Passtech ZP100WR User Manual

Rfid locker lock
Hide thumbs
Table of Contents

Advertisement

Quick Links

USER GUIDE
RFID LOCKER LOCK
(model : ZP100WR)
Version 1.2
- 1 -
2010-10-06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZP100WR and is the answer not in the manual?

Questions and answers

Related Manuals for Passtech ZP100WR

Summary of Contents for Passtech ZP100WR

  • Page 1 USER GUIDE RFID LOCKER LOCK (model : ZP100WR) Version 1.2 - 1 - 2010-10-06...

  • Page 2: Table Of Contents

    Table of Contents 1. Understanding ZP-100WR RFID lock ................3 1.1 What is ZP100WR RFID Locks? ..............3 1.2 Card Type and Functions ................. 3 2. Type of Lock Operation ....................4 2.1 Free Selection (Day Use) ................... 4 2.2 Fixed Mode (Pre-Assigned Mode) ..............4 3.

  • Page 3: Understanding Zp-100Wr Rfid Lock

    1. Understanding ZP-100WR RFID lock 1.1 What is ZP100WR RFID Locks? ZP100WR RFID lock is a locker lock operated by 13,56 Mhz RF keys such as card, tag, key ring or wristband. It has the wireless online communication feature that provide the central controlling and remote monitoring ( See Esmart ultra user manual ) 1.2 Card Type and Functions...

  • Page 4: Type Of Lock Operation

    2. Type of Lock Operation ZP-100WR RFID lock are designed to work for the various operation requirements by simple set up process. Following operation modes can be programmed before or after lock installation. 2.1 Free Selection (Day Use) - User can select any empty locker. - Red LED lamp is blinked to show the locker is in use (Option.

  • Page 5: Basic Operation Of The Lock

    3. Basic operation of the Lock ZP100WR RF Locker lock is woken up by touch sensor, and read and write the User Card when User card is placed on the Front body. Once the User Card is authenticated by RF lock, the bolt of the lock will come out (Free Selection mode) or come backward and forward (Fixed Mode).

  • Page 6: Replacing Old Master Cards With New Master Cards

    (2) Maximum five Master cards can be registered in a lock. 3.2.2 Replacing old Master cards with New Master cards There are two ways to delete the lost Master card and register new Master card in the lock. (1) Using Time/Master Change Card Read the master cards (all Master cards to be used in a lock) to register in each lock at Time/master change menu in LOS program (or LIS program).

  • Page 7: What Can I Do With Master Card

    3.2.4 What can I do with Master card? The function of the Master card is decided when Set up card is generated by lock installer from the following three functions. Door Open & User Card delete : Turn off the alarms, open the lock and delete old User card registration.

  • Page 8: Fixed Mode (Pre-Assigned Mode)

    Lock will check the lock ID and key of the user card (or any form of user key). Lock will emit Green LED and beep sound once. Bolt will be moved and locker will open. User information will be erased from the lock so that new user can use the empty lock.

  • Page 9: Low Battery Warning And Battery Change

    new user card is issued by LOS program. Then, Lock updates it’s revision number when new user card is registered. The other user cards which are assigned to this locker also needs to be reissued with updated lock revision by LOS program.

  • Page 10: Audit Trail

    3.5 Audit Trail Put Audit Trail Card to the lock. The latest event data (up to 18 events) will be downloaded from lock to the Card. Wait until melody is on. Read the Card at LOS program, and 18 event data will be saved to the PC. 3.6 Open in Emergency In case User forget his(her) password, Operator can open the lock by Master Card.

  • Page 11: Annex A Beep & Led Table

    ANNEX A Beep & LED Table Beep Description 1 x short beep 1 x Green(2sec) 3 x short beep 3 x Red(2sec) flashes Operation Error 3 x short beep 1 x Red & Green in turn(2sec) Time over Do-Re-Mi Melody 1 x Red &...

  • Page 12: Annex B Trouble Shooting

    ANNEX B Trouble Shooting 1) Master card registration should be followed after deleting old master card in the lock by Master card registration in the lock Owner card. was failed. 2) Put Master card on the lock before waiting time is out after Owner card. Cannot open the lock with Master Master card is not registered in the lock.
  • Page 13 Should you have any questions, please contact your local distributor or our technical support. Version 1.2 - 13 - 2010-10-06...
  • Page 14 USA-Federal Communications Commission (FCC) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules.
