- Page 2 Safety Guide ................... 3 Your new 7” Video Screen ..............4 Setting Up ....................5 Overview ....................5 Formatting ....................6 Remote Control ..................7 Programming ..................8 Technical Information ................9 Technical Drawings ................10...
- Page 3 • For disposal of old electrical equipment please follow the guidelines associated with your country/territory or ship the unit back to blackbox-av and we will dispose/recycle the unit. The symbol on the left indicates that this product shall not be treated as household waste.
- Page 4 The open frame design allows it to be easily mounted with signage or other such installations. It can be looping or use up to 8 activation buttons. The 7VS is supplied with 2 Mountable Speakers.
- Page 5 ‘Programming’ for information on how to headphones and amplifiers. program your USB or SD Card. The 7VS is built with 4 fixing holes for If you wish to use button activated content easy mounting (two on either side). then attach the required number of buttons using the button wires (supplied) to the appropriate button inputs.
- Page 6 Before putting the content onto either a USB or SD Card it needs to be in the right format as listed below. Your storage medium must be formatted to FAT32. Below are the file type requirements. Category Codec/FourCC Max Res Max Bitrate MPEG4 800x480...
- Page 7 To access the menu press the ‘setup’ button, press this again to exit. If the 7VS is playing content you may need to press the ‘stop’ button before entering the setup menu, otherwise a number of options might be greyed out and unable to be accessed.
- Page 8 Once you have edited and converted your content into the correct format you will need to put these on USB or SD Card. The file names of your content will determine how it is activated. The USB or SD Card will be pre- programmed with a template, when loading your content make sure to delete these files.
- Page 9 0.8Kg 254 x 222 x 100 mm 197 x 109 x 27.20 Fixing Wings, 45 x 75mm VESA Sample Rate: 8-320KHz, Bitrate: 32- 448Kbps SDHC or USB Video: .MP4, Audio: .MP3, Images: .JPG Still Picture: up to 8000 x 8000px, Video: 1024 x 600 U45°/D50°/L45°/R50°...
- Page 10 Front 181.50 Bottom...
