Summary of Contents for D-Link WNA-1330
-
Page 2: System Requirements
802.11g or 802.11b wireless adapter (for Ad-Hoc networking mode.) Package Contents D-Link WNA-1330 Wireless Cardbus Adapter If any of the above items are missing, please contact your reseller. D-Link WNA-1330 Quick Install Guide Manual, software, and warranty on CD... -
Page 3: Hardware Overview
Hardware Overview Activity LED A blinking light indicates data is being transmitted. Link LED A steady light indicates a connection to a wireless network. D-Link WNA-1330 Quick Install Guide... -
Page 4: Wireless Installation Considerations
Wireless Installation Considerations The D-Link wireless adapter lets you access your network using a wireless connection from virtually anywhere within the operating range of your wireless network. Keep in mind, however, that the number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass through, may limit the range. -
Page 5: Adapter Installation
Warning: Do NOT install the WNA-1330 Cardbus Adapter into your computer before installing the driver software from the D-Link CD. Turn on the computer and Insert the D-Link WNA-1330 Driver CD in the CD-ROM drive. The step-by-step instructions that follow are shown in Windows XP. - Page 6 Click Next to continue. By default setup will install to the default location: C:\Program Files\ Wireless G WNA-1330, where C: represents the drive letter of your hard drive. To install to a different location click Browse and specify the location.
- Page 7 If you are using Windows XP (SP), ® you will have the option to use either the D-Link utility or the built-in Windows ® Wireless utility. Click Next to continue. Insert the adapter into an available Cardbus slot on your computer.
- Page 8 WEP key or WPA-PSK passphrase. Click Next to continue. Click Finish to continue. If you are prompted to reboot your computer, select Yes, I want to restart my computer now. D-Link WNA-1330 Quick Install Guide...
-
Page 9: Connect To A Wireless Network
The utility provides the user an easy interface to change any settings related to the wireless adapter. After you have completed the installation of the WNA-1330 and whenever you start the computer, the Configuration Utility starts automatically and the system tray icon is loaded in the toolbar. - Page 10 If the network you are connecting to is using WEP, enter the WEP key for the network and click OK. If the network you are connecting to is using WPA-PSK, enter the passphrase for the network and click OK. D-Link WNA-1330 Quick Install Guide...
-
Page 11: Windows ® Xp Configuration Utility
XP users may use the built-in wireless utility. The following ® instructions are for Service Pack 2 users. If you are using Windows 2000, you must use the D-Link utility. ® Please refer to page 9. If you receive the Wireless... - Page 12 Click on a network and click the Connect button. Refer to the Wireless Security section in the manual for information on connecting to a secure network. If you want to use the D-Link utility instead of the Windows ® wireless utility, refer to the next page.
- Page 13 Disabling The Windows XP Utility ® If you want to use the D-Link wireless utility you must disable the Windows XP wireless utility. ® Right-click on the wireless computer icon in your system tray (lower right corner next to the time). Select View Available Wireless Networks.
- Page 14 In the Wireless Network Connection Properties window, uncheck Use Windows to configure my wireless network settings and then click OK. You can now use the D-Link Wireless Utility to configure your wireless adapter. D-Link WNA-1330 Quick Install Guide...
- Page 15 Notes D-Link WNA-1330 Quick Install Guide...
-
Page 16: Technical Support
Copyright ©00 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, the D-Link logo are registered trademarks of D-Link Corporation or its subsidiaries in the United States and other countries. Other trademarks are the property of their respective owners. Maximum wireless signal rate based on IEEE Standard 0.11g specifications. Actual data throughput will vary.
