Summary of Contents for Altimium PUH2-H2
- Page 1 User Manual PUH2-H2 4K HDMI Splitter 1x2 All Rights Reserved Version: PUH2-H2_2016V1.3...
- Page 2 4K HDMI Splitter 1x2 Preface Read this user manual carefully before using this product. Pictures shown in this manual is for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. The functions described in this version are updated till September 2016.
- Page 3 4K HDMI Splitter 1x2 SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ...
-
Page 4: Table Of Contents
4K HDMI Splitter 1x2 Contents 1. Introduction ......................... 1 1.1 Introduction to 4K HDMI Splitter 1x2 ..............1 1.2 Features ......................1 1.3 Packing List ....................... 1 2. Panel Description ......................2 3. System Connection ..................... 4 3.1 Usage Precautions .................... 4 3.2 System Diagram .................... -
Page 5: Introduction
4K HDMI Splitter 1x2 1. Introduction 1.1 Introduction to 4K HDMI Splitter 1x2 4K HDMI Splitter 1x2 is a HDMI splitter featuring the capability to repeat HDMI or DVI source to 2 displays synchronously. Compliance with HDMI2.0& HDCP2.2, 4K HDMI Splitter 1x2 provides comprehensive resolution capacities up to 4K&... -
Page 6: Panel Description
4K HDMI Splitter 1x2 2. Panel Description DC 5V OUT 2 OUT 1 Name Description Power ① Illuminate red once powered on indicator Indicate the HDCP compliant status of the input signal Input HDCP OFF: No HDMI traffic (no picture) or abnormal link. ②... - Page 7 4K HDMI Splitter 1x2 Note: a) Pictures shown in this manual are for reference only, different model and specifications are subject to real product. b) Output HDCP compliant status depends on input signal. When the input signal is with HDCP, then output signal is with HDCP and vice versa. c) HDMI signal contains both HDMI video signal and embedded audio signal (PCM, Dolby Digital, DTS, DTS-HD), while DVI signal contains solely video signal.
-
Page 8: System Connection
4K HDMI Splitter 1x2 3. System Connection 3.1 Usage Precautions 1) System should be installed in a clean environment and has a prop temperature and humidity. 2) All of the power switches, plugs, sockets and power cords should be insulated and safe. -
Page 9: Edid Management
4K HDMI Splitter 1x2 3.4 EDID Management 4K HDMI Splitter 1x2 comprises 1 HDMI input port & 2 HDMI output ports, and it possess built-in EDID management function. When all output ports are connected with displays, the source device will gain the EDID data from the display connected output 1 port. -
Page 10: Specification
4K HDMI Splitter 1x2 4. Specification Video Input Input 1 HDMI Input Connector 1 female type A HDMI 2.0 Video Output Output 2 HDMI Output Connector 1 female type A HDMI 2.0 Video General Max data rate 18Gbit/s Max Resolution 4Kx2K@60Hz 4:4:4 Compliant with HDCP2.2,and is backward compatible to HDCP... -
Page 11: Supported Input Video Formats
4K HDMI Splitter 1x2 4.1 Supported Input Video Formats Input Resolution HDMI 720 x 480@60Hz 720 x 480I@30Hz 720 x 576@50Hz 720 x 576I@25Hz 1280 x720@50Hz 1280 x720@60Hz ... -
Page 12: Panel Drawing
4K HDMI Splitter 1x2 5. Panel Drawing HDMI2.0 & HDCP2.2 102 mm... -
Page 13: Troubleshooting & Maintenance
4K HDMI Splitter 1x2 6. Troubleshooting & Maintenance Problems Causes Solutions The connecting cables may Check whether the cables not be connected correctly are connected correctly Color losing or no video or it may be broken. and in working condition. signal output in HDMI The display is not Make sure the resolution of... -
Page 14: After-Sales Service
4K HDMI Splitter 1x2 7. After-sales Service If there appear some problems when running 4K HDMI Splitter 1x2, please check and deal with the problems referring to this user manual. Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: We warrants that its products will be free from defects in materials and workmanship for two years, which starts from the first day you buy this product (The purchase invoice shall prevail).
