Page 1: Table Of Contents
TRUE INSTALLATION MANUAL th models heated cabinets manufacturing co CONGRATULATIONS! You have just purchased the finest commercial heated cabinet available. You can expect many years of trouble-free operation. TABLE OF CONTENTS SAFETY INFORMATION Safety Precautions Proper Disposal, Connecting Electricity, & Adapter Plugs INSTALLATION Ownership, Uncrating, &...
Page 2: Safety Information
TRUE th models heated cabinets truemfg SAFETY INFORMATION How to Maintain Your True Refrigerator to Receive the Most Efficient and Successful Operation. You have selected one of the finest commercial refrigeration units made. It is manufactured under strict quality controls with only the best quality materials available.
Page 3: Proper Disposal, Connecting Electricity, & Adapter Plugs
TRUE th models heated cabinets truemfg DANGER! WARNING! RISK OF CHILD HOW TO CONNECT ELECTRICITY DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR ENTRAPMENT REMOVE THE GROUND PRONG FROM THE POWER CORD. FOR PERSONAL SAFETY, THIS APPLIANCE MUST BE PROPERLY GROUNDED. PROPER DISPOSAL OF THE CABINET The power cord from this appliance is equipped with a grounding Child entrapment and suffocation are not problems of the past.
Page 4: Installation
TRUE th models heated cabinets truemfg INSTALLATION OWNERSHIP ELECTRIC INSTALLATION & SAFETY INFORMATION To ensure that your unit works properly from the first day, it must be installed properly. We highly recommend a trained refrigeration • If the supply cord is damaged, it must be replaced by a special mechanic and electrician install your TRUE equipment.
Page 5: Wire Gauge Chart
TRUE th models heated cabinets truemfg WIRE GAUGE CHART LOCATING A. Remove louver from the front of cabinet and backguard (if 115 Volt s Distance In Feet To Center of Load applicable) from rear of cabinet. Amps 20 30 40 50 60 70 80 90 100 120 140 160 Skid bolts are located in each of 4 corners inside cabinet bottom.
Page 6: Leveling
TRUE th models heated cabinets truemfg LEVELING INSTALLATION OF CASTORS OR OPTIONAL LEGS A. Set unit in its final location. Be sure there is adequate ventilation in your room. Under extreme heat conditions, (100°F+, Important Safeguard for installation of leg/castor. Images 1-5 demon- 38°C+), you may want to install an exhaust fan.
Page 7: Sealing Cabinet To The Floor
TRUE th models heated cabinets truemfg SEALING CABINET TO FLOOR STEP 1 - Position Cabinet - Allow one inch between the wall and rear of the refrigerator to assure proper ventilation. For freezers 3 inches between the wall and rear of the cabinet will assure proper ventilation.
Page 8: Setup
TRUE th models heated cabinets truemfg SETUP STANDARD ACCESSORIES WARNING! Do not use pliers or any crimping tools SHELVING INSTALLATION / OPERATION when installing shelf clips. Altering shelf SHELF INSTALLATION: clips in any way can lead to shelving instability. STEP 1 A.
Page 9 TRUE th models heated cabinets truemfg INSTALLING THE VENTILATION CAP HUMIDIFICATION PROCEDURE NOTE: Be sure unit is unplugged before proceeding. ADJUSTING HUMIDITY A. Remove the ventilator cap, screws and gasket from the plastic This instruction is TRUE’s recommended procedure for providing bag located on the inside floor of heated cabinet.
Page 10: Operation
TRUE th models heated cabinets truemfg OPERATION STARTUP A. The cabinet is ready to operate. Plug in the unit. C. Excessive tampering with the control could lead to service difficulties. Should it ever become necessary to replace Temperature controls are factory-set to maintain an approxiate temperature control, be sure it is ordered from your TRUE temperature of 140°F -180°F (60°C -82°C).
Page 11: Maintenance, Care, Cleaning
TRUE th models heated cabinets truemfg MAINTENANCE, CARE, CLEANING STAINLESS STEEL EQUIPMENT CARE 8 STEPS THAT CAN HELP PREVENT RUST ON AND CLEANING STAINLESS STEEL: CAUTION: Do not use any steel wool, abrasive or chlorine based USING THE CORRECT CLEANING TOOLS products to clean stainless steel surfaces.
Page 12: General Maintenance
TRUE th models heated cabinets truemfg GENERAL MAINTENANCE LIGHT BULB REPLACEMENT (IDL) INTEGRATED DOOR LIGHTING LIGHT BULB REPLACEMENT (INTERIOR LIGHTS) GENERAL MAINTENANCE WARNING: When replacing a light bulb make sure power to the unit is either turned off or unplugged. WARNING: When replacing a light bulb make sure power to the unit is either turned off or unplugged.
Page 13 TRUE th models heated cabinets truemfg EFRIGERATION ® WARRANTY INFORMATION (U.S.A & CANADA ONLY!) MADE IN U.S.A. SINCE 1945 THIS WARRANTY ONLY APPLIES TO UNITS SHIPPED FROM TRUE'S MANUFACTURING FACILITIES AFTER SEPTEMBER 1, 2015. THREE-YEAR PARTS & LABOR WARRANTY TRUE warrants to the original purchaser of every new TRUE refrigerated unit, the cabinet and all parts thereof, to be free from defects in material or workmanship, under normal and proper use and maintenance service as specified by TRUE and upon proper installation and start-up in accordance with the instruction packet supplied with each TRUE unit.
