one monitor to the back panel connector of the Video Splitter marked "STA-1 MON". Connect the second monitor to
the other backpanel connector marked "STA-2 MON".
Or in the case of the V2, V3, and V4 series ViewSplice
Connect one set of monitors to the back panel of the Video Splitter marked "STA-1 MON A', "STA-1 MON B", STA-1 MON C',
and "STA-1 MON D", Connect the other set of monitors to the back panel of the Video Splitter marked "STA-2 MON A", "STA-
2 MON B", "STA-2 MON-C", and "STA-2 MON D".
3. Connect the Power Supply to the Video Splitter:
The Video Splitter is powered by an external wall plug-in supply the VIP-210 +5 Vdc 1 A. First plug the power output plug of
this external supply into the mating jack on the front panel of the Video Splitter marked "+5VDC", and only then plug the
supply into a suitable AC power source.
