Model No. GBC1747WPF-U / GBC1747WRS-U / GBC1747WBS-U
(ASDA Spec Code: 16B.02.17.031 / 16B.02.17.032 / 16B.02.17.033 )
FOR YOUR SAFETY:
Read the following instructions carefully and
be sure your barbecue is properly installed,
assembled and cared for. Failure to follow these
instructions may result in serious bodily injury
and/or property damage.
FOR YOUR SAFETY:
1. Do NOT store or use gasoline or other
flammable liquids or vapors in the vicinity of
this or any other appliance.
2. When cooking with oil/grease, do NOT allow
the oil/grease to exceed 350ºF (176.5ºC).
Do NOT store or use extra cooking oil in the
vicinity of this or any other appliance.
Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 2
Expanded View & Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing Gas Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Gas Regulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Refund Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Customer Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Contact Us . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION . PLEASE READ AND KEEP
FOR FUTURE REFERENCE .
If you are assembling this unit for someone else, give this manual to him or her to read and save for
future reference .
0359-16
Manufactured in China for: RevoAce Inc . Limited
Hong Kong, China
UNIFLAME GAS BBQ GRILL
.
If you smell gas -
1. Shut off gas to appliance.
.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from
the appliance and immediately
call your gas supplier or your fire
department.

Table of Contents

OWNER'S MANUAL
.
Never operate this appliance unattended.
This grill is supplied with a 27 mm clip
on propane regulator suitable for use
with propane patio gas cylinders.
CAUTION
FOR YOUR SAFETY:
Do not use spirit, petrol or comparable fluids for
lighting or re-lighting!
FOR YOUR SAFETY:
Keep children and pets away.
FOR YOUR SAFETY:
For Outdoor Use Only (outside any enclosure)
ATTENTION
This barbecue will become very hot, do not move it
during operation.
.
.
.
.
.
GBC1747W-U-E-OM-F103

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GBC1747WPF-U and is the answer not in the manual?

Questions and answers

Kathleen Robertson
May 12, 2025

How do you change the regulator and hose on a uniflame GBC1747WPF-U gas bbq

1 comments:
Mr. Anderson
May 20, 2025

To change the regulator and hose on a Uniflame GBC1747WPF-U gas BBQ:

1. Make sure all control knobs are in the OFF position.
2. Turn the regulator valve handle to the OFF position (counterclockwise).
3. Remove the regulator from the gas cylinder by lifting it off after turning it OFF.
4. Detach the old hose from both the regulator and the BBQ, if needed.
5. Replace with a new approved hose (maximum length 1.5 meters) and ensure it meets the relevant safety standards.
6. Attach the new hose securely to the BBQ and the new regulator.
7. Remove the seal cap from the gas cylinder valve.
8. Place the new 27 mm propane regulator vertically onto the cylinder valve and push down firmly until you hear a "click."
9. Turn the regulator valve handle clockwise to the ON position to start gas flow.

Only use regulators and hoses approved for gas at the specified pressure, and replace the regulator within 10 years of manufacture.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for Uniflame GBC1747WPF-U

  • Page 1: Table Of Contents

    OWNER’S MANUAL UNIFLAME GAS BBQ GRILL Model No. GBC1747WPF-U / GBC1747WRS-U / GBC1747WBS-U (ASDA Spec Code: 16B.02.17.031 / 16B.02.17.032 / 16B.02.17.033 ) FOR YOUR SAFETY: Read the following instructions carefully and be sure your barbecue is properly installed, assembled and cared for. Failure to follow these instructions may result in serious bodily injury and/or property damage.
