- Page 1 POCSAG ALPHANUMERIC DISPLAY RADIO PAGER User’s Manual MODEL: ACE-4010(155M) ACE TELECOM CO., LTD.
-
Page 2: Table Of Contents
CONTENTS - FEATURES --------------------------------------------------------------------------------------------- 3 - DESCRIPTION OF INDICATORS & SYMBOLS --------------------------- 4 - CONTROL BUTTONS ------------------------------------------------------------------------- 5 - OPERATION ------------------------------------------------------------------------------------------- 5 Turning Pager On -------------------------------------------------------------------------------- 5 Turning Pager Off ---------------------------------------------------------------------------- 5 Read Personal Message ----------------------------------------------------------------- 6 Delete Personal Message --------------------------------------------------------------- 6 Lock Personal Message --------------------------------------------------------------- 7... -
Page 3: Features
FEATURES - 2 / 4 Line Display per Line besides Icon Indicator Line - 14 Character Display per Line - Address Capability: 6 - Personal Message Storage per Slot : 400 Characters - Maildrop Message Storage per Slot : 500 Characters - Personal Message Slot : 60 (including 20 NoteBook Slots) - MailDrop Message Slot : 16 - Message Lock up to 30 Personal Messages... -
Page 4: Description Of Indicators & Symbols
DESCRIPTION OF INDICATORS & SYMBOLS ! ! ! ! Indicators ! ! ! ! Symbols Read MailDrop Pager On Calendar Service Area Set Incoming message Alert Auto Power On Set Time, Date Batter Gauge Set Alarm Vibration Mode Set Auto Power On/Off Audible Mode Set Scrolling Speed Set Alert Periodic Time for... -
Page 5: Control Buttons
CONTROL BUTTONS • Used to go left through the Function menu and your messages, to decrease the numbers through the functions like time, alarm, date settings. • Used to go right through the Function menu and your messages, to increase the numbers through the functions like time, alarm, date settings. -
Page 6: Read Personal Message
twice 1. From the Standby screen, press to display the Function menu (Fig. 2) 2. Press • or • to move the cursor to 3. Press . "Pager Off? No" is displayed. 4. Press • or • to display "Pager Off? Yes". 5. -
Page 7: Lock Personal Message
Up to 30 messages can be locked to prevent them from being deleted or from being replaced when memory is full. 1. From the Fig. 6, move the cursor to 2. Press to lock the message. Unlock Personal Message First, read the locked message. 1. -
Page 8: Calendar
Its receiving date (May 18th) is displayed on the right lower corner. 3. Press • or • to move the flash to select the maildrop you want to read. 4. Press to read the selected maildrop. In order to delete the maildrop(s), 1. -
Page 9: Setting The Date And Time
and press to select your desired maildrop alert on/off mode. Maildrop Alert On (The pager alerts when it has a mail coming.) Maildrop Alert Off (The pager won't alert when it has a mail coming.) Setting a Vibrating Alert From the Choose alert menu, press while the cursor is moved to Setting an Audible Alert after Vibration From the Choose alert menu, press... -
Page 10: Setting Auto Power On/Off
6) Setting Auto Power On/Off You can set the pager to automatically turn on and off. This feature can greatly improve battery life. 1. From the Function menu screen, press • or • to move the cursor to 2. Press 3. -
Page 11: Setting The Display Duration Time
1. From the Function menu screen, press • or • to move the cursor to 2. Press 3. Press • or • to adjust the display duration time (4, 8, 12, 16 and 20 sec) 4. Press to select. 10 Zoom In/Out 1. - Page 12 2) Easy Way to Change Alert Mode You can easily change the incoming alert mode by pressing • or • twice fast. 1. From the Message initial screen (Fig. 3), press • or • twice fast to change. 2. The alert mode is changed to the following steps. [ Audible alert "...
