MODEL NAME: AC1B0HGAN
Read the following safety cautions for your safety.
Please read the following safety matters for your safety. This User's Manual describes circumstances that may
inflict injury onto drivers and others with the following notations (Warning, Caution, Notice, Information).
Notations used within this User's Manual
Safety
Warnings
Failure to observe the safety instructions within this category could result in serious injury or death.
Safety
Cautions
Failure to observe the safety instructions within this category could result in accident related injuries or damage to the vehicle.
WARNING
• Possible Serious Injury or
Death
• Failure to observe safety
instructions in the 'Warning"
category could result in
serious injury or death.
CAUTION
• Possible Moderate or Minor
Injury
• Failure to observe safety
instructions in the "Caution"
category can result in
moderate or minor injury.
Information
• Additional information tips
and instructions are indicated
by this symbol (international
symbol for information).
NOTICE
• Possible vehicle damage
Failure to observe instructions
in the "Notice" category
could result in damage
to the vehicle.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC1B0HGAN and is the answer not in the manual?

Questions and answers

Related Manuals for Hyundai Mobis AC1B0HGAN

Summary of Contents for Hyundai Mobis AC1B0HGAN

  • Page 1 MODEL NAME: AC1B0HGAN Read the following safety cautions for your safety. Please read the following safety matters for your safety. This User's Manual describes circumstances that may inflict injury onto drivers and others with the following notations (Warning, Caution, Notice, Information).

  • Page 2: Before Use

    Before Use Thank you for purchasing this Audio System. iPod ® ® iPod This user's manual explains how to use the Audio System. is a registered trademark of Apple Inc. Before using the product, read the contents of this user's manual carefully and use this product safely.
  • Page 3 시작하기 전에 Basic Thank you for purchasing this Audio System. iPod ® ® iPod This user's manual explains how to use the Audio System. is a registered trademark of Apple Inc.  Warnings and Cautions Before using the product, read the contents of this user's manual carefully and use this product safely.

  • Page 4: Warnings And Cautions

    1 Basic Warnings and Cautions Safety Cautions Safety Warnings Operating the device while driving could lead to accidents due to a lack of attention to external surroundings. First park the vehicle before operating the device. Do not stare at the screen while driving. Staring at the screen for prolonged periods of time could lead to traffic accidents.

  • Page 5: Component Names And Functions

    asic Component Names and Functions Name Description • In Radio mode, saves a frequency or receives saved frequencies Preset/ Repeat · Head Unit • In MEDIA mode, press the [1] key to repeat and [2] key to play in Random random order (shuffle) EJECT Press to insert or eject disc...
  • Page 6 1장 기본 스티어링 리모트 컨트롤 Name Description • Each time this key is pressed, the mode is changed in order of FM1→ FM2→ AM→ XM1→ XM2 → XM3 → USB or iPod→AUX My Music →BT Audio. • If the media is not connected or a disc is not inserted, [MODE] corresponding modes will be disabled.
  • Page 7  Change Radio / Media Mode  FM/AM Mode  HD Radio Mode  XM Radio Mode  Audio CD Mode  MP3 CD Mode  USB Mode  iPod Mode  AUX Mode  My Music Mode  Bluetooth® Audio Mode...
  • Page 8 2 AV Change Radio/Media Mode Change Radio Mode Change Media Mode Pressing the [MEDIA] key will change the Pressing the [RADIO] key will change the operating mode in order of CD  USB(iPod) operating mode in order of FM1 → FM2 → AM ...

  • Page 9: Basic Mode Screen

    2 AV FM/AM Mode Basic Mode Screen 12:05 Name Description Mode Displays currently operating mode Display Frequency Currently playing frequency Preset Displays currently playing preset number [1] ~ [6] 87.5 MENU Displays Radio menus Preset Displays saved presets  MENU Info Displays broadcast information 12:05...

  • Page 10: Hd Radio Mode

    2 AV HD Radio Mode Basic Mode Screen 12:05 Name Description Mode Display Displays currently operating mode  Album Name Frequency Currently playing frequency  Artist Name Preset Displays currently playing preset number [1] ~ [6]  Song Title MENU 87.6 KWVEEE HD Displays Radio menus...
  • Page 11 2 AV XM Radio Mode Basic Mode Screen Name Description 12:05 Displays currently operating mode Mode Display  Category Name Channel Displays the category, channel number, Information channel name, artist and title information 　 194. Channel Name Displays currently playing preset number [1] ~ Preset ...

  • Page 12: Selecting Presets

    2 AV Using Auto Store Selecting Presets Press the [MENU] key ▶ Select [Preset] Press the [SEEK(<)],[TRACK(>)] keys to play the previous/next frequency. 12:05 Using TUNE 91.3 Press the [Tune(Up)], [Tune(Down)] keys 87.6 KWVEEE  MENU to select the frequency. 1 Preset 2 Info 3 HD ▶...

  • Page 13: Saving Presets

    2 AV Saving Presets Scan 12:05 12:05 SCAN 87.5 1 4 104.1 91.3 88.1 88.1 2 5 108.1 98.1 3 6 104.1  MENU  MENU After selecting frequency ▶ Press and Press the [SCAN] key to scan all radio frequencies.
  • Page 14 2 AV HD Radio Technology Listening to HD Radio Stations Changing HD stations HD Radio Technology is a digital radio 12:05 technology used by AM and FM radio station to transmit audio and data via a  Album Name digital signal in conjunction with their ...
  • Page 15 2 AV NOTE: XM Radio Mode • If you are driving on a mountain road where is the signal blocked by mountains. There may be other unforeseen circumstances leading to reception problems with the XM™ satellite radio signal Features of your vehicle Satellite of your vehicle You may experience difficulties in receiving XM™...

  • Page 16: Using Seek

    2 AV Using Seek Selecting Presets Saving Presets Press the [MENU] key ▶ Select [Preset] Press the [SEEK(<)],[TRACK(>)] keys to 12:05 play the previous/next channel. 12:05 ❈ If the “Category” icon is displayed,  Category Name 1 77 1 4 103 channels are changed within the current 　...
  • Page 17 2 AV Scan 12:05 SCAN  Category Name 　 194. Channel Name  1-888-539-SIRIUS  1-888-539-SIRIUS  MENU Press the [SCAN] key to scan all channels with superior reception for 5 seconds each. Once scan is complete, the previously played channel will be restored. During Scan, pressing the [SCAN] key again will cancel the scan operation and restore the previously played channel.

  • Page 18: Audio Cd Mode

    2 AV Audio CD Mode Precautions upon handling discs • This device has been manufactured to be compatible with • The use of CD-R/CD-RW discs attached with labels may software bearing the following logo marks. result in disc slot jams or difficulties in disc removal. Such discs may also result in noise while playing.

  • Page 19: Mp3 File Information

    2 AV MP3 File Information Supported Audio Formats 2. Sampling Frequencies (Hz) • MPEG1 MPEG2 MPEG2.5 ISO 9660 Level 1 File 44100 22050 11025 32000 ISO 9660 Level 2 System 48000 24000 12000 44100 Romeo / Juliet (128문자) 3000 16000 8000 48000 MPEG1 Audio Layer3...
  • Page 20 2 AV Compatibility by Disc Type • 3. When naming files with MP3/WMA file extensions, write 1. Playing MIXED CDs: First plays the audio CD, then plays the using only Korean and English. (Languages other than compressed file(s), Korean and English are not supported and are displayed as 2.
  • Page 21 2 AV Basic Mode Screen Name Description Mode Displays currently operating mode Operation From Repeat/Shuffle/Scan, displays the State currently operating function Track Displays information about the current track Information Play State Displays the play/pause state Displays the current play time and total play Play Time time MENU...

  • Page 22: Changing Tracks

    2 AV Play/Pause Changing Tracks Selecting from the List Once an audio CD is inserted, the mode Press the [SEEK(<)], [TRACK(>)] keys to Press the [Tune(Up)], [Tune(Down)] keys will automatically start and begin playing. to search and select for the desired track. change tracks.

  • Page 23: Audio Cd Menu

    2 AV List Scan Audio CD Menu Press the [SCAN] key to play the first 10 Press the [MENU] key ▶ Select [List] If you press the [MENU] key, you will have seconds of each track. access to the Repeat, Shuffle, List and Info features.

  • Page 24: Folder Name

    2 AV MP3 CD Mode Basic Mode Screen Name Description 12:05 Mode Displays currently operating mode REPEAT FILE Operation From Repeat/Shuffle/Scan, displays the currently State operating function.  Folder name File Index Displays the total number of files  File name_01 File Info Displays information about the current file Play State...

  • Page 25: Selecting Mp3 Files

    2 AV Play/Pause Selecting MP3 files Rewinding / Fast-forwarding Files • Once an MP3 disc is inserted the mode Press the [SEEK(<)], [TRACK(>)] keys to While playing, press and hold the will automatically start and being playing. select the previous or next file. [SEEK(<)], [TRACK(>)] keys (over 0.8 seconds) to rewind or fast-forward the current file.
  • Page 26 2 AV Shuffle Play Information MP3 CD Menu If you press the [MENU] key, you will have Press the [MENU] key ▶ Select [Shuffle] Press the [MENU] key ▶ select [Info] access to the Repeat, Shuffle, List, Info and Copy features. Each time the button is pressed, the Details for the currently playing file are feature changes in order of Shuffle Folder...

  • Page 27: Copying Files

    2 AV Copying Files Press the [MENU] key ▶ select [Copy] The currently playing file is copied into My Music. Information • Selecting another feature while copying is in progress will display a pop- up asking whether you wish to cancel copying.

  • Page 28: Usb Mode

    2 AV USB Mode Before playing a USB MP3 • Do not use the USB I/F to charge • Some USB devices may not be • Connect the USB device after turning on batteries or USB accessories that the engine. The USB device may become supported due to compatibility issues.
  • Page 29 2 AV • The device may not support normal operation when using formats such as HDD Type, CF, or SD Memory. • The device will not support files locked by DRM (Digital Rights Management.) • USB memory sticks used by connecting an Adaptor (SD Type or CF Type) may not be properly recognized.
  • Page 30 2 AV Basic Mode Screen Name Description 12:05 Mode Displays currently operating mode REPEAT FILE Operation From Repeat/Shuffle/Scan, displays the currently  Folder name State operating function.  File name_01 File Index Displays the total number of files File Info Displays information about the current file 00:01 Play State...

  • Page 31: Changing Files

    2 AV Play/Pause Changing Files Rewinding / Fast-forwarding Files Once a USB is connected, the mode will While playing, press and hold the [Press the [SEEK(<)], [TRACK(>)] keys to automatically start and begin playing. [SEEK(<)], [TRACK(>)] keys (over 0.8 select the previous or next file. seconds) to rewind or fast-forward the 12:05 current file.
  • Page 32 2 AV Shuffle Play Information USB Menu Press the [MENU] key ▶ Select [Shuffle] If you press the [MENU] key, you will have Press the [MENU] key▶ Select [Info] access to the Repeat, Shuffle, List, Info Each time the button is pressed, the and Copy features.
  • Page 33 2 AV Copying Files Press the [MENU] key ▶ Select [Copy] The currently playing file is copied into My Music. Information • Selecting another feature while copying is in progress will display a pop-up asking whether you wish to cancel copying. To cancel, select 'Yes'.

  • Page 34: Ipod Mode

    iPod Mode Using iPod Devices • In order to play the iPod by operating the • Skipping or improper operation may occur iPod is a registered trademark of Apple Inc. keys, you must use the dedicated iPod cable depending on the characteristics of your •...
  • Page 35 2 AV Basic Mode Screen Name Description 12:05 iPod Mode Displays currently operating mode REPEAT 1/10000 Operation From Repeat/Shuffle, displays the currently  Album Name State operating function  Artist Name Song Index Displays current song/total songs  Song Title 01 Song Displays information about the current file Information...
  • Page 36 2 AV Changing Songs Searching Categories Play/Pause Once an iPod is connected, the mode will [Press the [SEEK(<)], [TRACK(>)] keys to Press the [Tune(Up)], [Tune(Down)] keys automatically start and begin playing. select the previous or next file. to search categories and press the [OK] key to select.
  • Page 37 2 AV Category Menu Information iPod Menu •If the search mode is accessed while If you press the [MENU] key within the playing a song, the most recently If you press the [MENU] key, you will have Category Menu, you will have access to access to the Repeat, Shuffle and List searched category is displayed..

  • Page 38: Aux Mode

    2 AV AUX Mode Connecting an External Device Press the [MEDIA] key ▶ Select [AUX] Caution • Connecting a connector jack to the AUX terminal without an external device will convert the system to AUX mode, but only output noise. When an external device is not being used, also remove the connector jack.

  • Page 39: My Music Mode

    2 AV My Music Mode Basic Mode Screen Name Description My Music 12:05 Mode Displays currently operating mode REPEAT Operation FILE From Repeat/Shuffle/Scan, displays the currently State operating function.  Artist File Index Displays the total number of files  File name_01 File Displays information about the current file...
  • Page 40 2 AV Rewinding / Fast-forwarding Files Changing Files Play/Pause [Press the [SEEK(<)], [TRACK(>)] keys to 12:05 My Music While playing, press and hold the select the previous or next file. [SEEK(<)], [TRACK(>)] keys (over 0.8 REPEAT 1/100 seconds) to rewind or fast-forward the ...

  • Page 41: My Music Menu

    2 AV My Music Menu Information Play Information • The [1], [2] keys are shortcut keys to If you press the [MENU[ key, you will have set the Repeat and Shuffle features. access to the Repeat, Shuffle, List, Info Press the [MENU] key ▶ Select [Info] and Delete features.
  • Page 42 2 AV List Menu Use [Tune(Up)], [Tune(Down)] and the From the List screen ▶ Press [MENU] ▶ [OK] key to search and select files you want to delete and press the [Delete] Select [Edit] button from the Menu. Files saved in My Music can be selected 12:05 My Music and deleted.

  • Page 43: Bluetooth® Audio Mode

    2 AV Bluetooth® Audio Mode About Using Bluetooth® Audio Bluetooth® Audio Mode can be used only when a Bluetooth® phone has been connected. While Bluetooth® Audio is playing, if the Bluetooth® phone is connected, then the music will also stop. Bluetooth®...

  • Page 44: Using Bluetooth® Audio

    2 AV Using Bluetooth® Audio While playing, press the [OK[ key to pause the file being streamed from the Press the [MEDIA] key ▶ Select [BT Bluetooth phone. Audio] Information 12:05 The play/pause feature may operate Media differently depending on the mobile phone.
  • Page 45 Bluetooth®  About Using Bluetooth  Pairing from the Bluetooth® Device  Setting Bluetooth ® Connection Using Bluetooth  Using Bluetooth...

  • Page 46: Using Bluetooth Handsfree

    3 Bluetooth® About Using Bluetooth Using Bluetooth Handsfree Precautions for safe driving Bluetooth® Handsfree is a feature that enables drivers What is Bluetooth®? to practice safe driving. Connecting the head unit with a Bluetooth® phone allows the user to conveniently make calls, receive calls, and manage the phone book.

  • Page 47: Cautions Upon Connecting Bluetooth® Phone

    3 Bluetooth® Cautions upon connecting Bluetooth® phone The Handsfree call volume and quality may differ depending on the mobile phone. Before connecting the head unit with the mobile phone, check to see • Bluetooth® features supported within the vehicle are as follows. that the mobile phone supports Bluetooth®...
  • Page 48 3 Bluetooth® Pairing from the Bluetooth® Pairing [PHONE] Key / [] Key on the Steering Remote Controller 2. From your Bluetooth® device, search for Device the car name and pair the device. When searching from the Bluetooth® device, the default passkey is ‘0000’. When no phones have been paired What is Bluetooth Device Pairing? 3.
  • Page 49 3 Bluetooth® Pairing through [PHONE] Setup From your mobile phone, search for the car When Pairing Additional Devices audio system. The initial passkey is “0000”. Once pairing is complete, the following screen 1. If you already have a paired device but Press the [SETUP] key ▶...

  • Page 50: Setting Bluetooth® Connection

    3 Bluetooth® Setting Bluetooth® Connection Press the [SETUP] key ▶ Saelect Name Description [Phone] ▶Select [Paired Phone List] 1. Paired Device that is paired but Connecting a Device Phone not connected Setup 12:05 Press the [SETUP] key ▶ Select [Phone] 2.

  • Page 51: Disconnecting A Device

    3 Bluetooth® Disconnecting a Device Deleting a Device Information • Upon deleting the currently connected Press the [SETUP] key ▶ Select [Phone] Press the [SETUP] key ▶ Select [Phone] Bluetooth device, the connection will ▶Select [Paired Phone List] ▶ Select [Paired Phone List] automatically be disconnected to delete.

  • Page 52: Using Bluetooth

    3 Bluetooth® Calling by dialing a number Information Using Bluetooth • If you select the [Call History] button in a Press the [PHONE] key ▶ Select [Dial Phone Menu Screen state where there is no call history, a Number] prompt screen asking whether to download call history is displayed.

  • Page 53: Answering A Call

    3 Bluetooth® Answering Calls Answering a Call During a Handsfree Call Information • When the incoming call pop-up is Answering a call with a Bluetooth device displayed, most functions within AV mode Phone 12:05 connected will display the following and Setup will not operate. Only the call screen.

  • Page 54: Call History

    3 Bluetooth® Call History Contacts Information • Up to 20 outgoing, incoming, and missed Press the [PHONE] key ▶ Select Press the [PHONE] key ▶ Select [Call call history lists can each be saved [Contacts] • Upon downloading call histories, History] previously saved histories will be deleted.
  • Page 55 3 Bluetooth® Information • Up to 1,000 contacts can be copied into car contacts. • Upon downloading contacts , previously saved contacts will be deleted. • Downloading is not possible if the contacts download feature is turned off within the Bluetooth device. Also, some devices may require device authorization upon attempting to download.
  • Page 56 Voice Recognition  Before Using Voice Recognition  Using Voice Recognition  Command List...

  • Page 57: Voice Recognition

    4 Voice Recognition Before Using Voice Recognition Phone related voice commands can be used only when a When using the voice recognition feature, only commands Bluetooth device is connected. listed within the user's manual are supported. When making calls by stating a name, the corresponding Be aware that during the operation of the voice recognition contact must be downloaded and stored within the audio system, pressing any key other than the [VR] key or...

  • Page 58: Using Voice Recognition

    4 Voice Recognition Using Voice Recognition Information Re-starting Voice Recognition • If voice recognition is in [Expert Mode], then the system will only say a “Beep~” Starting Voice Recognition While system waits for a command ▶ • To change the Normal Mode/Expert Shortly press the [VR] key on the steering Mode setting, go to [SETUP] ▶...

  • Page 59: Ending Voice Recognition

    4 Voice Recognition Ending Voice Recognition Illustration on Using Voice Recognition While Voice Recognition is operating ▶ Starting Voice Recognition Ending Voice Recognition Press and hold the [VR] key on the steering remote controller (over 0.8 seconds) Please say a command DING~ Information Please say a command...

  • Page 60: Voice Command List

    4 Voice Recognition Voice Command List • Common Commands: Commands that can be used in all Commands Function situations. (However, some commands may not operate in special circumstances. • When listening to the radio, displays the next radio screen. (FM1→FM2→AM→XM1→XM2→XM3→FM1) Radio •...
  • Page 61 4 Voice Recognition Commands Function Commands Function AUX (Auxiliary) Media Moves to the most recently played media screen. Plays the connected external device. Plays the music saved in connected Bluetooth® If a music CD has been inserted， plays the Bluetooth Audio Play Track 1-30 device.
  • Page 62 4 Voice Recognition FM/ AM radio commands: Commands that can be used Satellite radio commands: Commands that can be used • • while listening to Satellite Radio. while listening to FM，AM radio. Commands Function Commands Function Preset 1-6 Channel Up Plays the broadcast saved in Preset 1-6.
  • Page 63 4 Voice Recognition MP3 CD / USB commands : Commands that can be used Audio CD commands : Commands that can be used while • • listening to Audio CD. while listening to music files saved in CD and USB. Commands Function Commands...
  • Page 64 4 Voice Recognition iPod Commands : Commands that can be used while iPod Commands : Commands that can be used while • • playing iPod playing iPod Commands Function Commands Function Shuffle Randomly plays all saved files. Shuffle Randomly plays the songs within the current category. Shuffle Off Cancels random play to play files in sequential order.
  • Page 65 4 Voice Recognition ® Bluetooth Wireless Technology Audio Commands : • Commands that can be used while playing Phone Music. Commands Function Play Plays the currently paused song. Pause Pauses the current song.
  • Page 66 Setup  Setup  Using Setup...
  • Page 67 5 Setup Setup Basic Mode Screen Name Description Display Sets display related settings Sound Sets sound related settings Clock Sets clock/Calendar related settings /Calendar Phone Sets phone related settings System Sets system related settings...

  • Page 68: Using Setup

    5 Setup Display Settings Using Setup Mode Pop Up Starting Mode Adjusting the Display Press the [SETUP] key ▶ Select [Display] ▶ Select [Mode Pop up] Press the [SETUP] key to display the Press the [SETUP] key ▶ Select [Display] Setup screen.

  • Page 69: Text Scroll

    5 Setup Text Scroll MP3 Information Display Press the [SETUP] key ▶ Select [Display] Press the [SETUP] key ▶ Select [Display] ▶ Select [Text Scroll] ▶ Select [Media Display] 12:05 Setup Display Brightness Mode Pop up  Text Scroll MENU :  This feature is used to change the information displayed within USB and This feature is used to scroll text...

  • Page 70: Sound Settings

    5 Setup Sound Settings After selecting the Fader/Balance, use SDVC (Speed Dependent Volume [Tune(Up),[Tune(Down)] and Control) [HD/CAT(Left)], [Folder(Right)] to move Press the [SETUP] key ▶ Select [Sound] Sound Settings the cursor on the control screen to the ▶ Select [Speed Dependent Vol] desired position.
  • Page 71 5 Setup Clock/Date Setting Use [HD/CAT(Left)], [Folder(Right)] to Voice Recognition Setting select the Month, Day, and Year and use Press the [SETUP] key ▶ Select [Sound] Clock Setting [Tune(Up), [Tune(Down)] to change ▶ Select [Voice Recognition Vol] settings. Press the [SETUP] key ▶ Select [Clock/Calendar] ▶...

  • Page 72: Bluetooth Setting

    5 Setup Bluetooth® Setting Name Description Viewing Paired Phone List 1.  Moves to the previous screen Press the [SETUP] key ▶ Select [Phone] Pairing a New Device Connect/disconnects currently 2. Connect ▶ Select [Paired Phone List] selected phone Deletes the currently selected Press the [SETUP] key ▶...
  • Page 73 5 Setup Auto Download (Contacts) Audio Streaming Press the [SETUP] key ▶ Select [Phone] Press the [SETUP] key ▶ Select [Phone] ▶ Select [Auto Download] ▶ Select [Audio Streaming] 12:05 Setup 12:05 Setup Phone Phone  Auto Download  Auto Download Use [HD/CAT(Left)], [Folder(Right)] to ...

  • Page 74: System Setting

    5 Setup System Setting Voice Recognition Mode Setting Language Memory Information Press the [SETUP] key ▶ Select [System] Press the [SETUP] key ▶ Select [System] ▶ Select [Prompt Feedback] ▶ Select [Language] Press the [SETUP] key ▶ Select [System] 12:05 ▶...
  • Page 75 MAP DATABASE HOTLINE M & SOFT AMERICA MAP CENTER TEL : 888-757-0010 WEBSITE : www.mapnsoft.com This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
