User Manual
For
Wireless Mini PCI Adapter
(Atheros AR9223)
Model Number : WMP-N09
Revision: 1.3
This document contains confidential proprietary information and is the property of Alpha Networks Inc.. The contents
of this document may not be disclosed to unauthorized persons without the written consent of Alpha Networks Inc..
Alpha Networks Proprietary and Confidential Information
Advertisement
Table of Contents
Summary of Contents for Alpha Networks WMP-N09
- Page 1 This document contains confidential proprietary information and is the property of Alpha Networks Inc.. The contents of this document may not be disclosed to unauthorized persons without the written consent of Alpha Networks Inc.. Alpha Networks Proprietary and Confidential Information...
- Page 2 March of 26th, 2008 Joyce Lin New released • August of 6th, 2008 Amanda Wang Revised Tx & Rx output power • Power consumption • August of 19th, 2008 Jimmy Yang Revised Tx power and Rx sensitivity Alpha Networks Proprietary and Confidential Information...
-
Page 3: Table Of Contents
2.6 R ..............11 EQUIREMENTS OF ELIABILITY AINTAINABILITY AND UALITY 2.7 E ........................11 NVIRONMENTAL EQUIREMENTS I:................................13 PPENDIX END PRODUCT LABELING ....................錯誤! 尚未定義書籤。 MANUAL INFORMATION TO THE END USER ..............錯誤! 尚未定義書籤。 INDUSTRY CANADA STATEMENT ..................錯誤! 尚未定義書籤。 Alpha Networks Proprietary and Confidential Information... -
Page 5: Operation Manual
1. Once utility is executed, a menu with test options will appear. To run a test, press the character key that is assigned to the test option. For example, press “c” to run the continuous transmit test, or press “r ” to run the continuous receive test. Alpha Networks Proprietary and Confidential Information... - Page 6 For example: press “h” to choice single chain or both chains in test mode. Alpha Networks Proprietary and Confidential Information...
- Page 7 11b Power is 17dBm, press ESC to return to the main Test Options menu when finished. 3. Continuous Receive Options Continuous receiver option will put the radio into receive mode to allow for radio measurement. Press ESC to return to the main Test Option menu when finished. Alpha Networks Proprietary and Confidential Information...
-
Page 8: Scope
Friendly user configuration and diagnostic utilities Ÿ Support Linux driver. Ÿ Supports Mini-PCI Type IIIA form factor 2.0 Requirements The following sections identify the detailed requirements of the 802.11n Draft 2.0 mPCI. 2.1 Functional Block Diagram Alpha Networks Proprietary and Confidential Information... -
Page 9: General Requirements
–71dBm at 48Mbps Ÿ Ÿ –70dBm at 54Mbps 2.2.3 IEEE 802.11n Section Feature Detailed Description Ÿ 2.2.3.1 Standard IEEE 802.11n Draft 2.0 Ÿ 2.2.3.2 Radio and BPSK, QPSK, 16QAM, 64QAM with OFDM Modulation Type Alpha Networks Proprietary and Confidential Information... -
Page 10: General Section
650mA at continuous transmit mode (2 Tx chains on ) Ÿ Consumption 250mA at continuous receive mode (2 Rx chains on ) Ÿ 2.2.4.4 Form Factor and Mini-PCI Type IIIA form factor Interface Ÿ 2.2.4.5 LEDs External LED function supported Alpha Networks Proprietary and Confidential Information... -
Page 11: Software Requirements
The product quality is followed-up by ALPHA factory quality control system 2.7 Environmental Requirements Feature Detailed Description Ÿ 2.7.1 Operating The product is capable of continuous reliable operation when operating in ambient temperature of 0 ℃ to +50 Temperature Alpha Networks Proprietary and Confidential Information... - Page 12 10% conditions and 90% non-condensing. Ÿ 2.7.4 Non-Operating The product is not damaged nor the performance is Humidity degraded after exposure to relative humidity ranging Conditions from 5% to 95% non-condensing Alpha Networks Proprietary and Confidential Information...
-
Page 13: Ppendix I
■ Rate: Rate in Mbps ■ NES: Number of FEC encoders used ■ NSD: Number of Data Subcarriers ■ NCBPS: Number of Code Bits Per Symbol (total of all spatial streams) ■ NSS: Number of Spatial Streams Alpha Networks Proprietary and Confidential Information... - Page 14 This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through Alpha Networks Proprietary and Confidential Information...
-
Page 15: End Product Labeling
The transmitter module may not be co-located with any other transmitter or antenna. As long as conduction above is met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements Alpha Networks Proprietary and Confidential Information... - Page 16 (for example, digital device emissions, PC peripheral requirements, etc.). 以下警語適用台灣地區： 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更 原設計之特性及功能。 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用， 並改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射 頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 本模組於取得認證後將依規定於模組本體標示審合格籤，並要求平台上標示「本 品 含射頻模 產 內 組：ID 編號」 Alpha Networks Proprietary and Confidential Information...
