Thank you for purchasing the BBS010 Slim Hands-Free Speaker
from BEEWI. Please read the following instructions to learn how
to configure and use more effectively your product.
The BBS010 Slim Speaker is a high performance full duplex hands-free solution specially
designed for users to enjoy the convenience and freedom of wireless hands-free communication in the
car, but also at home or in the office. It includes advanced built-in microphone and 1W speaker with
Digital Sound Processor (DSP) for echo cancellation and noise reduction that gives a loud and clear
full duplex sound quality.
The BBS010 Slim Speaker is a Bluetooth 2.1+EDR wireless speaker compatible with all Bluetooth
compliant devices using HFP profiles such as mobile phones.
Warning: always obey local legislation regarding the use of mobile phones in the car.
1. Product Description
1.1. Packaging content
- Bluetooth Speaker
- USB cable
- 12-24V Car Adapter with USB port
- Car visor clip
- User Manual CD
1.2. Features
- Full Duplex, background noise reduction with CVC Digital Signal Processor ( DSP)
- Multipoint Technology to connect 2 mobile phones simultaneously
- Extra slim size and light weight
- No installation required
- Up to 1000 hours standby time and 5 hours continuous talk time under normal usage.
1.3. Product overview
- (1) Speaker
- (2) Microphone
- (3) LED
- (4) Charging Socket (Micro-USB)
- (5) MFB (Multi-Function Button)
- (6) Volume Up (V+) & Down (V-)
1.4. Product Specification
Bluetooth Specification
Bluetooth Profiles
Frequency Band
Power class & range
Number of Paired Devices
Max Audio Output Power
Standby Time
Talking Time
Battery
Battery Charging Time
Dimensions
Weight
2. Using the product
Bluetooth V2.1+EDR
HSP - HFP1.5
2.4GHz~2.48 GHz ISM Band
Class 2, Up to 10 meters
Up to 8 devices
1 W
Up to 1000 hours (40 days)
Up to 5 hours
340mAH Li-Polymer rechargeable battery
Up to 2 hours
100L x 48W x 8D mm
42 g
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BeeWi BBS010
Summary of Contents for BeeWi BBS010
- Page 1 Digital Sound Processor (DSP) for echo cancellation and noise reduction that gives a loud and clear full duplex sound quality. The BBS010 Slim Speaker is a Bluetooth 2.1+EDR wireless speaker compatible with all Bluetooth compliant devices using HFP profiles such as mobile phones.
- Page 2 The alternated flashes indicate that the speaker is in pairing mode. Search for Bluetooth devices in the phone, select “BeeWi BBS010” on display and enter the pass key “0000” to add the speaker to the pair list. When pairing is complete, the blue and red LED light will stop flashing, and the speaker will automatically connect to the phone and go in standby mode with the blue light flashing every 3 seconds.
- Page 3 possible to disconnect the speaker either manually or by moving out of range. When losing the connection/link, the speaker will automatically power off after 15 minutes. 2.7. Multipoint The Multipoint function allows a simultaneous connection to 2 mobile phones. In default setting of the speaker’s Multipoint function is disabled.
