Retro Roller F1 898 Instruction Manual

Instruction manual
Retro roller model F1 898
Imported by Van der Meulen.
www.retroroller.eu
PLEASE NOTE! Assembly must be done
by an adult. Keep out of reach of young
children because of the small parts.
IMPORTANT:
1. For the child's safety, all assembly steps must be
carried out properly. Incorrect assembly could
cause injury.
2. Lubricate moving parts regularly or after long-
term use.
3. Ensure that all nuts and bolts have been tightened
before use. Check nuts and bolts regularly and
tighten where necessary.
4. Components showing signs of wear should be
replaced immediately.
5. The child should never be left unattended when
riding in the vehicle.
1
Tool required:
3
HARWARE SET COMPONENTS
No. Qty Description
Hexagon locknut
*898.8001 1
Hexagon locknut
*898.8002 8
Machine screw
*898.8003 1
Machine screw
*898.8004 8
Self tapping screw
*898.8005 4
*898.8006 4 Hub cap
* Standard hardware items may be purchased locally
or
short
Spec.
M4
Ø3/16"
M4x24mm
Ø3/16x13mm
Ø4/13mm
Ø10mm
2
Part no x Qty
Some parts may hav already been pre-assembled
upon receipt.
(898.001) x1
(898.002) x1
(898.004) x1
(898.006) x2
(898.008) x4
(898.010) x1
2
(898.8001) x1 (898.8002) x8
(898.8004) x8 (898.8005) x4
(898.003) x1
(898.005) x1
(898.007) x1
(898.009) x1
(898.011) x1
(898.8003) x1
(898.8006) x4
