Owner's Manual
Read the instructions before use. This
appliance must be installed in accordance
with such regulations as are in force.
Questions, problems, missing / replacement parts? Before returning to your retailer,
call our customer service department at 1-866-814-0585, 8 a.m. - 8 p.m., EST
Monday-Friday.
TM
36" Square Gas Fire Pit
Model#SRGF11610
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
WARNING
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
WARNING:
CAUTION:
Installer: Leave the instruction manual
to the user for future use.
Consumer: Please keep this manual
for future reference.
For Outdoor Use
Only.
Advertisement
Table of Contents
Summary of Contents for Bali SRGF11610
- Page 1 36" Square Gas Fire Pit Model#SRGF11610 DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your gas supplier or fire department.
- Page 2 If you cannot reach your gas supplier, call the fire department. Installation and service must be performed by a qualified installer, service agency or gas supplier. 36'' Gas Fire Pit SRGF11610 50,000 BTU/HR 20-lb. LP - gas cylinder 2.18 mm...
-
Page 3: Warnings And Cautions
WARNINGS AND CAUTIONS IMPORTANT SAFETY INFORMATION The installation must comform with local codes or, in the absence of local codes, with the CAN/CGA-B 149.2, Propane Installation Code. This appliance requires 20 lb (9 kg) LP gas supply cylinder. The burner must be replaced prior to the appliance being put into operation if it is evident that the burner is damaged. - Page 4 WARNINGS AND CAUTIONS NOTE: PLEASE READ THE FOLLOWING SAFETY RULES: Perform a leak test with a soapy solution: 1. To check gas connections. 2. After connecting a new cylinder. 3. Upon re-assembly after disassembly. This appliance is designed to operate with a standard 20 Ib propane cylinder with Approved Cylinder Connection.
-
Page 5: Exploded View
EXPLODED VIEW... -
Page 6: Parts & Hardware
PARTS & HARDWARE y t i y t i Lid handle 2 pcs 1 pc Sliding track 2 pcs Fire bowl lid Caster 1 pc 1 bag 1 pc Lava rocks/ glass chips Cylinder clamp screw Burner assembly 2 pcs Stator 1 pc Table top panel... - Page 7 ASSEMBLY INSTRUCTIONS Choose a flat place to assemble the product, pad a cardboard to protect the table surface. M6x20 Bolt 16Pcs Attach the right panel (F) and limited strip (O) to the front panel (G) & rear panel (N) with 6 M6x20mm bolts (AA) (Fig.
- Page 8 ASSEMBLY INSTRUCTIONS Fig. 3 Step 3 two stators with 4 Hardware Used AA M6 x 20 Bolt 8Pcs CC M4 x 12 Bolt Assembly 8Pcs Fig. 4 Step 4...
- Page 9 ASSEMBLY INSTRUCTIONS Fig. 5 end (locking position). Fig. 6 Place the burner assembly (D) onto the table top panel (E) . Attach two parts with 4 M4 x 25 bolts (BB), 4 D5 washers (EE). The control panel on the burner assembly (D) should fit the position on the front panel (G).
- Page 10 ASSEMBLY INSTRUCTIONS Fig. 7 Place lava rocks/ glass chips (C) (Max. 5.5 lbs) onto the burner assembly (D). (Fig.7) Fig. 8 Insert the lid handle (A) through fire bowl lid (B) and attach it with the D6 washer (DD) and M5 nut (FF). Place the fire bowl lid (B) onto the table top panel (E) when not use.
- Page 11 ASSEMBLY INSTRUCTIONS Battery Battery Compartment...
-
Page 12: Installation Instructions
INSTALLATION INSTRUCTIONS LAVA rocks (max 5.5lbs) Tighten regulator & cylinder connection... - Page 13 OPERATION WARNING: DO NOT ATTEMPT TO OPERATE THE APPLIANCE UNTIL YOU HAVE READ AND UNDERSTAND ALL PRECAUTIONS . FAILURE TO DO SO CAN RESULT IN PROPERTY DAMAGE, SERIOUS INJURY, OR DEATH. WARNING!!! WARNING Do not use an open flame to check for leakage. FOR YOUR SAFETY: Do not smoke during testing.
-
Page 14: Operation
OPERATION WARNING:DO NOT ATTEMPT TO OPERATE THIS HEATER UNTIL YOU HAVE READ AND UNDERSTAND ALL PRECAUTIONS. FAILURE TO DO SO CAN RESULT IN ATION PROPERTY DAMAGE,SERIOUS INJURY,OR DEATH. Before Lighting The gas fire pit should be thoroughly inspected before each use, and by a qualified service person at least annually. - Page 15 OPERATION CAUTION:AVOID INHALING FUMES EMITTED FROM THE GAS APPLIANCE'S FIRST USE. SMOKE AND ODOR FROM THE BURNING OF OILS USED IN MANUFACTURING WILL APPEAR. BOTH SMOKE AND ODOR WILL DISSIPATE AFTER APPROXIMATELY 30 MINUTES.THE GAS APPLIANCE SHOULD NOT PRODUCE THICK BLACK SMOKE. NOTE: MIN/IGNITE The burner may be noisy when initially turned on.
-
Page 16: Locating Heater For Use
LOCATING HEATER FOR USE FIRE PIT... -
Page 17: Maintenance & Storage
MAINTENANCE/STORAGE CLEANING AND MAINTENANCE : To enjoy years of outstanding performance from your WARNING: gas fire pit, make sure you perform the following FOR YOUR SAFETY ; maintenance activities on a regular basis: DO NOT touch or move gas appliance for at least 45 minutes after use. -
Page 18: Maintenance And Storage
MAINTENANCE AND STORAGE NOTE: Store the fire pit indoors during the winter if it will be subjected to Wait until the appliance is freezing temperatures. cool before covering. Disconnect and remove the cylinder from the appliance before the appliance can be stored indoors. STORAGE Turn the control knob to "OFF"... -
Page 19: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE MEASURES OBSERVED Gas odor Gas leak Check all gas connections Check gas supply pressure Low gas pressure Clean burner parts--see manual Clogged or dirty burner ports Delayed ignition "CLEANING AND MAINTENANCE" section Spent battery Change battery Incorrect burner Incorrect gas supply or pressure Check gas supply pressure...
