Summary of Contents for Albixon LED-P100
- Page 1 POOL LIGHT LED-P100 (12V/8W) INSTALLATION AND USER GUIDE VERZE 13. 11. 2017 / REVIZE: 13. 11. 2017...
- Page 2 • The mounting bracket must be properly installed in a way that the top edge of the light lens is at least 45 cm under the water level in the pool, see picture 1. / Pool light LED-P100 (12V/8W)
- Page 3 10. The secure attachment of the light to the console is ensured by turning on the safety system, see picture 4. 11. The light must be connected to a 12V safety transformer. Pool light LED-P100 (12V/8W) /...
- Page 4 Do not mount on irregular or uneven surface Mount on flat surface Mount on walls with a radius that is not less than 1.83 m when viewed from above Open position Closed position PIC. 2 PIC. 3 PIC. 4 / Pool light LED-P100 (12V/8W)
- Page 5 O-ring seal body screw screw lamp holder bracket for attachment to the wall cable insulated connections to terminals insulated connections to terminals Pool light LED-P100 (12V/8W) /...
- Page 6 Incorrect installation poses a hazard that could result in serious injury, death or damage to property. Before servicing the light, disconnect the power supply from the circuit breaker. Failure to follow these guidelines could result in serious injury, death or damage to property. / Pool light LED-P100 (12V/8W)
- Page 7 Notes Pool light LED-P100 (12V/8W) /...
- Page 8 Thank you for using ALBIXON products ALBIXON export@albixon.com www.ALBIXON.com Note that the photos used in the manual are illustrative only. Printing and typesetting errors reserved.
