Point Six WOWPIR Installation And Operation Instructions

Wireless sensor
Hide thumbs
1
2
3
4

Advertisement

Table of Contents

FCC ID: M5ZWOWPIR
Installation and Operation Instructions for the Point Six Wireless Sensor.
Wireless Sensor Model WOWPIR
Installation and Operation Instructions
The WOWPIR wireless Personal iButton Reader transmits a digital value representing
either the unique serial number of a touched iButton and a 16 bit field representing the ID
of the PIR to a 418 MHz receiver. The WOWPIR is enclosed in a high impact ABS
enclosure for direct surface mounting in the environment to be measured. WOWPIR is
battery operated
Application: Touch the iButton reader port to the iButton to be read. The red LED will
flash to indicate a successful read and transmission of data.
Battery: A 3.0 Volt lithium battery powers the WOWPIR wireless iButton reader. The
battery will last for more than 5 years in the idle state (as shipped from the manufacturer).
The WOWPIR will transmit data approximately 200,000 times before the battery must be
replaced. The WOWPIR is (other than the battery) covered with a water resistant rubber
coating to protect the electronics from the environment and condensation. The user can
replace the battery. The WOWPIR may be placed in a quiescent state (battery life greater
than 5 years) by covering the reader port with a nonconductive material such as tape.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES, OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY
NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT
ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY
CAUSE UNDESERED OPERATION
Point Six, Inc.
FCC ID: M5ZWOWPIR
MADE IN USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WOWPIR and is the answer not in the manual?

Questions and answers

Related Manuals for Point Six WOWPIR

Summary of Contents for Point Six WOWPIR

  • Page 1 16 bit field representing the ID of the PIR to a 418 MHz receiver. The WOWPIR is enclosed in a high impact ABS enclosure for direct surface mounting in the environment to be measured. WOWPIR is battery operated Application: Touch the iButton reader port to the iButton to be read.
  • Page 2 FCC ID: M5ZWOWPIR Wireless PIR Data Format The Point Six, Inc. 418 MHz wireless sensors require a compatible receiver with the ability to receive, error check and provide RS232 and RS422/485 interface. This document describes the data format provided by the HA8-wow 418 MHz. Receiver.
  • Page 3 FCC ID: M5ZWOWPIR C90C188C040000001B483BA4BCA5B <CR> This field is the unique serial number of the iButton touched.. C90C188C040000001B483BA4BCA5B <CR> This field is the 16-bit serial number of the PIR. C90C188C040000001B483BA4BCA5B <CR> This field is the CRC-16 error check as was originally received and checked.
  • Page 4 § Connect the equipment and the affected receiver to power outlets on separate circuits. § Consult the dealer or an experienced radio/TV technician for help. MODIFICATIONS Changes or modifications not expressly approved by Point Six Inc. could void the user's authority to operate the equipment.
