Summary of Contents for Euro Appliances EAL900RBQ
- Page 2 INDEX ABOUT THE BBQ Features Technical Information Test Point Pressure Gas Consumption Weight Accessories Information IMPORTANT INFORMATION AND SAFETY What happens if Gas Leaking What happens if Fire Flare-Up Control Setting up the Drip Tray Warning Labels & Stickers Fire Prevention BARBECUE POSITIONING GAS CYLINDER INFORMATION Gas leaking test...
- Page 3 ABOUT THE BARBECUE Features 304 grade stainless steel double skin hood 304 grade stainless steel cooking chassis 304 grade stainless steel fire box with insulation 304 grade stainless steel tube burners 304 grade stainless steel flame tamers 4 burner unit 2 halogen lights Large cooking area 660mm wide x 455mm depth Brass valves...
- Page 4 AC Adaptor Input: 230-240VAC, 50Hz Output: 12VAC 5000Ma Cord 250V, 10A Weight 52kg Gross /40kg Net(Model EAL900RBQ) 46kg Gross /37kg Net(Model EAL900FBQ) Accessories Information Natural gas conversion kit is (to be sold separately) Kit includes 700mm Hose Natural gas regulator See connecting Natural Gas instruction from this booklet Propane gas bottle not included.
- Page 5 IMPORTANT INFORMATION AND SAFETY It is important that you READ THE MANUFACTURER'S INSTRUCTIONS thoroughly. If you have any questions or doubts, call the retailer or visit the Euro Appliances website. http://www.euroappliances.com.au/ What happens if? Gas Leaking 1. Turn the Gas Cylinder off.
- Page 6 Most fires in outdoor barbecues are caused by a build-up of fats and greases. Regularly cleaning of your barbecue is recommended. Refer to the Maintaining Your Barbecue section in this booklet for further information or visit the Euro Appliances website. http://www.euroappliances.com.au/ 1.
- Page 7 BARBECUE POSITIONING This appliance shall only be used in an above ground open-air situation with natural ventilation, without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural convection. Any outdoor enclosure in which the appliance is used shall comply with one of the following: 1.
-
Page 8: Gas Cylinder Information
GAS CYLINDER INFORMATION 1. This appliance is designed to be used with a gas cylinder not exceeding (Australia 9KG) 2. The gas cylinder supply valve must be turned off when the appliance is not in use. 3. Gas cylinders must be stored outdoors, out of reach of children and must not be stored in a building, garage or any other enclosed area. - Page 9 Gas Leak Test Procedure The BBQ gas bottle, regulator & hose assembly should be checked for leaks, using the soapy water leak test, every time you reconnect your regulator to the BBQ gas bottle. You should also test after any long period of non-use, such as at the beginning of BBQ season In a small container, mix up a solution of 1/2 water and 1/2 detergent or soap.
-
Page 10: Lighting Your Barbecue
LIGHTING YOUR BARBECUE This barbecue is designed for use outdoors, away from any flammable materials. It is important that there are no overhead obstructions and that there is a minimum distance of 50mm from the side or rear of the appliance. The barbecue must be used on a level, stable, non-flammable surface. - Page 11 Flat Plate / Flat-Ribbed Plate The burners heat the griddle plate directly, which then cooks the food on contact. These allow for the cooking of smaller items, such as seafood, which could fall through the spaces of a grill. They are also suitable for cooking items that require high-temperature/ short-duration cooking, such as vegetables and smaller cuts of fish.
-
Page 12: Cleaning And Care
CLEANING AND CARE All cleaning and maintenance should be carried out when the barbecue is cool and with the fuel supply turned OFF at the gas cylinder after each use. DO NOT mistake brown or black accumulation of grease and smoke for paint. Interiors of gas grills are not painted at the factory (and should NEVER be painted). - Page 13 Spider and Insect Spiders and insects can nest in the burners of the grill and cause the gas to flow from the front of the burner. This is a very dangerous condition, which can cause a fire to occur, thereby damaging the grill and making it unsafe to operate.
- Page 14 Recommended Cleaning Product AKTIVO Easy Off Oven + BBQ Cleaner AKTIVO Easy Off Oven + BBQ Cleaner removes grease, oil and carbon build-up. With a powerful, non-caustic, low fuming formulation, the active ingredients will lift away the grease, grime, fat and burnt food from your oven, microwaves, cooktops and grills.
- Page 15 RECOMMENDATIONS Have propane (Aus)/ULPG (NZ) cylinder (LP units) filled by an authorised LPG supplier. Check all gas line connections for leaks with a soapy solution prior to lighting and tighten until bubbles disappear. Preheat the barbecue for 2 - 5 minutes before cooking. After cooking, turn knob to hi setting for 5 minutes to burn off excess grease deposits.
- Page 16 ASSEMBLY INSTRUCTIONS Ensure all transit protection is removed prior to assembly. Foot Assembly Flame tamer assembly Cooking grid/plate assembly Warming rack assembly...
- Page 17 Grease tray Battery is require for ignition Battery (Battery is not included) Transformer (for BBQ lights / LED) Assembly Transformer needs to be installed and fixed where it is located well away from high temperatures. The transformer must be always kept dry.
- Page 18 List of Spare Parts Expanded view and Part List (image is for illustration purpose only model EAL900RBQ) Parts Description Part No Description Part No Description Warming Rack Control panel Cast iron cooking grid Knob bezel with blue LED Cast iron flat plate...
- Page 19 Expanded view and Part List (image is for illustration purpose only model EAL900FBQ) Parts Description Part No Description Part No Description Lid handle Control panel Lid unit Regulator and hose Cast iron plate Cable for LED Cast iron grid Transformer Flame tamer Control knob burner...
- Page 20 Control Knob LED Always keep the plug in dry condition. Removed the control knob. Unscrew the knob bezel. Take off the unit and disconnect the cable. Replace a new one and reassemble...
- Page 21 BUILT IN INSTALLATION The construction of the enclosure and installation of the bbq should be carried out only by authorised persons. The barbecue must also be secured to the enclosure to prevent it being pulled out and straining the gas connections.
- Page 22 EAL900RBQ...
- Page 23 (when not used with a EURO Alfresco Kitchen Solution) Do not Block the ventilation slots adjacent to the side of the BBQ hood/lid...
- Page 24 NATURAL GAS CONVERSION PROCEDURE Please contact Eurostyle to request a Natural Gas Regulator Kit if the appliance is being converted to Natural Gas. Conversions only to be done by an authorized person. A restraining tether or bracket is required to be fixed to the appliance and to the wall within 50mm of each connection point.
- Page 25 Instructions for converting the main burners 1. Unscrew and remove the rear panel pictured. 2. Unscrew the main burner securing screws and remove the burner, sitting it alongside. 3. With the burner removed, you will see the brass gas jet which is screwed into the end of the valve. Using the socket driver supplied, unscrew the end LPG jet while retaining the inner (NG) jet.
-
Page 26: Warranty
4. Reassemble the burner. Note: Please make sure the gas valve is located well inside the main burner tube when re-installing the burners. 5. Repeat the above steps for the other main burners WARRANTY What Is Covered In The Warranty See our policy warranty in our website http://www.euroappliances.com.au/wp-content/uploads/Euro-Card.pdf What Is Not Covered In The Warranty...
